Delta Electronics Delphi S36SE Specification Sheet

Delphi S36SE, 17W 1x1 Brick Series
DC/DC Power Modules: 18~75V in, 5A out
The Delphi S36SE series, 1x1 sized, 18~75V input, single output,
isolated DC/DC converters are the latest offering from a world leader
in power systems technology and manufacturing ― Delta Electronics,
Inc. This product family is available in a surface mount or through-
hole package and provides up to 17 watts of power or 5A of output
current in a standard 1x1 form factor (1.10"x0.96"x0.33"). The pinout
is compatible with the industry standard 1x2 products. With creative
design technology and optimization of component placement, these
converters possess outstanding electrical and thermal performance,
as well as extremely high reliability under highly stressful operating
conditions. Typical efficiency of 12V/1.3A module is better than 87%
and all modules are fully protected from abnormal input/output
voltage, current and temperature conditions.
DATABRIEF
DB_S36SE_07292008
FEATURES
High efficiency: 87% @12V/1.3A
Industry standard 1x2 pinout
Size: 27.9x24.4x8.7mm (1.10"x0.96"x0.34")
SMT and Through-hole versions
Fixed frequency operation
4:1 input voltage range
Input UVLO,
Output OCP, OVP and OTP
Output voltage trim ±10%
2250V isolation and basic insulation
No minimum load required
ISO 9001, TL 9000, ISO 14001, QS 9000,
OHSAS18001 certified manufacturing facility
UL/cUL 60950-1 (US & Canada) Recognized,
and TUV (EN60950-1) certified.
CE mark meets 73/23/EEC and 93/68/EEC
directives
OPTIONS
SMD module available
Positive or no On/Off
Output OVP and OCP mode, auto-
restart (default) or latch
APPLICATIONS
Optical Transport
Data Networking
Communications, including Wireless and
traditional Telecom
Servers
