Preface
Thank you for purchasing this camera. This camera will help you fulfill all
your digital pictures processing needs.
The camera is equipped with five modes (Capture Mode, Playback
Mode, DSC Setup Mode, Video Mode, and Macro Mode) for your explo-
ration.
This light and handy digital camera offers 3.23 mega pixels high-quality
image along with precise 12 x zoom (3 x optical plus 4 x digital) The built-
in 16MB memory can store your images. The stylish metallic case is
crafted from aluminum alloy, making this camera light and portable.
Through a USB cable connection, pictures can be easily transmitted from
the camera to the PC. Nine recorded images can be displayed on the
high resoultion LCD. Continuous shooting function is also available for
users to take multiple frames of scenes in quick succession.
Note:
1.
The company keeps the right to change the con-
tents of this document, spec of this camera in the
future, without prior notice.
i
Advertisement
Table of Contents
Related Manuals for Rollei dt3200
Summary of Contents for Rollei dt3200
- Page 1 Preface Thank you for purchasing this camera. This camera will help you fulfill all your digital pictures processing needs. The camera is equipped with five modes (Capture Mode, Playback Mode, DSC Setup Mode, Video Mode, and Macro Mode) for your explo- ration.
-
Page 2: Table Of Contents
Table of Contents Preface................. i Prior to Operating the Camera ........1 Unpacking the camera............1 Identifying components ............2 Loading the battery and SD Card..........3 Basic Settings................4 Formatting the SD Card ............4 Basic Operating Procedure ........5 Turning the Camera ON/OFF.......... -
Page 3: Prior To Operating The Camera
Prior to Operating the Camera Set this digital camera by following these quick and simple instructions. Unpacking the camera Clear all items from the box. (It is highly recommended that the box and wrap- pings are kept for future usage) Double check for the following items: CD-ROM Handstrap... -
Page 4: Identifying Components
Identifying components Flash Viewfinder Handstrap Hook Auto-Focus LED Self timer LED Zoom Lens Display Button Zoom Button Power/Flash LED Microphone Viewfinder TFT LCD DC-in & USB Connector Power Button Menu Selection Five-way Switch Shutter Mode Dial Speaker Battery & SD Card Compartment Battery Charging Status LED Red (Charging), Green (Done) -
Page 7: Basic Operating Procedure
Basic Operating Procedure This section provides simple and basic directions to get you started with your camera. From this section, you will learn how to turn the camera on and off, shoot pictures, zoom In and Out, set your flash, and playback your pictures. -
Page 9: Playback
Five Main Camera Mode and Instructions This section describes the five modes included in this camera. An in- depth coverage of these modes will be further described. Here are the five main functions of this camera: Camera Mode Function Setting Page Video Mode Page 9... - Page 10 Macro Mode Page 17 Resolution Image Quality Color Effect White Balance Scene Metering Sharpness EV Adjust DSC Setup Mode Date and Time Page 17 Auto Power Off DPOF Slide Show Sound Effect Languages TV-out Restoring NOTE: Press the display button once to delete the icons from the LCD display.
-
Page 12: Capture Mode
Capture Mode Capture mode will allow you to shoot single, continuous images, set your flash and self-timer. Depending on the environment and setting, the cam- era’s settings will work accordingly. To exit the setting menu, simply press the menu button. Metering White Balance ISO (100/200) - Page 13 • FLASH Setting 1.To set the Flash, press the Five-Way Switch to the Left to select the desired Flash setting. You will have the four types of Flash settings: Flash Off, Auto Red-eye reduction, Flash Force On, and Night. Once you’ve set your Flash setting, proceed with your picture taking.
- Page 15 White Balance Users can select the fol- It adjusts the rela- lowing white balance: tive brightness under different condition. Auto The default is Auto. Shade Tungsten Fluorescent Sharpness Enhance of edge Users can select the fol- detail. The default is lowing sharpness: Normal.
-
Page 17: Displaying Thumbnails
• Displaying Thumbnails Turn the Mode Dial to Playback Mode. Press the display button two times to thumbnails in sets of nine. Use the Five-Way Switch to change the image selection. Press OK button to magnify images to standard size. Press the left or right button to view other images. -
Page 18: Macro Mode
Digital Print Order Users can select from: It is a standard for print- Format or DPOF ing the pictures directly Frame Set from the SD card. Pic- Reset all tures can be printed on printers compatible with the DPOF standard. frame set -->... -
Page 19: Dsc Setup Mode
DSC SETUP MODE Under this mode, you will be able to set your desired settings. There are a total of eight different settings. Sound Effect Languages Auto Power Off TV-out Date and Time Restoring DPOF Slide Show Order Turn the mode dial to enter the DSC Setup Mode. Select the type of setup you want to perform by pushing the left or right button. - Page 20 Slide Show Users can select the: Under this setting, users can set the number of Interval seconds they want the Repeat slide show to proceed Direction per slide, repeat the show or not, and the direction where these slides should proceed. Sound Effect Users can select either This function allows...
- Page 21 Restoring Reset back to default. To revert the setting back to the default setting. Press the OK if you want to, if not, press the “right” or “left” button to con- tinue next setting. When restoring is completed, "done" will appear on the LCD.
-
Page 22: Making Connections
Making Connections In this section you will be able to connect the camera to your PC to down- load or edit photos. The docking station can also be used for TV out and to charge battery. Installing software Insert the CD-ROM into your CD-ROM drive. Click “Digital Camera Driver”... - Page 23 A. Editing with ArcSoft Turn the computer ON. Connect the camera and the computer with the USB port cable. Turn the camera ON. Launch Photo Impression (the inclusive software which you have downloaded from the CD-ROM.) Select "from folder", you can find your camera as a new disk to upload your images to edit.
-
Page 24: Connecting Through Tv-Out Via Docking Station (Optional)
Connecting through TV-out via docking station (optional) Before you proceed, please determine your corresponding TV-Out mode. This camera will you to achieve full camera functions by TV-out connec- tion. User can operate each function through the TV monitor instead of the LCD display. -
Page 25: Appendix
APPENDIX Specifications Features Content Effective pixels 3.23M sensor, scale up to 5.5M Removable storage SD/MMC card Internal memory 16MB NAND Flash Memory Estimated number of Compression ratio@ 1 : 8, 16MB SD card storable pictures 5.5M: 8 pictures 3.0M: 15 pictures 1.3M: 35 pictures VGA:140 pictures Video mode display... - Page 26 Camera Interface Mini USB/DC-in Multiple language UI English/French/German/Italian/Spanish/ Japanese/Traditional and Simplified Chi- nese/ Korean Compatible Battery Li-ion battery Battery Level High/ Middle/ Low/ Empty AC Adapter 5 V 2A (optional) Docking interface Mini USB/ TV Out(through docking)/DC (Optional) In(through docking)" Dimension (WxHxD) 96 x 61 x 32 (mm) Weight...
