Quad Band FM Transceiver
FT-8900R
Technical Supplement
©
2002 VERTEX STANDARD CO., LTD.
VOL

Introduction

This manual provides technical information necessary for servicing the FT-8900R Transceiver.
Servicing this equipment requires expertise in handling surface-mount chip components. Attempts by non-qualified
persons to service this equipment may result in permanent damage not covered by the warranty, and may be illegal in
some countries.
Two PCB layout diagrams are provided for each double-sided circuit board in the transceiver. Each side of thr board is
referred to by the type of the majority of components installed on that side ("leaded" or "chip-only"). In most cases one
side has only chip components, and the other has either a mixture of both chip and leaded components (trimmers, coils,
electrolytic capacitors, ICs, etc.), or leaded components only.
While we believe the technical information in this manual to be correct, Vertex Standard assumes no liability for damage
that may occur as a result of typographical or other errors that may be present. Your cooperation in pointing out any
inconsistencies in the technical information would be appreciated.
Specifications .................................................... 2
Exploded View & Miscellaneous Parts ........ 3
Connection Diagram ........................................ 4
Circuit Description ........................................... 5
Alignment ........................................................ 11
(EH008M90A)
1
2
SQL
3
LOW
V/M
HM
SCN
Contents
VERTEX STANDARD CO., LTD.
4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan
VERTEX STANDARD
US Headquarters
10900 Walker Street, Cypress, CA 90630, U.S.A.
International Division
8350 N.W. 52nd Terrace, Suite 201, Miami, FL 33166, U.S.A.
YAESU EUROPE B.V.
P.O. Box 75525, 1118 ZN Schiphol, The Netherlands
YAESU UK LTD.
Unit 12, Sun Valley Business Park, Winnall Close
Winchester, Hampshire, SO23 0LB, U.K.
VERTEX STANDARD HK LTD.
Unit 5, 20/F., Seaview Centre, 139-141 Hoi Bun Road,
Kwun Tong, Kowloon, Hong Kong
4
5
6
KEY2
SCN
HM
V/M
LOW
Board Unit (Schematics, Layouts & Parts)
Main Unit ..................................................................... 17
Panel Unit ..................................................................... 47
Panel-Sub Unit ............................................................. 53
Vr-L Unit ..................................................................... 55
Vr-R Unit ..................................................................... 56
PWR
SQL
VOL
1
