Chapter 1
Overview
This section provides a general overview of the Intel
of the following sections.
•
•
•
1.1 Overview
The RAID Controller SRCS16 provides a high-performance Intelligent Peripheral
Component Interconnect to High Speed Serialized AT Attachment (PCI-to-Serial ATA)
interface with Redundant Array of Independent Disks (RAID) control capabilities. Serial
ATA RAID controllers provide reliability, high performance, and fault-tolerant disk
subsystem management.
You can install the RAID Controller SRCS16 on a PCI bus and use it to connect Serial ATA
drives to the host computer over a Serial ATA bus.
The RAID Controller SRCS16 is an ideal RAID solution for internal storage on workgroup,
departmental, and enterprise systems. SATA RAID controllers offer a cost-effective way to
implement RAID in a server.
The RAID Controller SRCS16 supports all major operating systems, such as Microsoft*
Windows* XP, Microsoft* Windows* 2000, Microsoft* Windows Server* 2003, Novell*
NetWare* 6.5, Red Hat* Linux* 9.0, Red Hat* Enterprise Linux* 3.0, and SuSE* Linux* 9.0.
1.2 Features
Features of the RAID Controller SRCS16 include:
•
•
•
•
•
•
•
•
Intel® RAID Controller SRCS16
Section 1.1, "Overview," page 14
Section 1.2, "Features," page 14
Section 1.3, "Hardware," page 15
Note: The operating systems supported by this controller may not be supported by
your server board. Please refer to the tested OS list for your server board.
Support for hard disk drives with capacities greater than 8 Gbytes
Online RAID level migration
RAID remapping
No reboot necessary after expansion
User-specified rebuild rate
Support for RAID levels 0 (striping), 1 (mirroring), 5 (striping and parity data across all
drives), 10 (mirroring and striping), and 50 (RAID 5 and striping)
Advanced array configuration and management utilities
NVRAM for storing RAID system configuration information and Configuration on Disk
(COD); the firmware is stored in flash ROM for easy upgrade
®
RAID Controller SRCS16. It consists
14
