Figure 4. VLAN tunneling mode - OS tagged packet goes to data center switch
OS TAG OS TAG OS TAG OS TAG OS TAG OS TAG
OS TAG
FlexNIC FlexNIC FlexNIC FlexNIC FlexNIC FlexNIC FlexNIC
Double
Tagged
VNET
VNET
Uplink Uplink
Data Center Switch

Mapping

A FlexNIC can also be configured to support OS VLAN tag mapping to different VC networks, as
shown in Figure 5. The combination of the outer VLAN tag and the inner OS tag are used to map an
Ethernet packet to a particular vNet. Double-tagged packets are mapped to vNet destinations without
exiting the VC domain.
BladeSystem
VM
OS TAG
server
Flex10 LOM/
Mezz Card
FlexNIC
port 01
VNET
VNET
Shared Uplink
1Gb server 1Gb server
VNET VNET VNET VNET
VNET VNET
VNET VNET
1Gb server 1Gb server
VNET VNET VNET VNET
Flex-10 Enet
Module
8
