Summary of Contents for PEUGEOT ELYSEO 125
-
Page 2: Table Of Contents
Information Information /Prolonged immobilisation ......2-3 Equipment ..............4 Instrument panel ............5 Switch ................6 Petrol ................7 Check and change engine oil ......... 8 Check and change coolant..........9 Battery / Fuse .............. 10 Lighting / Signalling ............11 Starting the engine ............ -
Page 3: Information /Prolonged Immobilisation
Use only petrol, oil and lubricants tested and recommended by PEUGEOT . Information Prolonged immobilisation You have just purchased a PEUGEOT scooter. Thank you for the confidence that you have shown in our company. This guide describes how to control, use and perform basic maintenance on your new PEUGEOT scoo- ter. - Page 4 Protection of the environment Inspection before the vehicle leaves General What the buyer has to do. - A worn spark plug, a badly fixed suppressor, a clogged air filter, a badly adjusted carburettor are all factors which can appreciably To check reduce the lifespan of the catalyser and the - The fuel level exhaust.
-
Page 5: Equipment
Equipement - Battery housing - Passenger support handle - Saddle lock - Rear disk brake * - Stand lever - Central stand with lever - Side stand * - Front disk brake - Hand glove box - Flap - Engine number - Manufacturer’s plate - Front brake lever - Throttle... -
Page 6: Instrument Panel
Instrument panel - Headlight indicator light - Oil pressure telltale Warning If the oil pressure telltale comes on when driving, it is essential to stop the vehicle and to check the level of engine oil (see level of engine oil page 8). - Indicator light - Antit theft warning light - Fuel level meter... -
Page 7: Switch
Ignition keys and locks Two keys (1 red and 1 black) are supplied with the scooter and are identified by a number. Please keep them apart and note the reference number. The ignition key : - Makes the contact when starting - Locks the steering - Unlocks the saddle and the hand glove - Starter switch... -
Page 8: Petrol
Saddle To open : - Insert the ignition key in the lock at the back of the left side, rotate it a quarter of a turn towards the right and lift the saddle. To close : - Press the back of the saddle: you do not need the key. The seat storage compartment gives access to : - Helmet housing - Petrol tank... -
Page 9: Check And Change Engine Oil
Checking and changing engine oil (Frequency : see maintenance booklet) - Checking engine oil level. Engine cold or at a standstill for at least 10 minutes, - Put the vehicle onto its central stand on level ground - Check the oil level contained in the engine housing using the peephole located on the lower right hand side of the engine;... -
Page 10: Check And Change Coolant
- In the event of high consumption of coolant In all cases, you will cause irreversible damage to your vehicle. Contact a Peugeot dealer for maintenance and repair. Checking the level of coolant is carried out with the engine cold and at a standstill :... -
Page 11: Battery And Fuse
Use demineralized water or special lead battery water only for your battery; tap water will reduce its life. Please call a PEUGEOT dealer if you have excessive electrolyte loss. It is essential that used batteries must be taken to an approved recycling point. -
Page 12: Lighting And Signalling
Lighting and signalling Lighting and signalling equipment in good working condition is essential for safety. Check the various lamps from time to time before starting and when using your scooter to make sure that they are working as they should. - Lamp characteristics Headlight/Diplight .... -
Page 13: Starting The Engine
Starting the engine - With the electric starter For safety reasons : - Put the scooter on its central stand The electric starter will not work unless you squeeze the left brake lever. To start the engine : - Turn the ignition key to the position - Squeeze the brake lever - Press the starter button... -
Page 14: Running / Driving
In case gearbox oil lack, have it topped up or renewed by your local dealer. - Spark plug (NGK CR8E) It is advisable to respect strictly the assembly recommendations given by PEUGEOT. The adaptation of a non recommended plug can destroy the engine. - Manually tighten the spark plug and washer... -
Page 15: Braking / Parking
Hydraulically controlled disk brake (Frequency : see maintenance manual) For your SAFETY, PEUGEOT recommends that you : - Monitor operation of your FRONT and REAR brakes. - Have adjustment and maintenance operations performed by a PEUGEOT dealer whenever action proves to be necessary - Use PEUGEOT original parts only. -
Page 16: Tyres
Appropriate valves are fitted in rims. When replacing them, use tyres and rims marked tubeless only. Ask your PEUGEOT dealer to repair or replace your Tubeless tyres. Danger Do not fit an inner tube inside a Tubeless tyre or put a Tubeless tyre on an ordinary rim (risk of bursting). -
Page 17: Removing / Refitting Front / Rear Wheel
Removing and refitting the wheels Important For your safety, PEUGEOT recommends that you : For these operations we advise you to contact a garage equipped with special tooling or a Peugeot dealer (agent). - When dismantling, be careful not to damage the pipework,... -
Page 18: Anti-Theft Device
Anti-theft device * - Removal of anti-theft device - Put the key into the lock, turn it , and pull the protective flap in order to remove the anti-theft device. - Locking the anti-theft device (the key must be in the lock). Unclip part from its housing, slide it along the cable, wrap the cable around a fixed point (metal post, 2-wheeler parking... -
Page 19: Transponder
All the so-called safety-related items are not available in After-Sales. However, if the rider can prove that he is the owner of the vehicle, our Peugeot dealer can order all the items of this system. A LED warning light blinks on the instrument panel to show that the system is actuated (dissua- sive effect). -
Page 20: Specifications
And do not forget that a PEUGEOT scooter should be maintained at a PEUGEOT dealer. Only your dealer knows it thoroughly, and has genuine PEUGEOT spare parts and the required special tools PEUGEOT to perform complete service and maintenace operations. - Page 21 recommande N° 11.739726.00...
- Page 22 Year of manufacture: ÿ2001-2002 VIN: ÿ(4-TAKTER) Capacities Fork oil per rod: ÿ150 CM3 Oil w/o filter: ÿSAE 10W/40 Oil incl. filter: ÿ1,25 LITER Brake fluid: ÿDOT 4 Final drive: ÿ120 CM3 SAE 80W/90 Fuel: 8,5Liter Coolant: ÿ1,6 LITER ÿ ÿ ÿ...
