Universal Remote Control AVEX Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading

Related Manuals for Universal Remote Control AVEX

Summary of Contents for Universal Remote Control AVEX

  • Page 2 Control’s AVEX™ R6 Pre--Programmed and Learning remote control. You now have the power to control your entire home entertainment system with one easy--to--use remote. The AVEX R6 can be used with thousands of audio/video components because of the extensive library of codes that have already been programmed into the remote.

  • Page 3: Table Of Contents

    Programming AVEX R6 Using Pre-Programmed Codes ……………………9 • Quick Set-Up Method ……………………………9 • Three-Digit Code Entry Method ………………10 • Auto-Search Method ……………………………12 Programming AVEX R6 Using the Learning Method ……………………………1 4 Finding a Component’s Set-Up Code Number …………………………………1 6 Programming Special Advanced Features •...
  • Page 4 Pre-Programmed Code Tables ..31 • CABLE/SAT………………………………………32 • TV ……………………………………………33-34 • DVR/VCR ……………………………………35-36 • DVD ………………………………………………37 • AUDIO……………………………………………38 • AUX ………………………………………………39 FAQs ………………………………………………40 Warranty ………………………………………41 Specifications …………………………………41 Page 4...

  • Page 5: Getting Started - Overview

    TV BUTTON Learning Capability The AVEX R6 has the ability to ‘learn’ functions from the original remote controls of other manufacturers, even if they are not in the Pre-programmed database. Page 5...

  • Page 6: Battery Installation

    LED will quickly blink three times when you press the Power [ON] button. Couch Mode The AVEX R6 is designed to automatically turn itself off if a button is pressed for more than 30 seconds. This prevents battery power from being depleted should the remote accidentally slip between the couch cushions.

  • Page 7: Special Advanced Features

    DVD, you would typically have to pick up the TV remote control to increase the volume. With the AVEX R6, you do not even have to press the TV component button. Once you program SimpleSound in your DVD mode, you will automatically have TV volume control in DVD mode.

  • Page 8: Keypad Layout & Button Functions

    Keypad Layout & Button Functions SYSTEM OFF POWER Designed to send Power Allows you to turn the On/Off commands for up selected component on to six components with and off. one button press. TV, CBL, GUIDE VCR, AUDIO, DVD, AUX Displays the Program Guide listings through Used to select the...

  • Page 9: Programming Avex R6 Using Pre-Programmed Codes

    10 major brands for each component. The Three-Digit Code Entry Method allows you to set-up the AVEX R6 using 3-digit codes for component brand names. It is also a fast and easy way to program the remote. The Auto-Search Method scans through all the brands in the remote control, one at a time.

  • Page 10: Three-Digit Code Entry Method

    STEP 2: Once you have located the 3-digit codes for each of the components that you wish to operate with your AVEX R6, write them ALL down on a piece of paper. It’s important that you write down all the codes listed for your brand because only one code is going to work with your component.
  • Page 11 STEP 5: Point the AVEX R6 toward the component (in this example the TV) and punch in the first 3-digit code that you wrote down for that specific compo- nent. Use the Number buttons 0~9 on the remote to punch in the code. The TV LED light will blink each time a number is pressed.

  • Page 12: Auto-Search Method

    TV, turn on your TV set. STEP 2: On the AVEX R6, press the Component button that you want to program (in this case the button that says TV) and the SELECT [SEL] button at the same time.
  • Page 13 STEP 4: Once you have found the right code number and the component has turned off, press the POWER button on the AVEX R6 remote to turn the component back on. Next test the VOLUME and CHANNEL buttons (or PLAY and STOP buttons for VCR and DVD) to make sure they all work.

  • Page 14: Learning Method

    STEP 3: Press any button on the AVEX R6 that you want to teach a command to. For example, if you want to teach the MUTE button on the AVEX R6 the...
  • Page 15 STEP 5: Once the AVEX R6 has learned all the buttons in the selected component mode, press and hold the Component button and ENTER [ENT] but- tons at the same time to save the learned functions. The component LED light will blink three times to confirm the programming.

  • Page 16: Finding A Component's Set-Up Code Number

    Finding a Component’s Set-up Code Number If you used the Auto--Search or Learning Methods to program a component, you may not know the code number you programmed. Here is a way for you to identify what that code number is, so you can make a note in the back of this Manual for future reference.

