- Page 1 COLOR TV RECEIVER OWNER'S MANUAL The Owner`s Manual for the Follow Models: Please READ this manual carefully 21FA11,21FA11-AM,29FA1, 25FA18 before operating the unit, and keep 29FA18,29FA11-AM,29FA12-AM it for future reference.
-
Page 2: Table Of Contents
*Please read this manual carefully before using your television and keep this manual in a good place for future reference. *To achieve the best performance of your television, read this User's Manual carefully and properly store it for future reference. *Information of screen displays and figures in the User's Manual may vary due to technical innovations or different models. -
Page 3: Warning And Cautions
Warning and cautions 1. When you clean the TV set, please Do not place the TV set near rain or pull out the power plug from AC outlet. moisture as it may cause an electric Don't clean the cabinet and the shock, or the TV set to catch fire. -
Page 4: Installation
Installation Aerial connection For an optimum high quality picture, it is strongly advised that the TV set connect to an external aerial(s) using high quality coax cable. When connecting to HiFi VCRs, satellite (or cable) set top boxes, that the AV terminals are used to allow the stereo sound to be transferred. -
Page 5: Function Buttons And External Sockets
Function buttons and external sockets Front and side panel of the TV set 21FA11/21FA11-AM Infrared receiver TV/AV MENU Power indicator MENU TV/Video Power switch (input selector Channel position down/ Volume down/ 29FA1 Infrared receiver TV/AV MENU VOL- VOL+ Power switch TV/Video MENU Channel position... - Page 6 Function buttons and external sockets 29FA18 25FA18 Audio Input AUDIO terminal VIDEO Video Input terminal Back panel 21FA11/21FA11-AM/29FA18/25FA18 Video C Input terminal Antenna Input socket Video Y Input terminal Video C Input terminal Audio Output terminal Video Output terminal S-VIDEO Audio Input terminal S-VIDEO input terminal Video Input terminal...
-
Page 7: Buttons On The Remote Control
Buttons on the remote control Buttons and Descriptions MUTE POWER Mute Button CALL SWAP Press to conceal the sound of programs. Stand by Button TV/AV -/-- Screen Display Button Swap function Button TV and AV Exchange Button To exchanger between TV and other available video inputs Digital selector SCAN... -
Page 8: Switching On/Off The Tv Set
Switching on/ off the TV set In the following, the methods of using power switch and remote controller to switch on/off power supply for the TV set will be explained. Switching on/ off the TV set Switching on/ off the TV set 1 Please press the power switch to switch on AC power supply and the power indicator will light. -
Page 9: Watching Tv Program
Watching TV You can watch TV program in a preset channel. Watching TV program How to select TV program Select the desired program 1 Using "Program number" buttons Directly enter the channel number with the numeric keypad on the remote control. To select channel numbers from 10 ~ 99 press [-/--] button and enter the two digit channel number To select channel numbers from 100 ~ 218 press [-/--] button... -
Page 10: Program Swap And Auto Scan Functions
Watching TV continued Swap function enables quick swap to the last watched program. Auto scan function enables automatic successive scanning of all the programs in memory with "OFF" skip status (each channel will last about 2 seconds). Program swap and auto scan functions Program swap Suppose the channel number you used just now is 8 and the... -
Page 11: Searching Channel
Searching channel This TV set has three methods to set the channels, which are respectively full automatic, semi automatic and manual fine tune. In this section, how to use the remote control to set the channel is explained. You can also use the buttons on the TV set to set channel. Full automatic mode 1 Press the TUNE menu button , TUNE... -
Page 12: Semi-Automatic Search
Searching channel Continued Semi-automatic search Semi-automatic search 1 Press the CH+/- buttons or PROGRAM NUMBER 0-9 AUTO buttons to choose desired channels I.E. channel 1 TUNE 2 Press the TUNE menu button , till the TUNING menu shown on the right display on the screen. Press the CH+/- buttons to TUNE... -
Page 13: Manual Fine Tune
