IBM System Storage SAN04B-R
Installation, Service, and User's Guide
Service information: 2005 / R04
Read Before Using
This product contains software that is licensed under written license agreements. Your use of such software is subject to
the license agreements under which they are provided.
GA32-0583-01

Advertisement

Table of Contents
loading

Related Manuals for IBM SAN04B-R - System Storage Router

Summary of Contents for IBM SAN04B-R - System Storage Router

  • Page 1 IBM System Storage SAN04B-R Installation, Service, and User’s Guide Service information: 2005 / R04 Read Before Using This product contains software that is licensed under written license agreements. Your use of such software is subject to the license agreements under which they are provided.
  • Page 3 IBM System Storage SAN04B-R Installation, Service, and User’s Guide Service information: 2005 / R04 GA32-0583-01...
  • Page 4 © Copyright International Business Machines Corporation 2008. US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.

  • Page 5: Second Edition

    Read this first Summary of changes This is the second edition of the IBM System Storage SAN04B-R Installation, Service, and User's Guide. The content changes since the last edition of this publication are noted by a vertical line placed in the left margin beside each change.

  • Page 6: Accessibility Features For The San04B-R

    GUI. Vendor software This product includes certain vendor software that is not covered under the IBM license agreement. IBM makes no representation about the accessibility features of these products. Contact the vendor for the accessibility information about its products.
  • Page 7 Department GZW 9000 South Rita Road Tucson, Arizona 85744-0001 U.S.A. When you send information to IBM, you grant IBM a nonexclusive right to use or distribute the information in any way it believes appropriate without incurring any obligation to you.
  • Page 8 SAN04B-R Installation, Service, and User’s Guide...

  • Page 9: Table Of Contents

    Related accessibility information ....iv IBM and accessibility ..... . iv How to send your comments .
  • Page 10 Items required ......12 Installation instructions ..... 12 Cabling and setting up the router .
  • Page 11 Environmental requirements ....58 Data transmission ranges ..... 59 Memory specifications .
  • Page 12 SAN04B-R Installation, Service, and User’s Guide...

  • Page 13: Figures

    25. Removing the caps from fiber optic cables ..... 52 26. Inserting a fiber optic cable into an SFP module ....53 © Copyright IBM Corp. 2008...
  • Page 14 SAN04B-R Installation, Service, and User’s Guide...

  • Page 15: Tables

    1. Sample caution notices ......xviii 2. Brocade and IBM product and model number matrix ....xxv 3.
  • Page 16 SAN04B-R Installation, Service, and User’s Guide...

  • Page 17: Safety And Environmental Notices

    IBM Systems Safety Notices (G229–9054) publication, which is on the CD-ROM that accompanies this product. The following notices and statements are used in IBM documents. They are listed below in order of increasing severity of potential hazards. Follow the links for more detailed descriptions and examples of the danger, caution, and attention notices in the sections that follow.
  • Page 18 DANGER Overloading a branch circuit is potentially a fire hazard and a shock hazard under certain conditions. To avoid these hazards, ensure that your system electrical requirements do not exceed branch circuit protection requirements. Refer to the information that is provided with your device or the power rating label for electrical specifications.

  • Page 19: Caution Notices

    Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the IBM provided power cord. Do not use the IBM provided power cord for any other product.

  • Page 20: Safety Labels

    Table 1. Sample caution notices If the symbol is... It means... A hazardous electrical condition with less severity than electrical danger. A generally hazardous condition not represented by other safety symbols. A specification of product weight that requires safe lifting practices. The weight range of the product is listed below the graphic, and the graphic and the wording of the caution varies, depending on the weight...

  • Page 21: Attention Notices

    The actual product safety labels may differ from these sample safety labels: DANGER Hazardous voltage, current, or energy levels are present inside any component that has this label attached. Do not open any cover or barrier that contains this label. (L001) DANGER Rack-mounted devices are not to be used as a shelf or work space.

  • Page 22: Rack Safety

    Rack safety Rack installation DANGER Observe the following precautions when working on or around your IT rack system: v Heavy equipment—personal injury or equipment damage might result if mishandled. v Always lower the leveling pads on the rack cabinet. v Always install stabilizer brackets on the rack cabinet. v To avoid hazardous conditions due to uneven mechanical loading, always install the heaviest devices in the bottom of the rack cabinet.

