- Page 1 Q71-8 Color Monitor Q71B-8 User Guide Guide de l’utilisateur Guía del usuario Guia do usuário With Plug & Play ✘ 17" (16" Viewable Diagonal)
-
Page 2: Table Of Contents
Contents Product Registration..............2 For Your Records ..............2 Getting Started Package Contents ..............3 Precautions ................3 Quick Installation ..............4 Using the Monitor Setting the Timing Mode ............5 Adjusting the Screen Image ..........6 OSD Lock Settings ..............7 Main Menu Controls ..............8 Other Information Specifications ..............10 Troubleshooting..............11 Customer Support ...............12... -
Page 3: Product Registration
To meet your future needs, and to receive any additional product information as it becomes available, please register your product on the Internet at: www.viewsonic.com. The Wizard CD- ROM also provides an opportunity for you to print the registration form, which you may mail or fax to ViewSonic. -
Page 4: Getting Started
• Always handle your monitor with care ViewSonic. It is dangerous to continue when moving it. using the monitor. Optiquest Q71/B-8... -
Page 5: Quick Installation
The Wizard CD-ROM also provides an (INF and ICM files) opportunity for you to print the registration form which you may mail or fax to ViewSonic. (1) Insert the Wizard CD-ROM into your computer’s CD-ROM drive. NOTE: If your computer does not have a CD-ROM drive, see “Customer Support”... -
Page 6: Using The Monitor
Using the Monitor Setting the Timing Mode Setting the timing mode is important for maximizing the quality of the screen image and minimizing eye strain. The timing mode consists of the resolution (example 1024 x 768) and refresh rate (or vertical frequency; example 85 Hz). -
Page 7: Adjusting The Screen Image
Adjusting the Screen Image Use the buttons on the front control panel to display and adjust the OnView ® controls which display on the screen. The OnView controls are explained at the top of the next page and are defined in “Main Menu Controls” on page 8. Main Menu With OnView controls Front Control Panel... -
Page 8: Osd Lock Settings
OSD Lock Settings You have the option of using the On Screen Display (OSD) locking feature, OSD LOCK, to prevent unwanted changes to the current image settings. ▼ • OSD Lock: Press and hold the [1] and [ ] buttons on the face of the monitor for 10 seconds. -
Page 9: Main Menu Controls
Main Menu Controls Adjust the menu items shown below by using the up and down buttons. Control Explanation adjusts the difference between the image Contrast background (black level) and the foreground (white level). adjusts the background black level of the screen Brightness image. - Page 10 Control Explanation removes the build-up of magnetic fields that can Degauss cause irregular colors to appear around the edges of screen images. There are two ways to degauss the display: automatically by turning the monitor on, or manually by selecting the Degauss control from the menu. With Degauss selected from the menu, press button [2] to degauss the monitor manually.
-
Page 11: Other Information
Other Information Specifications Type 17” (16.0” viewable diagonal area), 90 deflection, 29.1 mm Neck Dot Pitch 0.23 mm horizontal, 0.13 mm vertical, and 0.27 mm Phosphor diagonal dot pitch Glass surface RGB medium/short persistence TM~46%, anti-glare, anti-reflection Input Signal Video RGB Analog (0.7/1.0Vp-p, 75 Ohms Sync : 30-70 kHz, f... -
Page 12: Troubleshooting
• Connect the monitor to another computer. • Select Degauss from the Main Menu. Do this only once. • If you have an older graphics card, contact ViewSonic ® Customer Support. Entire screen image rolls vertically •... -
Page 13: Customer Support
You will need the product serial number. NOTE: Country/ Web site T = Telephone Email Region F = FAX United States viewsonic.com/ T: (800) 688-6688 service.us@ support F: (909) 468-1202 viewsonic.com Canada viewsonic.com/ T: (800) 688-6688 support F: (909) 468-1202 service.ca@... -
Page 14: Cleaning The Monitor
Cleaning the Monitor • MAKE SURE THE MONITOR IS TURNED OFF. • NEVER SPRAY OR POUR ANY LIQUID DIRECTLY ONTO THE SCREEN OR CASE. To clean the screen: Wipe the screen with a clean, soft, lint-free cloth. This removes dust and other particles. -
Page 15: Limited Warranty
(c) your address, (d) a description of the problem, and (e) the serial number of the product. Take or ship the product freight prepaid in the original container to an authorized ViewSonic service center or ViewSonic. For additional information or the name of the nearest ViewSonic service center, contact ViewSonic. -
Page 16: Appendix
Appendix Safety Guidelines CAUTION: The socket-outlet should be installed near the equipment and be easily accessible. CAUTION: Use a power cable that is properly grounded. Always use the appropriate AC cord that is certified for the individual country. Some examples are listed below: USA.... -
Page 17: Compliance Information For U.s.a
Compliance Information for U.S.A. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 18 Optiquest Corporation...
