Serial Line - Heave sensors with a serial line output are

connected to a RS-232 port at the rear of the echo sounder's

processor unit.

Protocol - These options are only available when Serial Line

has been chosen. Use these to select serial line input format. The

echo sounder recognises one character based telegram

(Sounder/TSS1) and two binary telegrams (EM 1000 and EM

3000).

Data Input

The most recent input data is displayed in a list. With analogue

input the input voltage and the computed heave value are

displayed. With serial line input the telegram content is

displayed. This function is useful during installation and trouble

shooting. The current heave value is displayed in meters in the

lower left corner of the dialogue box.

Clear - This button clears the input data list.

Depth Output

This opens the Depth Output dialogue box.

RS-232

This button activates the RS-232 Setup dialogue box. This box

is used to define communication port, baud rate etc.