  • Page 23: Rack Relocation (19" Rack)

    Rack relocation (19″ rack) CAUTION: Removing components from the upper positions in the rack cabinet improves rack stability during relocation. Follow these general guidelines whenever you relocate a populated rack cabinet within a room or building: v Reduce the weight of the rack cabinet by removing equipment starting at the top of the rack cabinet.

  • Page 24: Product Recycling And Disposal

    (TI) que reciclen responsablemente sus equipos cuando éstos ya no les sean utiles. IBM dispone de una serie de programas y servicios de devolucion de productos en varios países, a fin de ayudar a los propietarios de equipos a reciclar sus productos de TI.

  • Page 25: Battery Return Program

    United States, go to http://www.ibm.com/ibm/environment/ products/index.shtml or contact your local waste disposal facility. In the United States, IBM has established a return process for reuse, recycling, or proper disposal of used IBM sealed lead acid, nickel cadmium, nickel metal hydride, and other battery packs from IBM equipment.
  • Page 26 For proper collection and treatment, contact your local IBM representative. This notice is provided in accordance with Royal Decree 106/2008 of Spain: The retail price of batteries, accumulators and power cells includes the cost of the environmental management of their waste.

  • Page 27: About This Document

    When you use any of the Brocade documents, you will notice that the model numbers reflect the original Brocade products. Table 2 provides a product matrix for you to use to correlate the Brocade model numbers to the IBM product names and machine types and model numbers.
  • Page 28 Table 2. Brocade and IBM product and model number matrix (continued) IBM machine type and Brocade product name IBM product name model number Brocade 5100 SAN40B-4 2498 Models B40 and 40E Brocade 300 SAN24B-4 2498 Models B24 and 24E Brocade 7500E SAN04B–R...

  • Page 29: Chapter 1. Introducing The San04B-R

    The router can integrate into existing IBM SAN b-type infrastructures, whether router- or switch-based. The FC routing and FCIP capabilities help give you flexibility for a variety of architectures, while extending the reach of the IBM SAN b-type product family.
  • Page 30 Optional features of the router include: v High-Performance Extension Activation, enabling additional routing capabilities ® v IBM Fiber Connection (FICON ) Protocol with Control Unit Port (CUP), designed to provide in-band management capability v FICON Accelerator, designed to support secure data movement across enterprise...

  • Page 31: Upgrade License Features

    Upgrade license features The following table lists the features for the base model router and the additional features supported on a router with additional licenses. Table 3. Capabilities of base model router and router capabilities with upgrade license Base model router, without Router with upgrade Feature upgrade license...

  • Page 32: Port Side Of The Router

    Port side of the router Figure 1 shows the port side of the router. This side includes sixteen Fibre Channel ports, two management ports, two Ethernet ports, and a number of light-emitting diodes (LEDs) for monitoring system and port status. See “LEDs on the port side of the router”...

  • Page 33: Management Ports

    1-, 2-, or 4-Gbps. The ports are able to auto-negotiate to the maximum link speed. A number of different small form-factor pluggable (SFP) optical transceivers are compatible with these ports. Contact your IBM representative for more information on SFPs for this product.

  • Page 34: Nonport Side Of The Router

    Supported connectivity Specific details on supported operating systems, servers, and devices, storage products attachability, SAN connectivity products, and configuration options can be found in the interoperability matrices at the following web site: www.ibm.com/ servers/storage/support/san. SAN04B-R Installation, Service, and User’s Guide...

  • Page 35: Supported Optional Features

    IP ports up to 1 Gbps v FICON with CUP Activation–designed to provide in-band management of ® supported SAN b-type switch, router and director products with IBM zSeries products ® v FICON Accelerator Activation–supports FICON Emulation for IBM z/OS v Advanced Performance Monitor–Performance Monitoring provides the capability...
  • Page 36 SAN04B-R Installation, Service, and User’s Guide...

  • Page 37: Chapter 2. Installing And Configuring The Router

    Note: If any items are damaged or missing, within the United States and Canada, contact the IBM Quality Hotline toll-free 1-800-442-6773 or direct dial in other locations: 770-858-8459. v One SAN04B-R, composed of: –...

  • Page 38: Installation And Safety Considerations

    Installation and safety considerations Use this section to prepare your site for a safe and successful installation. The physical installation of the router must be completed by qualified service personnel. Attention: Read the “Safety and environmental notices” on page xv before attempting any installation, maintenance, or service procedures.

