Important
Please read this User's Manual and Setup
Manual (separate volume) carefully to
familiarize yourself with safe and effective
usage.
PRECAUTIONS
Chapter 1 Features and Overview
1-1 Features
1-2 Buttons and Indicators
1-3 Functions and Basic Operation
Chapter 2 Settings and Adjustments
2-1 Utility Disk
2-2 Screen Adjustment
2-3 Color Adjustment
2-4 Off Timer/Power Saving Settings
2-5 Screen Size Selection
2-6 Power Indicator/EIZO Logo Display Setting
2-7 Locking Buttons
2-8 Setting Adjustment Menu Display
2-9 Viewing Information/Setting Language
2-10 Resumption of Default Setting
Chapter 3 Connecting Cables
3-1 Connecting Two PCs to the Monitor
Chapter 4 Troubleshooting
Chapter 5 Reference
5-1 Attaching an Arm (Option)
5-2 Cleaning
5-3 Specifi cations
5-4 Glossary
5-5 Preset Timing
How to Setup
Please read the Setup Manual (separate volume

Advertisement

Table of Contents
loading

Related Manuals for Eizo FLEXSCAN S2000

Summary of Contents for Eizo FLEXSCAN S2000

  • Page 1 2-2 Screen Adjustment 2-3 Color Adjustment 2-4 Off Timer/Power Saving Settings Important 2-5 Screen Size Selection 2-6 Power Indicator/EIZO Logo Display Setting Please read this User’s Manual and Setup 2-7 Locking Buttons Manual (separate volume) carefully to 2-8 Setting Adjustment Menu Display...

  • Page 2: Safety Symbols

    EIZO NANAO CORPORATION’s receipt of said information Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifi cations are subject to change without notice.

  • Page 3: Precautions

    PRECAUTIONS IMPORTANT • This product has been adjusted specifi cally for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specifi ed in the specifi cations. •...
  • Page 4 WARNING Place the unit at the strong and stable place. A unit placed on an inadequate surface may fall and result in injury or equipment damage. If the unit falls, disconnect the power immediately and ask your dealer for advice. Do not continue using a damaged unit.
  • Page 5 WARNING Handle the power cord with care. • Do not place the cord underneath the unit or other heavy objects. • Do not pull on or tie the cord. If the power cord becomes damaged, stop using it. Use of a damaged cord may result in fi re or electric shock.
  • Page 6 CAUTION Handle with care when carrying the unit. Disconnect the power cord and cables when moving the unit. Moving the unit with the cord attached is dangerous. It may result in injury. When handling the unit, grip the bottom of the unit fi rmly with both hands ensuring the panel faces outward before lifting.

  • Page 7: Lcd Panel

    LCD Panel In order to suppress the luminosity change by long-term use and to maintain the stable luminosity, use of a monitor in lower brightness is recommended. The LCD panel is manufactured using high-precision technology. However, note that the appearance of any missing pixels or lit pixels does not indicate damage to the LCD monitor.

  • Page 8: Table Of Contents

    [Border Intensity] ..........19 Power Indicator/EIZO Logo Display Setting ................. 20 ● To turn off the Power indicator while a screen is displayed [Power Indicator Setting] ....20 ● To display EIZO logo [EIZO Logo Appearing Function] ............20 CONTENTS...

  • Page 9: Chapter 1 Features And Overview

    • This monitor supports the Portrait/ • The utility software “ScreenManager Pro for LCD” (for Windows) to control Landscape display. (The panel can be the monitor from a PC with mouse/keyboard is included (refer to the EIZO turned 90 degrees clockwise.) LCD Utility Disk).

  • Page 10: Functions And Basic Operation

    1-3 Functions and Basic Operation To adjust the screen and color Main menu (Refer to page 9 for operation) Analog input only Automatic Adjustment Page 11 Press Press again. Screen Adjustment Page 11 • The Adjustment menu and the FineContrast menu cannot be displayed at the same time.

  • Page 11: Basic Operation Of Adjustment Menu

    EIZO Logo Display Setting Page 20 menu settings ……………………… see page 21 ● [EIZO Logo Appearing Function] to display or Resume the factory default settings not to display the EIZO logo. ● [Reset] to reset all settings ………… see page 23...

