Haier 21FA12-AM Owner's Manual
Colour tv receiver
Hide thumbs
Also See for 21FA12-AM:
- Operating instructions manual (10 pages) ,
- Owner's manual (32 pages) ,
- Owner's manual (32 pages)
Related Manuals for Haier 21FA12-AM
Summary of Contents for Haier 21FA12-AM
- Page 1 COLOUR TV RECEIVER OWNER'S MANUAL The Owner's Manual for the Follow Models: Please read this manual carefully 21FA12-AM,29FA12-AM,29FA11-AM before operating the unit, and keep it for future reference.
-
Page 2: Table Of Contents
CONTENTS Ä ¿ Â ¼ Before Operation ² Ù × ÷ Ö ® Ç ° Warning and Cautions Installation Antenna connection Preparation for the remote control Position of keys and plug-ins Front and side panel Back panel Using the remote control Basic Operation »... -
Page 3: Warning And Cautions
Warning and Cautions 4. To prevent the TV set from firing 1. When you clean the TV set, please pull out the power plug from AC outlet. and electric shock, don't expose the Don't clean the cabinet and the TV set to rain or moisture. screen with benzene, petrol and other chemicals. -
Page 4: Installation
Installation Antenna connection Ì ì Ï ß µ Ä ° ² × ° ¡ ¡ Generally speaking, to enjoy a clearer picture, we recommend that you use a CATV system or an outdoor antenna .In different places, the suitable antenna type and position are different. -
Page 5: Position Of Keys And Plug-Ins
Position of Keys and Plug-ins Front and side panel Front A12: A11: TV/AV VOL- VOL+CH- CH+MENU 1.TV/AV :TV/AV/SVHS/DVD selection 2.VOL-:Decrease sound 3.VOL+:Increase sound 4.CH-:Select next lower channel 5.CH+:Select next higher channel Side 6.Menu:Access/Exit main menu 7.Power Indicator VIDEO ensor Windows 9.Power:Power on/off AUDIO-L AUDIO-R... -
Page 6: Using The Remote Control
Using the Remote Control Buttons and Descriptions Mute Button Press to conceal the sound of programs. POWER MUTE Screen Display Button TV and AV Exchange Button CALL SWAP To exchange between TV and other available video inputs TV/AV Direct-digit Choosing Button Directly select channel numbers Program Scan Button Picture Mode Select Button... -
Page 7: Power On And Power Off
½ Ó Í ¨ / ¹ Ø ± Õ µ ç Ô ´ Power On and Power Off In the following, they are the methods on how to power on/off the TV set with the switches on the TV and on the remote control. Power on/ off the TV set 1. -
Page 8: Viewing Tv Programs
Viewing TV Programs The channels amount to 218 . Viewing TV programs How to select the TV program Use the direct-digit choosing button Press the button from 0-9 to select a one digit channel. MENU VOL+ VOL- If you want to select a two-digit channel, press the Digit Select button and change it into two- digit mode, then press the number of the channel. -
Page 9: Program Swap And Auto Program Scan
Viewing TV Programs(continued) Swap function enables quick swap to the last watched program. Auto scan function enables automatic successive scanning of all the programs in memory with "OFF" skip status (each channel will last about 2 seconds). Program swap and a uto program scan Swap Program swap... -
Page 10: Tuning
Tunning There are three ways of searching: auto search, search and fine tune. You may operate it either on the TV or on the remote control. Here is mainly about the remote control. Automatic search Automatic search TUNE TUNE Press the TUNE menu button ,and the TUNING TUNING menu shown on the right display on the screen. -
Page 11: Manual Search
Tuning functions Manual search Manual search 1. Press CH+/- button or the Direct-digit Choosing button to select a channel directly(take channel 1 for example). Press the TUNE menu button, and the TUNE TUNE menu display on the screen. Press the CH+/- buttons select SEARCH MENU VOL- VOL+... -
Page 12: Fine Tune