  • Page 39: Electrical Requirements

    Electrical requirements For successful installation and operation of the router, ensure that the following electrical requirements are met. Ensure that two dedicated electrical branch circuits with the following characteristics are available: v Primary ac input 100-240 V ac, 47 to 63 Hz (the router autosenses input voltage) v Correctly wired primary outlets, with circuit protected by a circuit breaker and grounded in accordance with local electrical codes v Adequate supply circuit, line fusing, and wire size, as specified by the electrical...

  • Page 40: Installing The Router In A Cabinet

    Installing the router in a cabinet Attention: Refer to “Rack safety” on page xx for danger and caution notices related to rack and cabinet installations. You can install the rack mount kit in only one way in a cabinet, with the port side of the router able to slide out of the exhaust-air side of the cabinet.

  • Page 41: Rack Assembly

    Outer Slide EIA Rack Rail Inner Slide Detail A Front of Switch Detail A SJ000153 Figure 3. Rack assembly 1. Unpack the rack-mount kit and verify that all ordered items and parts are present and undamaged. See Table 6 for a list of parts and the quantities supplied.
  • Page 42 2. Separate the inner and outer slides. a. Open one of the slides until the lock engages. b. Press the lock release lever ( 1 in Figure 4) and remove the inner rail from the outer rail. SJ000046 Figure 4. Separating the inner and outer rails. c.
  • Page 43 Front SJ000047 Figure 5. Mounting the moving portion of the slide and mounting brackets to the router c. Repeat step 3a on page 14 and step 3b on page 14 for the second inner rail on the other side of the router chassis. 4.
  • Page 44 SJ000048 Figure 6. Mounting the fixed portion of the rail and the locking brackets to the rack 6. Install the outer (larger) slides in the rack, as shown in Figure 6. a. At the desired height, install the five M5 nut clips 5 . Put three M5 nut clips in the front of the rack and two in the back.
  • Page 45 SJ000049 Figure 7. Inserting slides into the rack rails b. Check the alignment of the slides by sliding the router in and out of the rack. Any difficulty moving the router indicates lateral stress or misalignment. If this situation occurs, adjust the slide positions until the movement is smooth. 8.

  • Page 46: Cabling And Setting Up The Router

    Cabling and setting up the router You must configure the router before it can operate within a network and fabric. This section provides the basic steps required for the initial setup of the router. For instructions on configuring the router to operate in a network containing switches from other vendors, refer to the Fabric OS Administrator’s Guide.

  • Page 47: Providing Power To The Router

    v “Configuring FCIP and Fibre Channel routing services” on page 25 v “Verifying correct operation of the router” on page 25 v “Backing up the configuration” on page 26 Attention: Do not connect the router to the network until the IP address is correctly set.
  • Page 48 2. Connect the serial cable to the serial port on the switch and to an RS-232 serial port on the workstation. If the serial port on the workstation is RJ-45 instead of RS-232, remove the adapter on the end of the serial cable and insert the exposed RJ-45 connector into the RJ-45 serial port on the workstation.

  • Page 49: Installing Sfp Transceivers

    Creating an Ethernet connection and logging in Create an Ethernet connection to the router by completing the following steps: 1. Remove the plug from the Ethernet port (see 3 in Figure 1 on page 4 2. Insert one end of an Ethernet cable into the Ethernet port. 3.

  • Page 50: Connecting Cables

    2. Position a transceiver so that it is oriented correctly and insert it into a port until it is firmly seated and the latching mechanism clicks. 3. Repeat for the remaining ports, as required. Connecting cables Attention: A 50-micron cable should not be bent to a radius less than 5 cm (2 in.) under full tensile load and 3 cm (1.2 in.) with no tensile load.
  • Page 51 switch:admin> date "0927123007" Thu Sep 27 12:30:00 UTC 2007 switch:admin> Setting time zones You can set the time zone for a switch by name. You can specify the setting using country and city or time zone parameters. If the time zone is not set with the new options, the switch retains the offset time zone settings.
  • Page 52 1. Type the tsTimeZone command as follows: switch:admin> tstimezone --interactive 2. You are prompted to select a general location. Please identify a location so that time zone rules can be set correctly. 3. Enter the appropriate number or Ctrl-D to quit. 4.

  • Page 53: Configuring Fcip And Fibre Channel Routing Services

    switch:admin> tsclockserver 132.163.135.131 switch:admin> The following example shows how to set up more than one NTP server using a DNS name: switch:admin> tsclockserver "10.32.170.1;10.32.170.2;ntp.localdomain.net" Updating Clock Server configuration...done. Updated with the NTP servers Changes to the clock server value on the principal or primary FCS switch are propagated to all switches in the fabric.

