Jensen Heavy Duty JHD1620 Quick Manual

JHD1620 Quick Reference Guide
AUDIO MENU: With each
press of the button choose
from the following AUDIO
ADJUSTMENT options: BASS,
TREBLE, BALANCE (left to
right), & FADER (front to back).
Use the rotary encoder knob
to adjust desired mode.
POWER ON/OFF: Push
to turn power ON or OFF.
VOLUME: Rotate CLOCKWISE
to INCREASE (+) volume.
Rotate COUNTERCLOCKWISE
to DECREASE (-) volume.
AS/PS/FAV:
Press to SCAN
through currently stored
presets. Press & hold to
STORE strongest broad-
cast stations in your area.
VOLUME:
Rotate CLOCK-
WISE to INCREASE (+)
volume. Rotate COUNTER-
CLOCKWISE to DECREASE
(-) volume.
BAND:
FM1, FM2, FM3, AM1, or AM2 each
with 6 channel memory locations.
WB:
to WEATHERBAND.
www.asaelectronics.com
MODE: Continue to EQ/LOUD:
press to navigate one of the predefined bass
through the following and treble curves. Press &
modes: AM/FM, hold to turn loudness ON/OFF.
*SAT, *iPOD, & AUX.
Press to select preset group MUTE:
to MUTE audio.
Press & hold to listen
*Some features may not be available depending on installed factory options.
Press to choose MUTE: Press to
MUTE audio.
Press STATION STORE BUTTONS:
Press & hold to store current channel playing.
Momentarily press to recall stored channel.
NOTE: you can store up to 30 channels
(6 channels per band FM1, FM2, FM3, AM1, AM2).
PTY/CAT MENU:
Press & hold to access
SYSTEM MENU. Press
<< or >> to navigate
though menu items.
Press ENTER to adjust
desired menu item.
AUXILIARY INPUT: Insert stereo
connector from any portable audio player.
TUNE/SEEK:
tarily press >> to tune
UP in frequency or
<< to tune DOWN in
frequency. Press &
hold to SEEK to next
strongest station.
PTY/CAT MENU:
to enter program type
search. Press << or
>> to navigate through
program types. Press
PTY to select desired
program type.
www.JensenHeavyDuty.com
Momen-
Press
