FUTABA FP-8SGAP Instruction Manual page 5

RECEIVER FP-R118GP
•The receiver of this set is a miniature PCM re-
ceiver in which the highest reliability has been
pursued. It is the first R/C receiver in the world
to incorporate the newest computer technology.
• Miniature PCM receiver with high speed single
microprocessor. Resistance to adjacent band and
spark noise interference has been increased by
one full order of magnitude.
• Microprocessor servo hold function eliminates
erroneous operation when a "dead point" area
is entered.
• Microprocessor provides fail safe and battery fail
safe functions for greater safety.
• Error lamp display allows checking of the receiv-
er operating state.
SERVO FP-S130
•Small, double ball bearing, water-tight & dust-
tight servo. High output torque 55.6 oz-in (5kg-
cm), high-speed .24sec/60 .
• New indirect drive
vibration and shock
precision.
• Futaba low-power custom 1C provides high start-
ing torque, narrow dead band, and excellent
trackability.
• Fiberglass reinforced PBT (polybutylene ter-
ephthalate) molded servo case is mechanically
strong and invulnerable to glow fuel.
SERVO FP-S130G
•Small retractable landing gear servo with high
class 5-pole micromotor. High output torque
4.7kg-cm, high-speed 0.34sec/60°, waterproof
type.
•Since forward/reverse operation is controlled by
the pulse width of the signal generated by turn-
ing the transmitter snap switch on and off, the
motor stops at the end of its throw in either
direction.
• Unlike other proportional servos, motor drive
current does not flow when the servo is stopped
even if a load is applied. Thus current drain is
extremely low.
potentiometer improves
resistance and neutral
• DC-DC converter in the power supply improves
low-voltage operation characteristics.
• High sensitivity design with RF amplifier.
• Ultra narrow-band ceramic filter and PCM sys-
tem are invulnerable to adjacent band inter-
ference.
• Gold plated connector pins eliminate poor con-
tact. Polarized housing
against shock and vibration.
• DSC circuit. Each servo can be controlled from
the transmitter without turning on the transmit-
ter by connecting the transmitter directly to the
C terminal.
• Strong polyacetal resin ultra-precision servo gear
features smooth operation, positive neutral, and
very little backlash.
• Fiberglass reinforced epoxy resin PC board with
thru-the-hole plating improves servo amp vibra-
tion and shock resistance.
•Thick gold plated connector pins ensure positive
contact and improve reliability against shock and
vibration. The connector housing is polarized to
prevent reverse insertion.
• Six special adjustable splined horns.
• Fiberglass reinforced PBT (polybutylene ter-
ephthalate) injection molded servo case is me-
chanically strong and invulnerable to glow fuel.
•Strong polyacetal resin ultra-precision servo gear
features smooth operation, positive neutral, and
very little backlash.
• Fiberglass reinforced epoxy resin PC board with
thru-the-hole plating improves servo amp vibra-
tion and shock resistance.
•Thick gold plated connector pins ensure positive
contact and improve reliability against shock and
vibration. The connector housing is polarized to
prevent reverse insertion.
improves reliability
