AOC E2237FWH Brochure

e2237Fwh
Cabinet Color
Panel
Pixel Pitch
Display Area
Brightness
Contrast Ratio
Response Time
Viewing Angle
Scanning Frequency
Pixel Frequency
Maximum Resolution
Recommended Resolution
Supported Resolutions
Color
Signal Input
Digital Input
Connectors
Built-in Speakers
Power Source
Power Consumption
Plug & Play
EPA ENERGY STAR®
User Control
OSD Languages
Regulations
Other Features
Dimensions (WxHxD mm)
Dimensions (WxHxD inches)
Weight
Loading Qty w/pallet
UPC Code
Note: Specifications are subject to change without notice. *High-bandwidth Digital Content Protection: Enables viewing of High-Definition contents. Windows 7
and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.
A12/09
Piano-black Glossy Finish with Transparent Border
TFT Active Matrix LCD with WLED Backlight
22" Class, 16:9 Aspect Ratio
21.5" Viewable Image Size, Diagonal
0.248 x 0.248mm
476.6mm x 268.5mm
250 cd/m2 (typ)
2,000,000:1 (dynamic)
5ms (typical)
Horizontal: 170 Degrees (CR>10)
Vertical: 160 Degrees (CR>10)
Horizontal: 30K~80KHz
Vertical: 55~75 Hz
170Mhz
1920x1080x60Hz
1920x1080@60Hz
640x480 @60/67/72/75Hz, 800x600 @56/60/72/75Hz,
1024×768 @60/70/72/75Hz, 1280×1024 @60/75Hz,
1440x900 @60/75Hz, 1680x1050 @60Hz, 1920x1080 @60Hz
16.7M
Analog: 0.7Vp-p(standard), 75 OHM, Positive
DVI-D & HDMI with HDCP*
Analog RGB Signal: 15-pin D-sub Male
Digital Signal: 24-pin DVI-D, 18-pin HDMI
2W x 2
Universal 110~240VAC, 50/60Hz
On: <30 Watts, Standby: <1W, Off: <0.5W
VESA DDC2B
Yes
Menu/Enter, Eco/Up, Image Ratio/Left, Source/Down, Volume/Right
15 Languages including English, French and Spanish
cCSAus, FCC, CE, ROHS, EPEAT Silver
User Friendly Graphical OSD Menu, Touch Control, iCare Sensor, Slim
Profile (23mm), LED Desk Light, WLED Backlight
Monitor: 394x541x132, Carton: 605x124x464
Monitor: 15.5x21.3x5.2, Carton: 23.8x4.9x18.3
3.24KG, 7.1 lbs Net
5.5KG, 12.1 lbs Gross
40' Std = 1558 pcs., 20' = 760
685417027583
