6•
Place cardboard or hardboard in
front of range. Stand range back up
onto cardboard or hardboard.
Tip Over Hazard
A child or adult can tip the range and
be killed.
Connect anti-tip bracket to rear range
foot•
Reconnect the anti-tip bracket, if the
range is moved.
Failure to follow these instructions
can result in death or serious burns
to children and adults.
25" (63.5 cm) couetertop over
24" (61 cm) cabinet
J
I
cutout
"_ template
= Place the anti-tip bracket
template
on the floor in the cabinet
opening so that the left edge is against
cabinets and the top edge is against the
rear walt, molding or cabinet. If
countertop opening is deeper than 25
inches (63.5 cm), measure and mark a
distance 25 inches (63.5 cm) in from
front of countertop opening and align
template with mark (or subtract 25 inches
(63.5 cm) from countertop depth and add
the difference to the 2-1/4-inch (5.7 cm)
dimension).
25"(63.5
_'*"_,
1,,_,,_,,_,,_,,_,,_,_
Countettop
""
i
l!
_overhangs
:::
Ii
cabinet side.
i. J;; A=Difference
j J! between
i I i countertopdepth
H
j and 25"(1_3.5 c m).
--
Y_nU4ip
r
_bracket
template
slide-in cutout
shown
If countertop is not flush to the side of
cabinet opening, align the left side of
the template to allow for the countertop
overhang. Tape the range anti-tip
bracket template in place.
Contact a qualified floor covering
installer for the best procedure of
drilling mounting holes through your
type of floor covering.
Before moving, slide range onto
cardboard or hardboard.
==To mount
anti-tip bracket
to wood floor,
use the anti-tip
bracket template
to mark where to
drill mounting
holes. Use a drill
with a 1/8" (0.3
cm) drill bit to drill the two holes.
Remove template from floor.
To mount anti-tip bracket to concrete
or ceramic floor, use the anti-tip
bracket template to mark where to drill
mounting holes. Use a drill with a 3/16"
(0.48 cm) masonry drill bit to drill the
two holes. Remove template from floor.
Tap plastic anchors into mounting holes
in floor with hammer.
= Line up holes in
anti-tip bracket with holes in
\
.
floor. Use the screws
_,
t'
provided to fasten
_
"_k
anti-tip bracket to .< •
/_q ___
floor.
_"_ 4/'"-
"
NOTE: Anti-tip
bracket
must be mounted securely to
the sub floor. Depending on the
thickness of your flooring, longer screws
may be necessary to anchor the
bracket to the sub floor. Longer screws
are available from your local hardware
store.
0
• Move range close to cabinet
opening. Make electrical connection.
See "Electrical requirements" and
"Electrical connection," Panel B, for
details. "8888" should appear in the
clock display. Refer to Use and Care
Guide for information on electronic
controls.
1.
Remove
cardboard
or
hardboard from under range. Carefully
move range into final position.
2.
The
left rear leveling
leg must be
engaged in the
anti-tip bracket. If
leveling leg is not
properly engaged, remove and
reposition the anti-tip bracket to insure
that the leveling leg fits properly in the
anti-tip bracket.
J
A
1 ;.!.
Place rack in oven. Place
level on rack, first side to side; then front
to back. If the range is not level, pull
range forward until the rear leveling leg
is removed from the anti-tip bracket.
Adjust the leveling legs up or down.
Then slide range back into position.
Check that leveling leg is engaged in
anti-tip bracket.
NOTE: Oven must be level for
satisfactory baking conditions.