  • Page 12: Chapter 2 Settings And Adjustments

    Chapter 2 Settings and Adjustments 2-1 Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with the monitor. The following table shows the disk contents and the overview of the application software programs. ● Disk Contents • Disk contents and software overview The disk includes a monitor information file, application software programs for adjustment, and User’s Manual.

  • Page 13: Screen Adjustment

    NOTE Run the Screen Adjustment Program. • For how to start the Screen Load the EIZO LCD Utility Disk on the PC, and start the Screen Adjustment Program, refer to Adjustment Program compatible with the PC in use. “readme.txt” or the “Readme” fi le.

  • Page 14: [Clock] To Remove Vertical Bars

    NOTE Perform advanced adjustments for the following using the • Press the control button slowly so as not to miss the adjustment point. <Screen> menu of the Adjustment menu. • When blurring, fl ickering or bars ● To eliminate vertical bars [Clock] appear on the screen after adjustment, (1) Choose <Clock>...

  • Page 15: [Resolution] To Adjust Extra Image Or Cut Image

    ● To adjust extra or cut image [Resolution] This adjustment is available to equalize the resolution shown on the Setting menu and the resolution of input signal. (1) Choose <Resolution> from the <Screen> menu, and press The <Resolution> menu appears. (2) Adjust the vertical resolution with , and then horizontal resolution with...

  • Page 16: Color Adjustment

    2-3 Color Adjustment Simple adjustment [FineContrast mode] This function allows you to select the best display mode for monitor brightness, etc. ● FineContrast Mode An appropriate display mode is selectable out of fi ve modes. Mode Purpose Custom Available for making desired setting. Suitable for color matching with sRGB compatible sRGB peripherals.

  • Page 17: Advanced Adjustments [Adjustment Menu]

    Attention Advanced Adjustments [Adjustment menu] • Perform [Range Adjustment] before Independent setting and saving of color adjustment are available for each starting color adjustment for analog input signals. FineContrast mode. Refer to “To adjust color gradation automatically” on page 13. ●...

  • Page 18: To Set/Adjust Color

    Menu Description Adjustment range Gain To adjust red, green, and 0 to 100% blue to a desired color tone Adjust the respective brightness of respectively red/green/blue to make a desired color tone. Display an image with white or gray background for adjustment.

  • Page 19: Off Timer/Power Saving Settings

    2-4 Off Timer/Power Saving Settings ● To set monitor power-off time [Off Timer] Attention This function allows the monitor to automatically turn off after a specifi ed time • The Off Timer functions even in the has passed. This function serves to reduce afterimages caused when the monitor power saving mode, but the advance screen is left on for a long time period without use.

  • Page 20: To Set Monitor Power-Saving

    ● To set monitor power-saving [VESA DPMS/DVI DMPM] ■ Analog input This monitor complies with the VESA DPMS standard. [Power Saving System] Attention • Unplugging the power cord Power Monitor completely shuts off power supply to Indicator the monitor. Operating Operating Blue •...

  • Page 21: Screen Size Selection

    2-5 Screen Size Selection ● To change screen size [Screen Size] The image with the resolution other than the recommended resolution is displayed in full screen automatically. You can change the screen size by using <Screen size> from <Others> menu. Menu Function Displays an image in full screen.

  • Page 22: Power Indicator/Eizo Logo Display Setting

    To display EIZO logo [EIZO Logo Appearing Function] setting. When this unit is turned on, the EIZO logo appears at the center of the screen. Selection to display or not to display the logo is available with this function. [Procedure] (1) Press to power off the unit.

  • Page 23: Setting Adjustment Menu Display

    2-8 Setting Adjustment Menu Display ● To update menu settings [Menu Size/Menu Position/Menu Off Timer/Translucent/Orientation] Menu Size Change the Adjustment menu size using the following procedure. (1) Choose <Others> from the Adjustment menu, and press (2) Choose <Menu Settings> from the <Others> menu, and press (3) Choose <Menu Size>...

  • Page 24: Viewing Information/Setting Language

    Translucent Set the transparency for menu display using the following procedure. (1) Choose <Others> from the Adjustment menu, and press (2) Choose <Menu Settings> from the <Others> menu, and press (3) Choose <Translucent> from the <Menu Settings> menu, and press The <Translucent>...

  • Page 25: Resumption Of Default Setting

    NOTE 2-10 Resumption of Default Setting • For default settings, refer to “Main ● To reset color adjustment [Reset] default settings (factory settings)” on page 30. The hue in the color mode currently set will revert to the default settings (factory settings).

