Datamax S-Class with USB ST/SV 3210 Quick Start Manual

!
Turn off the printer before
Connecting the
Printer
Serial Port
USB Port
Parallel Port
ONLINE Indicates the printer is ready to accept data.
FAULT Indicates no ticket stock is detected or that a
mechanical malfunction has occurred.
POWER Indicates that main power to the printer is 'On.'
Controlling the
Printer
PAUSE / F1 Allows the operator to temporarily stop printing
(pause mode) or to enter off-line mode.
FEED / F2 Allows the operator to advance the ticket stock to
the next print position.
TEST / F3 Allows the operator to print test tickets when the
printer is in off-line mode.
connecting cables Serial Port
USB Port
Parallel Port
AC Power Connector
Power On/Off Switch
AC Power Connector
Power On/Off Switch
Indicator Lights:
Buttons:
Note: More information
on the Front Panel can be
found in Section 3.4 of the
Operator's Manual.
With USB
ST/SV 3210 & ST/SV 3306

Quick Start

Guide