Tuning functions Fine tune FINE TUNE If the picture or sound is poor,try the FINE TUNE feature .Do not use this feature unless reception is poor. MENU VOL- VOL+ Press the CH+/-buttons or PROGRAM NUMBER (0-9)button to choose desired channels(I.E.channel 1) 2. -
Page 13: Program Skip
Tuning functions Program skip Program skip The Program skip feature enables you to skip/hide programs that you do not wish to be displayed when using the CH+/- buttons. MENU VOL+ VOL- 1 Press the CH+/- buttons or PROGRAM NUMBER 0-9 button to choose desired channels I.E. -
Page 14: Convenient Picture Control Functions
Convenient picture control functions Multiple picture modes ¶ à Ö Ö Í ¼ Ï ñ Ä £ Ê ½ How to select picture modes You can quickly select the desired picture mode STANDARD from four preset modes and one customized mode. - Page 15 · ½ ± ã µ Ä Í ¼ Ï ñ £ ¨ ½ Ó É Ï Ò ³ £ © Convenient picture control functions BALCK STRETCH and PICTURE BOOST How to select PICTURE BOOST PICTURE 1.Press PICTURE menu button,and MENU VOL+ VOL- the PICTURE menu appears on the screen.
-
Page 16: Time Functions
Time functions This TV set provides you with three timer functions such as timer on, timer off and sleep off. Clock setting TIME We can set the CLOCK as follows: MENU VOL+ VOL- 1. Press the TIME menu button, and the TIME menu display on the screen. -
Page 17: Remind Prog Function
Time functions Continued REMIND PROG function REMIND PROG function TIME Program remind timer, that displays an on-screen reminder prompt, when a program on a different channel is due to MENU VOL+ VOL- start Press the TIME menu button to call up the TIME menu on the screen. -
Page 18: Avl Function
Set up function How to start screen saver & AVL function How to start screen saver function FUNCTION When the BACKGROUD functions ON, the screen MENU VOL+ VOL- will turnautomatically as shown "NO SIGNAL" of moving . 1.Press the FUNCTION menu button till the FUNCTION menushown on the right display on the screen. -
Page 19: Channel Exchange
Setting the other Function(continued) The function of channel exchange will enable you to exchange any two programs and you can conveniently adjust the order of the programs due to your own need. Channel exchange Channel exchange MENU VOL- VOL+ for example, to change between channel 6 and 9 EXCHANGE Press MENU button continuously until select... -
Page 20: Calendar Function
Setting the other Function(continued) function alender How to use the calendar function This TV set has been designed to store the calender from the year 1901-2099. 1. Press the MENU button ,till the CALENDAR menu appears on the screen. 2.Press CH+/- button to turn the YEAR/MONTH/DAY , press VOL+/- button to adjust or set the YEAR/MONTH/DAY . -
Page 21: Connecting Additional Equipments
Connecting Additional Equipments Connecting additional equipments You can connect a stereo to the AUDIO output terminals on the TV set to enjoy sounds of higher quality. Video and audio input terminals in the side panel To video terminal To AUDIO-L terminal To AUDIO-R terminal To audio/video input Signal flow... -
Page 22: Troubleshooting
Troubleshooting *To assist in location possible faults use help guide below. BREAKDOWN PHENOMENON CHECKING SOUND PICTURE The aerial direction and connection Picture with snow Noise This is called ghosting which can be minimized with an outside aerial, and good quality cable and terminations. -
Page 23: Specifications
*Design and specifications are subject to change without notice. Color system PAL AV NTSC3.58 NTSC4.43 Sound system Sound output power 2X2W 2X3W 2X4W X400 X452 21FA12-AM Size 817 W x616 D x390 H 29FA11-AM 800 W x444 D x596 H 29FA11-AM Remote control Accessories Owner's manual Battery(AAA) - Page 24 0090505249...
