UNVENTED (VENT-FREE)
PROPANE/LP GAS LOG HEATER
(Variable Manually-Controlled Models Also Designed-Certified as
OWNER'S OPERATION AND INSTALLATION MANUAL
CGG2618P,
CGG3324P(T), and
CGG3630P
Thermostat and
Variably-Controlled Models
WARNING: If the information in this
manual is not followed exactly, a fire or
explosion may result causing property
damage, personal injury, or loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do
not use any phone in your building.
•
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
•
If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be per-
formed by a qualified installer, ser-
vice agency, or the gas supplier.
WARNING: This is an unvented gas-fired heater. It uses air (oxygen) from the room in
which it is installed. Provisions for adequate combustion and ventilation air must be
provided. Refer to Air for Combustion and Ventilation section on page 4 of this manual.
This appliance may be installed in an aftermarket* manufactured (mobile) home, where not prohibited by
state or local codes.
* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
Vented Decorative Appliances)
Save this manual for future reference.
WARNING: Improper installation, adjust-
ment, alteration, service, or maintenance
can cause injury or property damage.
Refer to this manual for correct installa-
tion and operational procedures. For as-
sistance or additional information con-
sult a qualified installer, service agency,
or the gas supplier.
WARNING: This appliance is for instal-
lation only in a solid-fuel burning ma-
sonry or UL127 factory-built fireplace,
or in an approved ventless firebox. It is
design-certified for these installations
in accordance with ANS Z21.11.2. Ex-
ception: Do not install this appliance in
a factory-built fireplace that includes
instructions stating it has not been
tested or should not be used with
unvented gas logs.
®
Advertisement
Table of Contents
Related Manuals for Desa Comfort Glow CGG2618P
Summary of Contents for Desa Comfort Glow CGG2618P
- Page 1 UNVENTED (VENT-FREE) PROPANE/LP GAS LOG HEATER (Variable Manually-Controlled Models Also Designed-Certified as Vented Decorative Appliances) OWNER’S OPERATION AND INSTALLATION MANUAL CGG2618P, CGG3324P(T), and CGG3630P Thermostat and Variably-Controlled Models WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life.
-
