Delta Electronics Series Q48DR Datasheet

Delphi Series Q48DR, 87W-100W, Quarter Brick
Dual Output, DC/DC Power Modules:
48V in, 1.8V and 3.3V, 15A out each channel
The Delphi Series Q48DR Quarter Brick Dual, 48V input, dual output,
isolated DC/DC converters are latest offering from one of the world's
largest power supply manufacturers — Delta Electronics, Inc. This
product family provides up to 100 watts of power or 15A of output current
(each channel simultaneously) in an industry standard footprint. Both
output channels can be used independently of each other with option to
trim each channel either in the same direction or in reversion direction.
With creative design technology and optimized circuit, these converters
possess outstanding electrical and thermal performance, as well as
extremely high reliability under highly stressful operating conditions. All
the models are fully protected from abnormal input/output voltage,
current, and temperature conditions. The Delphi Series converters meet
all safety requirements with basic insulation.
DATASHEET
DS_Q48DR1R833_03162007
OPTIONS
1
FEATURES
High Efficiency: 88%@ 1.8V/15A, 3.3V/15A
Standard footprint:57.9mmx36.8mmx8.5mm
(2.28"×1.45"×0.33")
Industry standard pin out
2:1 input voltage range
Fixed frequency operation
Fully protected: OTP, OCP, OVP, UVLO
No minimum load required
1500 V isolation and basic insulation
Two independent power train and separate
trim for each output
ISO 9001, TL 9000, ISO 14001, QS9000,
OHSAS18001 certified manufacturing
facility
UL/cUL 60950 (US & Canada) Recognized,
and TUV (EN60950) Certified
CE mark meets 73/23/EEC and 93/68/EEC
directives
Optional second trim pin for
independent trim of the two outputs
Positive On/Off logic
Short pin lengths available
APPLICATIONS
Telecom/DataCom
Wireless Networks
Optical Network Equipment
Server and Data Storage
Industrial/Test Equipment
