ZyXEL Communications CARRIER SWITCHES - QUICK SALES GUIDE Manual

Carrier Switches Product Highlight
Cabinet Switch Solution
MES-3728
Metro Managed Layer 2
Fast Ethernet Switch
Key Benefits
Optimized Design for Cabinet
The cabinet switch solution (MES-3728, MGS-3712, and MGS-3712F)
is the ZyXEL's Metro Ethernet Switch that offers high operating
MEF9 & MEF14 Certified
(EPL, EVPL and E-LAN)
temperature tolerance, flexible AC/DC dual-input power source as well
as protection against humidity and dust for service providers to extend
their networks.The cabinet switches adopt the "front access" design,
technicians can easily wire and maintain outdoor cabinets; the external
The ZyXEL MES-3728 (RoHS compliant; green alarm input/output block connects mechanical cabinet parts to the
product) L2 Ethernet switch offers Layer 2 switching. management networks and offers higher protection to the equipment.
With non-blocking 12.8 Gbps switching fabric.
Advanced QoS for Significant Service
A consistency service quality and reliable connecting ability in a
converged network is the key for service providers to trust customer
and build customer loyalty.Therefore, the ability to control traffic flow
and set traffic policy becomes increasing critical.The cabinet switch
solution offers wire-speed flow control which can classify, policy, and
prioritize the incoming packets according to predefine QoS policies
which can meet service provider's requirements. In classification,
Differentiated Services Code Point field (DSCP) and the 802.1p class
of service (CoS) field are identified to assess the priority of incoming
packets. Classification and reclassification can be based on criteria as
MGS-3712/MGS-3712F
specific as rule-based on IP, MAC addresses, VLAN ID, TCP/UDP port
number. Moreover, for bandwidth management, the cabinet switch
Metro Managed Layer 2
solution provide 8 priority queues per port for different types of traffics,
Gigabit Ethernet Switch
allowing service provider to set rule-based rate limiting which takes
full advantage of limited network resources and guarantees the best
performance.
Enhanced Security Help Create Protection among Customers
Avoiding subscribers affecting each other in a shared network or
shared device is a major concern for service providers.The cabinet
MEF9 & MEF14 Certified
(EPL, EVPL and E-LAN)
switch solution offers complete set of security to protect user's data
and administrative traffic.The intrusion lock function detects the
"plugged" and "unplugged" status change of Ethernet cables, and the
switch will deactivate the port automatically if needed.The 802.1x
MGS-3712F
authentication can secure the network from unauthorized users. Port
security provides the ability to deny unauthorized users from accessing
the network. Moreover, Cooperating with RADIUS, 802.1x is useful to
prevent unauthorized access based on username and password (or
MGS-3712
other credentials) and acts as powerful access control for convergent
networks with mixed wired and wireless access.
The ZyXEL MGS-3712 and MGS-3712F L2 Gigabit
Ethernet switches offer Layer 2 switching capability Furthermore, the cabinet switch solution provides multilayer (L2/
in a smart enclosure. With non-blocking 24 Gbps L3/L4) ACLs suite of sophisticated rule-based control mechanisms,
switching fabric, the MGS-3712 and MGS-3712F
enabling service provider easily deployed, based on realistic network
feature 8 GbE copper ports (8 port GbE SFP on environments via a Web GUI or command line to prevent abnormal and
MGS-3712F) and 4 dual-personality GbE (GbE SFP + illegal access.The rules can be defined to deny packets based on source
1000BASE-T) ports. and destination MAC addresses, IP addresses, or TCP/UDP ports.
