Delta T17T038 Specifications

T17T038 T17T238
Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
7"
(178 mm)
Designate proper finish suffix
®
RP51305 Touch-Clean Raincan
Showerhead
2 5/8"
(67 mm)
Full Spray
5 1/8"
(130 mm)
RP51303 (Pull-Up Diverter)
6 3/4"
(171 mm)
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.specselect.com for finish options and product availability.
DSP-B-T17T038 Rev. A
T17T438
Face of plasterguard
should be flush with
finish wall line.
2 3/4"
(70 mm)
2 3/4"
(70 mm)
TUB AND SHOWER
JETTED SHOWER
TRIM
Lahara ™ Bath Collection
TempAssure ® Thermostatic
Valve Only (T17T038)
Shower Only (T17T238)
Tub/Shower (T17T438)
STANDARD SPECIFICATIONS:
• TempAssure
• Thermostatic wax element maintains the outlet
temperature to ±3.6˚F.
• Must also order R10000-UNBX rough valve body.
As
• Back to back installation capability.
Desired
• Lever volume control handle; temperature
adjustment dial.
• Graphics indicate hot/cold temperature adjustment.
• Field adjustable to limit rotation into hot water zone.
• All parts are replaceable from the front of the valve.
Inlet
• Adjusts for up to 1" wall thickness.
8" (203 mm)
min.
18" (457 mm)
Max.
WARRANTY
• Lifetime Faucet and Finish Limited Warranty to the
original consumer purchaser to be free from
defects in material and workmanship.
• 5 Year Limited Warranty for usage in all industrial,
commercial and business applications.
COMPLETE VALVE COMPLIES WITH:
•
ASME A1 12.18.1 / CSA B125.1
•
ASSE 1016
Indicates ADA compliance to
ICC/ANSI A117.1
•
CSA Certified
•
IAPMO Listed
0
9
8
7
6
5
4
3
2
1
0
0
55 E. 111th Street, Indianapolis, Indiana 46280
395 matheson Blvd. E., Mississauga, ON L4Z 2H2
© 2007 Masco Corporation of Indiana
®
17T thermostatic valve cartridge.
U P
C
®
®
Pressure (kPa)
69 138 207 276 345 414 483
Tub Filler
Showerhead
10 20 30 40 50 60 70
™
552 621
34.1
30.3
26.5
22.7
18.9
15.1
11.4
7.6
3.8
0
80 90