  • Page 54: Backing Up The Configuration

    switch:admin> switchshow switchName: sw7500 switchType: 46.2 switchState: Online switchMode: Native switchRole: Subordinate switchDomain: 49 switchId: fffc31 switchWwn: 10:00:00:05:1e:37:0d:a5 zoning: ON (cfg_em) switchBeacon: OFF FC Router BB Fabric ID: 1 Area Port Media Speed State ============================== 0 0 id N4 Online E-Port 10:00:00:60:69:e4:20:3e "sw48000" (upstre am)(Trunk master) 1 1 id N4 Online 2 2 id No Module...

  • Page 55: Viewing, Adding, And Removing License Keys (Optional)

    IBM. Contact your IBM representative for more information. You will need to supply IBM with the WWN to obtain a transaction key, which is sent in a paperpack. To obtain the license key, follow the instructions included in the paperpack. The transaction key and the router wwn or product serial number are required to obtain the license key.

  • Page 56: Removing A License Key

    The license key is a string of approximately 16 uppercase and lowercase letters and digits. Case is significant. The key is an encrypted form of the system WWN and the products licensed to run on this system. 3. Enter the licenseAdd command, followed by the license key enclosed in quotation marks, as shown in the following example.

  • Page 57: Chapter 3. Managing The Router And Monitoring Components

    For information, see the Fabric OS MIB connection Reference. Management Server Ethernet or serial management port Native in-band interface For information, see the Fabric OS Administrator's connection (over HBA only) Guide and the Fabric OS Command Reference. © Copyright IBM Corp. 2008...

  • Page 58: Interpreting Led Activity

    Interpreting LED activity System activity and status can be determined through the activity of the LEDs on the router. LEDs are located on both the port side and the nonport side of the router. There are three possible LED states: no light, a steady light, and a flashing light. The steady lights and flashing lights can be green or amber.
  • Page 59 IOIOI IOIOI scale: 5/1 6" = 1" scale: 3/4" = 1" Figure 8. LEDs and other components on the port side of the router Switch chassis Ethernet link LED System status LED Ethernet management port Power status LED Fibre Channel ports 0 - 3 Console port Port 0 status LED IP address, WWN, and...

  • Page 60: Power Status Led Patterns

    Check the failure indicated on the system console. normal and does not indicate a fault. If the problem does not resolve, contact your IBM representative. Flashing Attention is required. A number Check the management interface and the error log for details on...

  • Page 61: Ethernet Management Port Led Patterns

    (enabled) status. Fast-flashing amber SFP or port is faulty. Replace the SFP. (on 1/2 second; Reset the port. If the problem does not resolve, then off 1/2 second) contact IBM. Chapter 3. Managing the router and monitoring components...

  • Page 62: Leds On The Nonport Side Of The Router

    LEDs on the nonport side of the router The LEDs on the nonport side of the router provide status information for the individual power supplies and the fan assemblies. Figure 9 shows the location of these LEDs and other components on the nonport side of the router. scale: 3/4"...

  • Page 63: Power Supply Status Led Patterns

    Power supply status LED patterns The power supply status LEDs ( 6 in Figure 9 on page 34) on each power supply indicate the status of the individual power supplies. Table 13 describes the meaning of different displays of the power supply LEDs and recommended action, if any. Table 13.

  • Page 64: Interpreting Post Results

    Interpreting POST results POST is a system check that is performed each time the router is powered on, rebooted, or reset, and during which the LEDs flash different colors. To determine whether POST completed successfully and whether any errors were detected: v Verify that the LEDs on the router indicate that all components are healthy (LED patterns are described in the tables in “Interpreting LED activity”...

  • Page 65: Diagnostics And Troubleshooting

    Diagnostics and troubleshooting The router is designed for high availability and low failure. It does not require any regular physical maintenance. Diagnostic tests In addition to POST, Fabric OS includes diagnostic tests to help you troubleshoot the hardware and firmware. This includes tests of internal connections and circuitry, fixed media, and the transceivers and cables in use.

  • Page 66: Powering Off The Router

    v Enter the psShow command at the command prompt to display power supply status as shown in the example below: sw7500:admin> psshow Power Supply #1 is OK V10529, TQ2H0000118 ,60-0300031-01,X2, ,SP640 ,2X,TQ2H0000 Power Supply #2 is OK V10529, TQ2H0000121 ,60-0300031-01,X2, ,SP640 ,2X,TQ2H0000 sw7500:admin>...

