ViewSonic Q72B - Optiquest - 17" LCD Monitor Specification page 2

1 7 " L C D W I T H S U P E R - F A S T 5 M S V I D E O R E S P O N S E
ViewSonic Corporation's QMS & EMS have been
registered to ISO 9001 & ISO 14001, respectively,
by the British Standards Institution.
Sales: (888) 881-8781 • SalesInfo@ViewSonic.com • ViewSonic.com
*Excluding major U.S. holidays. **Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic
representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2008 ViewSonic Corporation. All rights reserved. [13823-00B-12/07] Q72b-1
For more product information, visit us on the web at ViewSonic.com
Q72b
LCD
VIDEO INPUT
COMPATIBILITY
CONNECTOR
POWER
CONTROLS
ERGONOMICS
OPERATING
CONDITIONS
DIMENSIONS
(W x H x D)
WEIGHT
REGULATIONS
RECYCLE/DISPOSAL
POWER MANAGEMENT
PACKAGE CONTENTS
WARRANTY
Type 17" color TFT active matrix LCD
Display Area 13.3" horizontal x 10.6" vertical; 17.0" diagonal
Optimum Resolution 1280x1024
Contrast Ratio 800:1 (typ)
Viewing Angles 160º horizontal, 160º vertical
Response Time 5ms (typ)
Light Source Long life, 50,000 hrs. (typ)
Brightness 300 cd/m
Panel Surface Anti-glare
Analog RGB analog (75 ohms, 0.7 Vp-p)
Frequency F h : 30~81kHz, F v : 56~75Hz
Sync H/V separated (TTL)
PC VGA up to 1280x1024 non-interlaced
Mac ** G3/G4/G5 up to 1280x1024
®
Analog 15-pin mini D-sub
Power 3-pin AC plug (CEE22)
Voltage AC 100–240V (universal), 50–60Hz (auto switch)
Consumption 36W (typ)
Basic Power, menu, – , +
OnView Auto setup, brightness, contrast, ViewMatch
®
adjust (cool, neutral warm, black level adjust (R, G, B),
user color), H. position, V. position, language, phase,
clock, recall, volume, OSD H. position, OSD V. postion
Tilt –5º/+20º
Temperature 41–104ºF (5–40ºC)
Humidity 20–85% (non-condensing)
Physical with stand 15.1" x 15.3" x 8.0" (383mm x 389mm x 203mm)
Physical without stand 16.0" x 11.0" x 2.26" (383mm x 342mm x 58mm)
Net with stand 8.8 lb. (4.0 kg)
Net without stand 8.1 lb. (3.7 kg)
Gross with stand 12.1 lb. (5.5 kg)
UL, cUL, FCC-B, NOM, , ENERGY STAR
CSA, RoHS, MPR II
The lamp in this product contains mercury. Please
dispose of in accordance with local, state or federal laws.
ENERGY STAR
LCD display, power cable, video cable, User Guide
One-year limited warrranty on parts, labor and backlight
(typ)
2
, CE, CB, TUV-S,
®
standards
®
color
®
