Data Sheet
Tiger Switch™ 10/100
SMC6709L2
8-port 10/100+ 1 Gigabit
and 2 Uplink Slot Standalone Managed Switch
SMC6709L2 is an intelligent standalone Fast Ethernet Switch with
8 auto-MDIX 10BASE-T/100BASE-TX ports and 1 10/100/1000BASE-T
port. There are also 2 slots for optional uplink expansion. One of
the slots supports 100BASE-FX SMF/MMF via a SC/ST/MTRJ port, the
second slot supports 1000BASE-T/SX/LX.
With an aggregated bandwidth of up to 3.8Gbps, it has a nonblocking
switching architecture that facilitates packet forwarding at wire-
speed. As today's network has diverse needs such as multimedia
applications, QoS is also delivered on this TigerSwitch thru IEEE802.1Q
VLAN's, GVRP and priority queuing that ensures the smooth delivery
of mission critical data and security of different multicast groups.
The SMC6709L2 is perfect for the small or medium sized business
and education market segment looking to strengthen their networks
with an intelligent 8-port switch with a fixed gigabit port and fiber
modules.
Features and Benefi ts
High Performance & Functionality
•
Easy to install and integrate: 8-port 10/100 auto-MDIX port and 1 gigabit port
•
Convenient expansion: each unit comes with 1 slot supporting Gigabit Fiber and 1 slot for
100BASE-FX
•
QoS expedites critical data via prioritizing and fi ltering
•
MultiLink trunking creates high-speed data paths to servers or other switches
•
VLAN support provides port VLANs and GVRP for auto-registration
•
IGMP snooping reduces multicast traffi c for maximum performance
•
Broadcast storm control allows a userdefi ned threshold to limit broadcast traffi c
Compatibility
•
IEEE802.3
•
IEEE802.3u
•
IEEE802.3z
•
IEEE802.1d
•
IEEE802.1p
•
IEEE802.1Q
•
IEEE802.3ad
•
IEEE802.3ab
•
IEEE802.1ac
Product Model No
Tiger Switch 10/100
SMC6709L2
Modules SMC6709L2GSSC
SMC6709L2GLSC
SMC-EZ108FMSC
SMC-EZ108FSSC
SMC-EZ108FMST
SMC-EZ108FMMT
Description
8-port 10/100 auto-MDIX ports and 1 1000BASE-T port
1-port 1000BASE-SX, SC module
1-port 1000BASE-LX, SC module
1-port MMF 100BASE-FX SC module
1-port SMF 100BASE-FX SC module
1-port MMF 100BASE-FX SC module with SC to ST converter
1-port MMF 100BASE-FX MTRJ module
