Delphi Series E36SR, 75W Eighth Brick Family
DC/DC Power Modules: 18~75V in, 5V/15A out
The Delphi Series E36SR Eighth Brick, 18~75V input, single output,
isolated DC/DC converter is the latest offering from a world leader in
power systems technology and manufacturing — Delta Electronics, Inc.
This product family operates from an extremely wide 18~75V input range
and provides up to 75 watts of power in an industry standard eighth brick
footprint and pinout. With creative design technology and optimization of
component placement, these converters possess outstanding electrical
and thermal performances, as well as extremely high reliability under
highly stressful operating conditions. All models are fully protected from
abnormal input/output voltage, current, and temperature conditions. The
Delphi Series converters meet all safety requirements with basic
insulation.
DATASHEET
DS_E36SR05015_01042008
FEATURES
High efficiency: 89% @ 5V/ 15A
Size: 58.4mm x 22.8mm x 9.2mm
(2.30"x0.90"x0.36")
Industry standard pin out
18~75V extremely wide 4:1 input range
Fixed frequency operation
Input UVLO, Output OCP, OVP and OTP
2250V isolation
Basic insulation
No minimum load required
SMD and through-hole versions
ISO 9001, TL 9000, ISO 14001, QS 9000,
OHSAS 18001 certified manufacturing
facility
UL/cUL 60950-1 (US & Canada)
Recognized, and TUV (EN60950-1)
Certified
CE mark meets 73/23/EEC and 93/68/EEC
directives.
OPTIONS
Positive On/Off logic
Short pin lengths available
SMD pin
APPLICATIONS
Telecom / Datacom
Wireless Networks
Optical Network Equipment
Server and Data Storage
Industrial / Testing Equipment
Advertisement
Table of Contents
Related Manuals for Delta Electronics Series E36SR
Summary of Contents for Delta Electronics Series E36SR
- Page 1 Delphi Series E36SR, 75W Eighth Brick Family DC/DC Power Modules: 18~75V in, 5V/15A out The Delphi Series E36SR Eighth Brick, 18~75V input, single output, isolated DC/DC converter is the latest offering from a world leader in power systems technology and manufacturing — Delta Electronics, Inc.
-
Page 2: Technical Specifications
TECHNICAL SPECIFICATIONS =25°C, airflow rate=300 LFM, V =48Vdc, nominal Vout unless otherwise noted.) PARAMETER ABSOLUTE MAXIMUM RATINGS Input Voltage Continuous Transient (100ms) Operating Temperature Storage Temperature Input/Output Isolation Voltage INPUT CHARACTERISTICS Operating Input Voltage Input Under-Voltage Lockout Turn-On Voltage Threshold Turn-Off Voltage Threshold Lockout Hysteresis Voltage Maximum Input Current... - Page 3 ELECTRICAL CHARACTERISTICS CURVES Figure 1: Efficiency vs. load current for minimum, nominal, and maximum input voltage at 25°C. Figure 3: Typical full load input characteristics at room temperature. DS_E36SR05015_01042008 Figure 2: Power dissipation vs. load current for minimum, nominal, and maximum input voltage at 25°C.
- Page 4 ELECTRICAL CHARACTERISTICS CURVES Figure 4: Turn-on transient at full rated load current (CC mode) (5ms/div). Vin=48V.Top Trace: Vout, 2V/div; Bottom Trace: ON/OFF input, 5V/div. Figure 6: Turn-on transient at full rated load current (CC mode) (5ms/div). Vin=48V.Top Trace: Vout, 2V/div; Bottom Trace: input voltage, 20V/div.
- Page 5 ELECTRICAL CHARACTERISTICS CURVES Figure 8: Output voltage response to step-change in load current (50%-25% of Io, max; di/dt = 0.1A/µs). Load cap: 10µF, tantalum capacitor and 1µF ceramic capacitor. Top Trace: Vout (100mV/div, 200us/div), Bottom Trace: I out (5A/div). Figure 10: Test set-up diagram showing measurement points for Input Terminal Ripple Current and Input Reflected Ripple Current.
- Page 6 ELECTRICAL CHARACTERISTICS CURVES Figure 12: Input reflected ripple current, i source inductor at 48Vin and 15A output current (20 mA/div, 2us/div). Figure 14: Output voltage ripple at 48Vin and rated load current (Io=15A)(20 mV/div, 2us/div) Load capacitance: 1µF ceramic capacitor and 10µF tantalum capacitor.
-
Page 7: Design Considerations
DESIGN CONSIDERATIONS Input Source Impedance The impedance of the input source connecting to the DC/DC power modules will interact with the modules and affect the stability. A low ac-impedance input source is recommended. If the source inductance is more than a few μH, we advise adding a 10 to 100 μF electrolytic capacitor (ESR <... -
Page 8: Features Descriptions
FEATURES DESCRIPTIONS Over-Current Protection The modules include an internal output over-current protection circuit, which will endure current limiting for an unlimited duration during output overload. If the output current exceeds the OCP set point, the modules will automatically shut down (hiccup mode). The modules will try to restart after shutdown. - Page 9 FEATURES DESCRIPTIONS (CON.) Output Voltage Adjustment (TRIM) To increase or decrease the output voltage set point, the modules may be connected with an external resistor between the TRIM pin and either the SENSE(+) or SENSE(-). The TRIM pin should be left open if this feature is not used.
-
Page 10: Thermal Considerations
THERMAL CONSIDERATIONS Thermal management is an important part of the system design. To ensure proper, reliable operation, sufficient cooling of the power module is needed over the entire temperature range of the module. Convection cooling is usually the dominant mode of heat transfer. Hence, the choice of equipment to characterize the thermal performance of the power module is a wind tunnel. - Page 11 PICK AND PLACE LOCATION SURFACE-MOUNT TAPE & REEL RECOMMENDED PAD LAYOUT (SMD) DS_E36SR05015_01042008...
- Page 12 LEADED (Sn/Pb) PROCESS RECOMMEND TEMP. PROFILE Pre-heat temp. 140~180°C 60~120 sec. Ramp-up temp. 0.5~3.0°C /sec. Time ( sec. ) Note: The temperature refers to the pin of E36SR, measured on the pin +Vout joint. LEAD FREE (SAC) PROCESS RECOMMEND TEMP. PROFILE Temp Peak Temp.
-
Page 13: Mechanical Drawing
MECHANICAL DRAWING Surface-mount module Pin No. Name +Vin ON/OFF -Vin -Vout -SENSE TRIM +SENSE +Vout DS_E36SR05015_01042008 Through-hole module Function Positive input voltage Remote ON/OFF Negative input voltage Negative output voltage Negative remote sense Output voltage trim Positive remote sense Positive output voltage... - Page 14 MECHANICAL DRAWING (WITH HEATSPREADER) THROUGH-HOLE MODULE DS_E36SR05015_01042008...
-
Page 15: Part Numbering System
PART NUMBERING SYSTEM Type of Input Number of Product Product Voltage Outputs Series E- Eighth 36-18~75V S- Single R- Regular Brick MODEL LIST MODEL NAME E36SR3R320NRFA 18V~75V E36SR05015NRFA 18V~75V Default remote on/off logic is negative and pin length is 0.170” For different remote on/off logic and pin length, please refer to part numbering system above or contact your local sales office CONTACT:...