  • Page 17: Programming Special Advanced Features

    Advanced Features Programming Multi-Commands to Macro Buttons The AVEX R6 has six Macro buttons (POWER, SYS- TEM OFF, A, B, C, D) that are designed to store up to 20 commands in each button. Pressing any one of the Macro buttons will send out the series of commands that are stored in that particular button.
  • Page 18 IMPORTANT: You have 30 seconds to perform the next step while you are in programming mode. If you do not press a button within 30 seconds, the component LED light will turn off. The remote will exit the programming mode and you will have to start over.
  • Page 19 Notes regarding programming multi-com- mands to Macro buttons: • You can program up to 20 commands on each Macro button. • You can program delays in between commands by pressing the PAUSE button. Each press adds a one-half second delay. •...

  • Page 20: My Favorites' - Favorite Channels

    Programming ‘My Favorites’ - Favorite Channel Buttons In Cable mode, the A, B, C, D buttons are also designed to serve as dedicated Favorite Channel buttons. Each button will access one of your favorite channels with just one button press. Here’s how to program Favorite Channels: STEP 1: Press the CBL button to select the Cable mode.

  • Page 21: Simplesound™ Total System Volume Control

    SimpleSound™ Total System Volume Control SimpleSound is one of the most exciting features of the AVEX R6. It gives you total volume control over ALL the components in your system, even those that do not have built--in volume control, such as TIVO, DVD and VCR.
  • Page 22 STEP 2: Press the VOLUME UP button and then press either the TV or AUDIO component button that you want to use for volume. The Component LED light will blink three times to confirm that it is saved. This sets up three buttons (Volume Up, Volume Down and MUTE) as a group for that component.

  • Page 23: Channel Control 'Punch Through

    Channel Control ‘Punch Through’ This ‘punch through’ enables you to program the AVEX R6 so that either the Cable or TV Channel Controls (CHANNEL UP, DOWN, LAST, CHANNEL NUMBERS 0-9, +10 and ENTER) will also operate in other component modes on the remote control.

  • Page 24: Transport Control 'Punch Through

    Transport Control ‘Punch Through’ This ‘punch through’ enables you to program the AVEX R6 so that VCR or DVD Transport Controls (PLAY, STOP, FF, REW, PAUSE, SKIP and RECORD) will also operate in other component modes on the remote control.

  • Page 25: Osd (On-Screen Display) Control 'Punch Through

    OSD (On-Screen Display) Control ‘Punch Through’ This ‘punch through’ enables you to program the AVEX R6 so that CBL or DVD OSD Controls (MENU, GUIDE, INFO, EXIT, SEL and 4 Cursor Controls) will also operate in other component modes on the remote control.

  • Page 26: Erasing Commands-Overview

    Erasing Commands -- Overview You can erase a single learned command, all learned commands in each component mode, SimpleSound programming, MacroPower com- mands, or re--set the remote to original factory default settings. Erasing a Single Learned Command from One Component STEP 1: Press the component button where the learned command is stored and the ENTER buttons at the same time for two seconds until the compo-...

  • Page 27: Erasing All Learned Commands From One Component

    Erasing All Learned Commands from One Component This function allows you to erase all the learned commands from one component. For example, if you want to erase all learned commands on the TV component button because you bought a new TV, the process is very simple.

  • Page 28: Erasing Macropower & Other Macro Commands

    Erasing MacroPower & Other Macro Commands STEP 1: To erase MacroPower commands on the POWER ON or SYSTEM OFF button, press and hold either the POWER ON or SYSTEM OFF button and the MUTE button simultaneously for two seconds until the current status component LED turns on. IMPORTANT: If you don’t proceed to the next step within 30 seconds, the LED will turn off and exit set-up mode and you will need to start over.)

  • Page 29: Erasing Simplesound & Other 'Punch Through' Commands

    Erasing SimpleSound & Other ‘Punch Through’ Commands STEP 1: Press and hold the Component button you want to erase volume control from, such as DVD or VCR and the SELECT [SEL] button at the same time for two seconds until the Component LED light turns on.

  • Page 30: Factory Reset

    DVR/VCR component LED light blinks five times. All programming and set- up codes that you have entered into the remote will be erased and the AVEX R6 will return to the origi- nal factory default settings. Warning This procedure will erase all programming and set-up codes that you have entered into the remote.

  • Page 31: Pre-Programmed Code Tables

    Pre-Programmed Code Tables The AVEX R6 Pre-Programmed code library is classified by category (TV, VCR, DVD, etc.). Within each category, the code numbers are listed in rows by brand (Sony, Panasonic, B & K, etc.). Some brands have more than one three-digit code.

