Microtek ArtixScan 120tf Reference Manual page 102

Selected From color
is enclosed in a
sector with a hollow
dot in it. Resizing this
sector (using the
Spiked Ball pointer)
will change the Delta
LCH values in the edit
boxes
NEW button
Hollow dot position reflects
e) To move the From color sector without changing the hollow dot position-
Hollow Cross
pointer (Hand
pointer for PC)
Click NEW
button to
specify
additional
colors to be
altered
To adjust the lightness of the From value, drag this
arrow along the slider. The value of the slider is the
same as the value shown in the " From L" edit box.
C&H From color values
For Mac
Press the Shift key and click inside the sector. When the pointer changes
to a Hollow Cross, drag the sector to a new position.
For PC
Press the Ctrl key and click inside the sector. The pointer now turns into
a Hand pointer, then drag the sector to a new position.
You will see that the sector can only be expanded or contracted in a
limited fashion, as it is constrained by the position of the hollow dot. If
you need to move the sector around, you will also need to reposition the
hollow dot, which then changes the Chroma and Hue (C&H) values.
Left Eyedropper to pinpoint From
color on color wheel
From color sector. To reposition From color
sector without moving the hollow dot, press the
Shift key and click, and drag the sector around
the hollow dot position. The sector cannot break
away from the fixed position of the hollow dot.
Hollow dot
To color preview
From color preview
Reference: The Advanced Image Correction tools
Be sure the
From element on
top of the
column is
underscored if
you are
changing any of
the " From" LCH
edit boxes.
93
