T18230
Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
5"
(127 mm)
(333.37 mm)
9 1/2"
(241.30 mm)
Designate proper finish suffix
RP40594 Touch-Clean
Showerhead
®
4 3/4"
(121 mm)
Full Spray
Massage Spray
3 3/4"
(95 mm)
Soft Aerated Spray
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.specselect.com for finish options and product availability.
DSP-B-T18230 Rev. B
4 1/4"
(108 mm)
13 1/8"
2 3/4 " (70 mm)
A74
2 13/32"
As
Desired
4 1/4"
(108 mm)
Fixed
Inlets
(61mm)
TUB AND SHOWER
JETTED SHOWER
TRIM
®
Innovations
Collection
Shower Only
STANDARD SPECIFICATIONS:
• Monitor
®
18 Series pressure balanced bath mixing
valve with Scald-Guard
®
.
• Maintains a balanced pressure of hot and cold water
even when a valve is turned on or off elsewhere in
the system.
• Must also order R18222 Jetted Shower XO
R18224 Jetted Shower
TM
rough valve body.
• Back to back installation capability.
• Lever volume control handle; temperature
adjustment dial.
• Red and Blue graphics indicate hot/cold
temperature adjustment.
• Field adjustable to limit handle rotation into
hot water zone.
• Maximum dial rotation adjustable between
90° and 180°.
• All parts are replaceable from the front of the valve.
• Adjusts for up to 1" wall thickness.
WARRANTY
• Lifetime Faucet and Finish Limited Warranty to the
original consumer purchaser to be free from
defects in material and workmanship.
• 5 Year Limited Warranty for usage in all industrial,
commercial and business applications.
U P
C
®
®
COMPLETE VALVE COMPLIES WITH:
•
ASME A1 12.18.1 / CSA B125.1
•
ASSE 1016
Indicates ADA compliance to
ICC/ANSI A117.1
•
CSA Certified
•
IAPMO Listed
Pressure (kPa)
0
69
138
207
276
345
6
5
4
3
2
1
0
0
10
20
30
40
50
Pressure (PSI)
55 E. 111th Street, Indianapolis, Indiana 46280
395 Matheson Bld. E., Mississauga, ON L4Z 2H2
© 2008 Masco Corporation of Indiana
™
TM
or
414
483
552
621
22.7
18.9
15.1
11.4
Showerhead
7.6
3.8
0
60
70
80
90
2.D.21