  • Page 32: Cable/Sat

    CABLE/SAT Brand Code Numbers ECHOSTAR CABLE Boxes 004 042 EXPRESSVU ADELPHIA 001 110 ADVANCED NEWHOUSE 001 GENERAL INSTRUMENT 148 ALTRIO AMERICAST HITACHI ARMSTONG AT&T BROADBAND HUGHES AT&T IPTV ATLANTIC BROADBAND 001 110 BELL SOUTH MITSUBISHI BLUE RIDGE 001 110 NEXT LEVEL BRESNAN PANASONIC BRIGHT HOUSE...
  • Page 33 Brand Code Numbers ABEX ADMIRAL 072 251 333 GIBRALTER 116 073 ADVENT GOLDSTAR 113 116 102 004 106 112 ADVENTURA GRUNPY 028 043 AIKO HAIER ALERON HALL MARK AKAI 116 146 248 281 404 405 HANNSPREE A MARK HARLEY DAVIDSON AMERICA ACTION HARSPER AMPRO...
  • Page 34 Brand Code Numbers NUVISION TELERENT OLEVIA TERA ONKING ONWA TNCI OPTIMUS TOSHIBA 138 030 007 040 258 325 OPTONICA 019 251 TRUTECH OPTOMA ORION UNIVERSAL 008 009 PANASONIC 080 034 056 164 208 583 VICTOR REVOLUTION HD VIDEO CONCEPTS PHILCO 116 003 059 060 164 363 024 056 VIDIKRON 174 164 188...

  • Page 35: Dvr/Vcr

    DVR/VCR Brand Code Numbers PULSAR VCRs ADMIRAL RADIO SHACK ADVENTURA RADIX AIKO RANDEX AIWA 144 147 145 013 034 102 AKAI REALISTIC 003 008 010 145 034 102 053 101 AMERICA ACTION RICO AMPRO SAMSUNG 102 112 144 147 ANAM SANKY AUDIO DYNAMICS 012 043...
  • Page 36 DVR/VCR Brand Code Numbers REPLAY NETWORKS 775 SONY 804 805 TIVO TOSHIBA Page 36...

  • Page 37: Dvd

    Brand Code Numbers AIWA TECHNICS AKAI TECHWOOD ALLEGRO THETA DIGITAL APEX DIGITAL 087 111 115 TOSHIBA 035 130 141 164 188 273 BLAUPUNKT URBAN CONCEPTS BROKSONIC VENTURER CINEVISION YAMAHA 138 089 001 197 COBY ZENITH 057 091 CYBERHOME DENON 138 173 DVD Recorders DURABRAND GO VIDEO...

  • Page 38: Audio

    AUDIO Brand Code Numbers ADCOM 082 092 225 161 269 356 SUNFIRE 344 345 182 AIWA 170 018 104 202 203 213 211 188 TEAC 005 019 049 040 212 217 AKAI TECHNICS 122 176 193 219 178 177 200 257 ANTHEM 335 337 ARCAM...

  • Page 39: Aux

    Brand Code Numbers iPod Controls APPLE / iPod 901 912 BOSE GRIFFIN KENSINGTON TEN TECHNOLOGY MEDIA PC Controls DELL GATEWAY KEYSPAN SONY TOSHIBA WINBOOK GAMING SYSTEM Controls MICROSOFT / XBOX 908 607 SONY / PS2 LIGHTING Controls LITE-TOUCH 708 757 LUTRON 658 659 577 X-10...

  • Page 40: Faqs

    Frequently Asked Questions If the batteries run out, will I lose my settings? No. The AVEX R6 stores all of your settings in non- volatile FLASH memory. You could remove the bat- teries for months, replace them at your convenience, and the AVEX R6 would still remember your settings.

  • Page 41: Warranty

    (1) year and as set forth below. Universal Remote Control will, at its sole option, repair the product using new or comparable rebuilt parts, or exchange the product for a comparable new or rebuilt product.
  • Page 42 Information To The User This equipment has been tested and found to com- ply with the limits for a Class B digital device, pur- suant to part 15 of the FCC Rules. These limits are designed to provide reasonable pro- tection against harmful interference in a residential installation.
  • Page 43 MEMO Page 44...
  • Page 44 UNIVERSAL UNIVERSAL remote control remote control The Pioneer in Control Technology 500 Mamaroneck Avenue, Harrison, NY 10528 Phone: (914) 835-4484 Fax: (914) 835-4532 www.universalremote.com OCE-0058A Rev03...

This manual is also suitable for:

Avex r6Urc-r6
