Basic Operation

FRONT PANEL OVERVIEW

1
1. Standby Button
Activates and deactivates standby mode when the LX amplifier
is powered on with the rear panel power switch. The standby
button performs no function when the LX amplifier is powered
off with the rear panel power switch.
When the unit is on, pressing the standby button activates
standby mode and deactivates the LX amplifier. When the unit
is in standby, pressing the standby button deactivates standby
mode and activates the LX amplifier. The red standby button
LED will flash for approximately five seconds. Then, the blue
channel status LEDs will light. If the red standby button LED
2-2
2
flashes rapidly and the blue channel status LEDs do not light,
the incoming AC voltage is too low or the temperature of the
transformer is too high. Refer to Section 3 for troubleshooting
information.
Note:
• Power is still supplied to the LX amplifier when
standby mode is activated.
