Crest Audio NC-IPN - TECHNICAL Technical Data

INPUT PROCESSING MODULE
FOR CKS, CKV & CKX SERIES
POWER PROCESSING AMPLIFIERS
NC-IPN
Programmable Gain Input
Product Information
The NC-IPN Module fits in the Input Processing bay located on the rear
panel of Crest Audio CKS, CKV & CKX Series Power Processing
amplifiers. It includes programmable gain elements and provision for
optional input isolation transformers. In conjunction with NexSys
ware, the hand-held N-Coder or N-Coder/PC software, the NC-IPN can
also function as a precision attenuator in NexSys and non-NexSys con-
trolled applications.
Features:
• NexSys-compatible gain control
• Programmable precision attenuation via NexSys network, N-Coder or N-Coder/PC software.
• Balanced input barrier strip connectors
• Input isolation transformers optional
Internal Features:
• Jumper-selectable gain of X20 (26 dB), X40 (32 dB, factory setting), or constant sensitivity for full output at 0dBu (.775V) in.
N C - I P N c o n n e c t i o n s
Designed & manufactured in the USA by:
S 2
G MAY
SED
put
Model Output Power
Name
@70.7V
CKV 100
50W
CKV 200
100W
CKV 400
200W
CKV 800 400W
CKV 1600 800W
CKV 2400 1200W
Network
al
nd
per
+ – + –
NexSys Bus
Architects and Engineers Specifications - NC-IPN.
The module shall plug into Crest Audio CKS or CKV Power Processing amplifiers in the
Input Processing bay. The module shall be NexSys-compatible. Barrier strip input connec-
tions shall be provided which feed two electronically balanced inputs. Two removable-knob
gain pots shall be provided that control the level of each input.
• Removable gain pot knobs for security
• Simple setup, tamper-proof configuration
PC Lap-Top running
N-Coder/PC software
Crest Audio Inc.
100 Eisenhower Dr.
Paramus, New Jersey 07652 USA
Model
Output Power
Name @8 /Ch.
CKS 100 50W
CKS 200 100W
CKS 400 200W
CKS 800
400W
CKS 800-2 400W
CKS 1200-2 600W
CKS 1600-2 800W
Address Model
NC-NXS
Data
8
8
Hi Lo
An internal jumper selects between gains of X20 (26 dB), X40 (32 dB),
or constant sensitivity for full output at 0dBu (.775V) in. The standard
factory setting is for X40 (32dB). Individual channel attenuators are pro-
vided with removable knobs for extra security. The NC-IPN is program-
® soft-
mable via NexSys, the hand-held N-Coder or N-Coder/PC software.
(NexSys-compatible Power/Output and Network NC modules are
required for NexSys implementation.)
N-Coder
Crest Audio
Revision 1.03E
OR
N-Coder
Data
Port
Input A Input B
+ +
– –
Input Input
Signal A Signal B
An internal input sensitivity/voltage gain jumper shall be provided with selections of 0dBu,
X20 and X40. Programmable gain elements shall be provided that can be controlled/pro-
grammed either by NexSys via an NC-NXS module (if fitted), a hand-held N-Coder or N-
Coder/PC software. The module shall be designated the Crest Audio model NC-IPN.
Power
Processing
Modules
5
Level
4
6
A 3
7
2
8
1
9
0
10
Level 5
4
6
B
3
7
2
8
1
9
0
10
Model
NC-IPN
