Wall Mantel and Base with Trim

ASSEMBLY AND INSTALLATION INSTRUCTIONS

Important: Read entire instruction sheet before
assembling or installing mantel kit.
This mantel is only approved for use with any DESA
Heating Products 32" fireplace system and Dimplex
Electric Fireplaces. Do not use mantel with any other
product.
This mantel kit contains the following:
• Mantel pieces (unassembled)
• Dimplex electric fireplace kit (unassembled) 119994-02
• Hardware package 117197-01
• Bracket hardware kit 118983-01
The hardware package 117197-01 contains the following:
• 32 - 1 ⁄ " Screws
1
4
• 2 - 3" Screws
For Dimplex Electric Fireplace Only use the following:
• 14 - 1 / " Screws
1
4
• 2 - Short wood blocks
• 1 - Long wood block
• 1 - Dimplex header
The hardware kit 118983-01 contains the following:
• 13 - Brackets
• 2 - Flat brackets
• 36 - 1/2" or 3/4" Screws
W32WP
Tools required:
• #2 Phillips driver bit (3
• Slotted screw driver
• Pencil
• Measuring tape
• Drill driver
If any wood pieces are missing or damaged, contact the
dealer where you purchased this mantel for replacement.
If hardware is missing or damaged, contact DESA Heating
Products at 1-866-672-6040 for referral information. You can
also visit DESA Heating Products' technical service web site
at www.desatech.com.
Note: Gather all mantel pieces together before assembling
mantel.
WARNING: Only use 1
assemble mantel. Damage to mantel will result if other
screws are used for this purpose.
WARNING: Use only 1/2" or 3/4" screws with brack-
ets in hardware pack 118983-01. Damage to mantel will
result if other screws are used for this purpose.
www.desatech.com
/ " min. length)
1
2
/ " screws in pocket holes to
1
4
