Technical Specification � � � � � � � � � � � � � � 17 Do not use any power adapter except the About Oregon Scientific � � � � � � � � � � � � 17 one provided.
Page 3
Disclaimers • Oregon Scientific will not, under any circumstances, hold responsibilities for injuries or property damage incurred during participation of any high-risk activities, which are not endorsed or recommended by Oregon Scientific. Should the device malfunction under these circumstances, it will not be covered under warranty.
Overview Front View Compartment cover button Mist outlet ON / OFF key Hair Mode key Drain saucer Face Mode key Sleep Mode / Aromatherapy Mode key...
Page 5
View Rear Handle Water container Valve Container cap Water tank cover The water tank must be closed during operation. Air inlet Power socket Drain switch Make sure the drain switch is at the “CLOSE” position before pouring solution into the water tank. Or otherwise, the solution will flow directly dow to the drain saucer.
Accessories Mist outlet stopper Seals the mist outlet when the device is not in use. p.16 Cleaning and Maintenance Extension hose Connects to the nozzle to Specially made extend the reach of mist. p.12 p.13 Herbal Solution Skin Treatment Hair Treatment Aroma head Attaches to the mist outlet for aromatherapy...
Page 7
Comb Sponge for aroma diffuser Sits inside the aroma head and holds Attaches to the nozzle and aromatic oil for aromatherapy extension hose for hair treatment. p.13 p.14 Hair Treatment Aromatherapy Herbal Solution and Serums Nozzle e for NanoActiv Skin Restoring System Directs the mist to a specific direction.
Functions of NanoActiv Skin Restor Hair Mode *with nozzle, comb and extension hose *please refer to below table for application Face Mode *please refer to below table for application Routine skin care MODE Solution Intensive skin care 45ml (with nozzle and FACE Herbal Solution extension hose)
ring System Sleep Mode *with nozzle *please refer to below 30cm approx. table for application Aromatherapy Mode • 75ml is designed for Sleep / Aromatherapy Mode. Use *with aroma head with distilled water. *please refer to below • 45ml is designed for Face and Hair table for application Mode.
Using the Device Getting accustomed to the device Those new to the device should start with skin treatments twice a day, or hair treatment 2-3 times a week. If you encounter any skin problems after use, stop using the device and consult your doctor� Check the followings before using the product: The air inlet and The water tank...
Page 11
Pull out the water container. Turn the container cap anti-clockwise to open the container. Fill the container with Herbal Solution up to the Herbal 45ml mark and mix with 2 full pumps of either Solution Intensive Restoring Serum for Face Mode or Revitalizing Hair Treatment Serum for Hair Mode.
Operation A. Setup Place the device on a sturdy, level and dry surface. Connect the power adapter to the device. Plug the power adapter to a main outlet. Press to turn on the device. B. Skin Treatment Press the key to start the skin treatment. A LED above the key will light up.
C. Hair Treatment Attach the comb, the nozzle and the extension hose to the mist outlet. Press the key to start the hair treatment. One LED above the key will light up. Each treatment lasts for 5 minutes. Press the key again to increase the mist volume.
D. Sleep Mode - Continued Press the key to start the sleep mode. The device will emit mist for 1 minute and then pause for 7 minutes. This cycle will last until the water runs out. A full tank of water can last around 8 hours. Press the key to switch the device to standby mode.
Cleaning and Maintenance Turn off the device and unplug it from the power supply before cleaning� A. Draining the distilled water / herbal solution / serum Slide the drain switch to the “Drain” position. The blue LED at the base will start flashing and the solution inside the water tank will be released to the drain saucer.
B. Cleaning the water tank Open the water tank compartment. If herbal solution or serum is used, fill the container with distilled water, insert it into the container compartment and drain. Turn the water tank cover anti- clockwise and take it out. Use the cleaning brush to clean the diffusing plate and the inner surface of the water tank.
2004 / 108 / EC and Low Voltage Equipment directive 2006 / 95 / EEC. A copy of the signed and dated Declaration of Conformity is available on request via our Oregon Scientific Customer Service. Correct Disposal of this product:...