  • Page 26: Chapter 3 Connecting Cables

    Chapter 3 Connecting Cables 3-1 Connecting Two PCs to the Monitor Two PCs can be connected to the monitor through the DVI-I and the D-sub Attention • When using an optional signal cable mini 15-pin connectors on the back of the monitor. (FD-C16), be sure to connect the Connection examples D-sub mini 15-pin connector to the...

  • Page 27: To Set Priority Of Pc To Be Displayed [Input Priority]

    ● NOTE To set priority of PC to be displayed [Input Priority] • Power-saving function When two PCs are connected, either one can be displayed preferentially. The When “1” or “2” is selected for monitor senses the input signal regularly. When the signal that is given priority <Input Priority>, the monitor’s power-saving function works only with the <Input Priority>...

  • Page 28: Chapter 4 Troubleshooting

    Chapter 4 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. • No-picture problems → See No.1 - No.2. • Imaging problems → See No.3 - No.14. • Other problems → See No.15 - No.19. •...
  • Page 29 Problems Possible cause and remedy Whole screen is fl ickering or blurring. • Adjust using <Phase>. Characters are blurred. • Adjust using <Smoothing>. Upper part of the screen is distorted as shown • This is caused when both composite sync (X-OR) below.

  • Page 30: Chapter 5 Reference

    The stand can be removed and replaced with an arm (or another stand) to be Attention • When attaching an arm or stand, attached to the monitor. Use an arm or stand of EIZO option. follow the instructions of their user’s manual.

  • Page 31: Specifi Cations

    5-3 Specifi cations LCD Panel 20.1-inch (510 mm) TFT color LCD with anti-glare hard coating Viewing angle: Vertical 178°, Horizontal 178° (CR: 10 or more) Dot Pitch 0.255 mm Horizontal Scan Frequency Analog: 24 - 94 kHz (Automatic) Digital: 31 - 76 kHz Vertical Scan Frequency Analog: 49 - 86 Hz (Automatic) (1600 ×...
  • Page 32 Main default settings (factory settings) Analog Input Digital Input Brightness 100% 100% Smoothing FineContrast Mode Custom PowerManager VESA DPMS DVI DMPM Screen Size Full Screen Input Priority Off Timer Disable Menu Settings Menu Size Normal Menu Off Timer 45sec Language English Outside Dimensions unit : mm (inch)

  • Page 33: Glossary

    + Data Serial data Ground Cable ground Option List Cleaning Kit EIZO ScreenCleaner Signal Cable FD-C16 5-4 Glossary Clock The analog input monitor needs to reproduce a clock of the same frequency as the dot clock of the graphics system in use, when the analog input signal is converted to a digital signal for image display.
  • Page 34 Gamma Generally, the monitor brightness varies nonlinearly with the input signal level, which is called “Gamma Characteristic”. A small gamma value produces a low-contrast image, while a large gamma value produces a high- contrast image. Phase Phase means the sampling timing to convert the analog input signal to a digital signal. Phase adjustment is made to adjust the timing.

  • Page 35: Preset Timing

    5-5 Preset Timing The following table shows factory preset video timing. Attention • Display position may be deviated Frequency depending on the PC connected, Mode Dot clock Horizontal: kHz Polarity which may require screen adjustment Vertical: Hz using Adjustment menu. Horizontal 31.47 Negative...
  • Page 36 Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the Impact on our natural environment.

  • Page 37: Fcc Declaration Of Conformity

    Changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specifi ed cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord...
  • Page 38 Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor Dieser Monitor ist für Bildschirmarbeitsplätze vorgesehen. Wenn nicht der zum Standardzubehör gehörige Schwenkarm verwendet wird, muss statt dessen ein geeigneter anderer Schwenkarm installiert werden. Bei der Auswahl des Schwenkarms sind die nachstehenden Hinweise zu berücksichtigen: Der Standfuß...
  • Page 39 Recycle Auskunft Die Rücknahme dieses Produktes nach Nutzungsende übernimmt EIZO in Deutschland zusammen mit dem Partner eds-r gmbh rucknahmesysteme. Dort werden die Geräte in ihre Bestandteile zerlegt, die dann der Wiederverwertung zugeführt werden. Um einen Abholtermin zu vereinbaren und die aktuellen Kosten zu erfahren, benutzen Sie bitte folgende Rufnummer: 02153-73 35 00.
