Mini Aroma Diffuser Model: WS904 USER MANUAL CONTENTS Introduction................ For Your Safety..............Overview................Features................How to Use............... Precautions for use............Use of Aromatic Oil............Care and Cleaning............Specifications..............About Oregon Scientific............. EU-Declaration of Conformity..........
INTRODUCTION Thank you very much for purchasing our “WS904 Mini Aroma Diffuser”. This instruction manual contains useful information on the proper use and care of this product. In order to enjoy its features, read through this manual first before use and keep it for future reference.
• Do not immerse the unit body or AC adaptor under water or splash them with water. • Do not plug or unplug the AC adaptor with wet hand. When not in use, pull the power cord out of the wall socket.
Page 5
Timer indicator LED Mist outlet Light switch Mist switch Watering cup DC plug Pouch AC adaptor...
FEATURES Packed in an elegant and easy-to-carry pouch, which can • carry a maximum of two aromatic oil bottles. Aroma can be enjoyed everywhere and anywhere, • even when travelling. • Only a drop or two of your choice aromatic oil can create a long-lasting scent in the air.
Page 8
* This product operates in Eco mode (intermittent operation). Slide the tank cover up (circled by dotted line) and detach from the unit. Pour water gently from the watering cup into the water tank and fill it between “MIN” (dotted line) and “MAX” (solid line).
When the amount of water in the water tank is low, NOTE mist ejection will automatically stop and the LED light will turn off regardless of the remaining time of the mist timer. PRECAUTIONS FOR USE • When the water tank is filled with water, remove the tank cover with great care.
• Near objects that are directly exposed to the ejected mist (e.g. furniture, clothes, curtains, walls, papers or ceilings). • Near areas of fire, direct sunlight or high temperatures (e.g. heaters or ventilation holes of air-conditioners). • Overhead locations or uneven, unstable surfaces (e.g.
Page 11
• Always use 100% plant-derived essential oil. Do not use other oils, or oils that are diluted with alcohol, or oils containing impurities, perfume or cologne. • Put a drop or two of oil into 40ml of water. Do not exceed the suggested amount.
CARE AND CLEANING Follow closely the steps below for the proper care and cleaning of the product to ensure its usability and durability. • Clean the water tank every three or four days as described below: Unplug the AC adaptor from the product. Detach the tank cover.
Page 13
minutes then pour out the tap water. Wipe the water tank dry thoroughly with a dry cloth. Wipe the inner and outer surface of the tank cover with a soft cloth. Use soft cotton swabs to clean the mist outlet. •...
SPECIFICATIONS Product name Mini Aroma Diffuser Unit colour Water lily (White) Cherry (Pink) Plum (Bluish black) Dimensions (mm) 73 (H) x 90 (W) x 45 (D) Weight (g) Approx.130 (Not including AC adaptor) Power source Dedicated AC adaptor supplied Input: AC100 - 240V 50/60Hz Output: DC24V 500mA Power cord length: Approx.1.8m Power consumption...
ABOUT OREGON SCIENTIFIC Visit our website (www.oregonscientific.com) to learn more about Oregon Scientific products. If you’re in the US and would like to contact our Customer Care department directly, please visit: www2.oregonscientific.com/service/support Call 1-800-853-8883. For international inquiries, please visit: www2.oregonscientific.com/about/international...
Page 16
“This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
