542-WFMPU
Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
??" (?? mm)
Max. Deck
Thickness
5 5/16"
(135 mm)
1/2"-14 NPSM
2 1/8"
(54 mm)
Dia.
3 3/8"
(86 mm)
4 5/8"
(118 mm)
1 1/4" (32 mm) Dia.
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book for
finish options and product availability.
DSP-L-542 Rev. B
6 5/8"
(168 mm)
6"
(152 mm)
2 3/8"
(60 mm)
6 9/16"
(167 mm)
4" Centers
(102 mm)
1 5/8"
(42 mm)
to
2 3/8"
(61 mm)
1 3/8"
(35 mm)
Dia.
LAVATORY
FAUCETS
Innovations
Single Handle Deck Mount
3 Hole Sink Applications
4" Centerset
STANDARD SPECIFICATIONS:
•
Solid brass fabricated body.
•
4" (102 mm) centerset.
•
5 5/16" (135 mm) long, 3 7/8" (98 mm)
high spout.
•
Clear knob handle. Control mechanism is the
rotating stainless steel ball type with replaceable
non-metallic seats operating in stainless steel
lined sockets.
•
Model has 3/8" O.D. copper supply tubes with
1/2"-14 NPSM adapters.
•
Metal drain with pop-up type fitting with plated
flange and stopper.
WARRANTY
• Lifetime Faucet and Finish Limited Warranty to the
original consumer purchaser to be free from
defects in material and workmanship.
• 5 Year Limited Warranty for usage in all industrial,
1 13/16"
(46 mm)
commercial and business applications.
U P
®
COMPLIES WITH:
•
ASME A1 12.18.1 / CSA B125.1
•
ASME A1 12.18.2 / CSA B125.2
•
IAPMO Listed
•
CSA Certified
0
69
138
207
6
5
4
3
2
1
0
0
10
20
Indianapolis, Indiana 46280
A Division of Masco Corporation of Indiana
© 2006 Masco Corporation of Indiana
®
Series
C
®
Pressure (kPa)
276
345
414
483
552
621
22.7
18.9
15.1
11.4
7.6
3.8
0
30
40
50
60
70
80
90
Pressure (PSI)
1.D.4