Searching channel Continued Manual fine tune Manual fine tune If the picture and/or sound are poor, try using the FINE Do not use this feature unless TUNE feature. reception is poor. 1 Press the CH+/- buttons or AUTO PROGRAM NUMBER 0-9 button to choose desired MENU channels I.E. -
Page 14: Program Skip
Searching channel Continued Program skip Program skip The Program skip feature enables you to skip/hide programs that you do not wish to be displayed when using the CH+/- buttons. These channels will still be displayed by directly using the channel number buttons on the remote control. -
Page 15: Convenient Picture And Sound Control Functions
Convenient picture and sound control functions Multiple picture modes How to select picture modes You can quickly select the desired picture mode from four preset modes and one customized mode. STANDARD P.STD Press the P.STD button to select the RICH desired picture quality. -
Page 16: Black Stretch And Noise Reduce
Convenient picture and sound control functions Continued Black Stretch-(Automatically Increases the Contrast Rage) Noise Reduce - (Picture Noise & Grain Reduction Circuit. Only use on poor reception.) Black stretch and noise reduce How to select BLACK STRETCH PICTURE PICTURE 1 Press the menu button , till the PICTURE... -
Page 17: Mute Function
Convenient picture and sound control functions Continued Mute function Sound mute 1 Press the MUTE button on the MUTE remote control and "MUTE" type face will display on the lower part of the screen. At this time, the MUTE sound of the TV set is turned off. 2 If you want to recover the sound, press the MUTE button again or directly press the VOL-/+ buttons. -
Page 18: Time Functions
Time functions Clock setting and timer on/off functions Clock setting The clock will only work if the TV set if left turned on or in standby. When the set is disconnect from the power supply or is turned off by the main power on TIME the front panel, the clock loses power and will need to be reset when the power is reconnected. -
Page 19: Sleep Timer And Program Preset
Time functions Continued Sleep timer and program preset Sleep timer The TV set have 18 sections option for sleep timer function (each section has a time interval of 10 minutes) (See right TIME chart): 1 Press the TIME menu button, and the TIME menu display on the screen. -
Page 20: Setup Function
Set up function Screen saver and childlock functions How to start screen saver function When the BACKGROUD function is ON, the screen will turn automatically as shown "NO NO SIGNAL SIGNAL" of moving . 1 Press the FUNCTION menu FUNCTION button till the FUNCTION menu... -
Page 21: Avl And Calendar Functions
Set up function Continued AVL and calendar functions AVL function Automatic Volume Limit control reduces effect of large volume changes such as when the ads come on. 1 Press the FUNCTION menu FUNCTION button till the FUNCTION menu FUNCTION shown on the right display ENGLISH on the screen. -
Page 22: Fade And Select Language
Set up function Continued Fade and select a language Fade The FADE control allows time for the picture tube to warm up and gently turned on, which can help prolong the life of the picture tube. 1 Press the FUNCTION menu FUNCTION button till the FUNCTION... -
Page 23: Position Exchange Function
Position exchange functions Exchange Exchange This feature enables TV programs that may be on a wrong TV channel number to be swapped/exchanged. This feature is very useful when Automatic Search Tuning has been used, to reallocate the found programs to the correct channel numbers. 1 Press the MENU button, till the EXCHANGE menu display on MENU... -
Page 24: Connection To The External Audio And Video Equipment
Connecting the TV set to the other video and audio equipment Connecting to the other video and audio equipment You can connect the DVD,VCR and stereo system to the output to enjoy a higher quality of picture and sound effect. an additional TV DVD, VCD or other units Video output... -
Page 25: Troubleshooting Guide
Troubleshooting guide To assist in location possible faults use help guide below BREAKDOWN PHENOMENON CHECKING PICTURE SOUND The aerial direction and connection Picture with snow Noise This is called ghosting which can be minimized with an outside aerial, and good quality cable and terminations. -
Page 26: Specifications
