Specifications - AKG HT 40 User Instructions

4. As soon as the windscreen has dried,
replace it in the wire-mesh cap and
screw the wire-mesh cap onto the
transmitter CW.

6 Specifications

Carrier frequency range
Modulation
Audio bandwidth
Frequency stability (-10°C to +50°C)
Rated deviation
T.H.D. at 1 kHz
Compander
Signal/noise ratio
RF output
Current consumption
Power requirement
Battery life
Audio input level for rated deviation
Input impedance
Size
Net weight
This product complies with the following standards:
EN60065:1998, EN301 489-9 v.1.1.1 (09-2000), and EN300 422-2 v.1.1.1 (07-2000).
710 to 865 MHz
FM
40 to 20,000 Hz
±15 kHz
15 kHz
typ. 0.8%
integrated
103 dB(A) typ.
10 mW typ.
70 mA typ.
2 x 1.5-V AA size batteries
30 hours typ.
100 mV/1 kHz
220 kΩ
length: 258 mm (10 in.);
dia.: 40 mm (1.6 in.)
245 g (8.7 oz.)
19