  • Page 67: Chapter 4. Removing And Replacing Crus

    You can also use the switchStatusShow command to verify the status of the power supplies. Refer to the Fabric OS Command Reference for more information on this command. © Copyright IBM Corp. 2008...

  • Page 68: Time Required

    scale: 1/8" = 1" x im ti n s c re g to w le fo r ra c /6 4 in . scale: 5/16" = 1" Figure 10. Power supply locations 1 Router chassis 3 Power supply #2 2 Back (nonport side) of router 4 Power supply #1 Time required Less than 2 minutes...

  • Page 69: Procedure

    Procedure Complete the following steps to remove and replace a power supply. 1. To leave the router in service while you replace a power supply, verify that the other power supply (the one not being replaced) has been powered on for at least four seconds and has a green LED.

  • Page 70: Replacing A Fan Assembly

    7. Connect the power cord to the power supply and then press the AC power switch to ″|″ (on). 8. Verify that the LED on the new power supply displays a steady green light while the router is operating. If the LED is not green, ensure that the power supply is securely installed, the power plug is secure, and the primary power is available.

  • Page 71: Time Required

    1 Router chassis 5 Fan assembly #2 2 Nonport (rear) side of router 6 Fan assembly #1 3 Fan assembly #3 Time required Less than 2 minutes. Items required v New fan assembly v Phillips screwdriver DANGER Hazardous voltage, current, or energy levels are present inside any component that has this label attached.

  • Page 72: Removing, And Installing Sfps

    Removing, and installing SFPs Note: For a listing of SFPs compatible with this product: v Go to the IBM SAN Support web page at www.ibm.com/servers/storage/ support/san v Select the product family, Storage Area Network (SAN), from the Product family list.

  • Page 73: Time Required

    Follow the instructions in “Removing SFP modules” on page 46 and then “Installing an SFP” on page 49 to replace faulty SFPs. These instructions are intended to provide steps that will work for most types of compatible SFPs. For instructions that are specific to the exact type of SFP, refer to the manufacturer’s documentation.

  • Page 74: Fiber Optic Cable Lever And Latches

    CAUTION: Data processing environments can contain equipment transmitting on system links with laser modules that operate at greater than Class 1 power levels. For this reason, never look into the end of an optical fiber cable or open receptacle. (C027) To remove and replace SFP modules from the router, complete the appropriate steps below, depending on the type of SFP used.
  • Page 75 Figure 17. Removing a fiber optic cable 4. Replace the protective caps on the cable ends. 5. If you are leaving the SFP in place, replace the protective cap on the SFP. Removing a wire bale type SFP: Follow the steps below to remove a wire bale type SFP.

  • Page 76: Unlocking The Sfp Module Latch, Wire Bale Type

    Open Bale Bale Figure 18. Unlocking the SFP module latch, wire bale type 2. Grasping it by the bale, gently but firmly pull the transceiver out of the port (see 2 in Figure 18). 3. Replace the protective cover on the SFP module. 4.

  • Page 77: Unlocking The Sfp Module Latch, Plastic Tab Type

    Note: If there is not enough room because of an adjacent cable and SFP, you may need to temporarily remove the adjacent cable. Plastic module Figure 19. Unlocking the SFP module latch, plastic tab type 2. Using the plastic tab, pull the SFP from the port (see Figure 20). Figure 20.

  • Page 78: Removing The Protective Cap From A Wire Bale Type Sfp

    3. Remove the protective cap from the SFP module, as shown in Figure 21 and Figure 22. Save the cap for future use. Wire Protective module Figure 21. Removing the protective cap from a wire bale type SFP Protective cap SFP module Figure 22.
  • Page 79 Bale Close Bale Figure 23. Installing a wire bale type SFP Chapter 4. Removing and replacing CRUs...
  • Page 80 Figure 24. Installing a plastic tab type SFP 5. For SFPs with wire bales, close the bale to lock it in place (see as shown in 2 in Figure 23 on page 51. 6. Repeat this procedure for the remaining SFPs and ports, as required. Installing fiber optic cables: Attention: Do not bend a fibre cable to a radius less than 5 cm (2 in.);...

  • Page 81: Replacing The Router

    Replacing the router If any of the internal circuitry fails within the router, the entire unit must be replaced. Contact IBM technical support for assistance with ordering the replacement. Within the United States call 1-800-IBMSERV (1-800-426-7378). For support outside the United States, you can find the service number at: http://www.ibm.com/planetwide/.

  • Page 82: Procedure

    (Refer to “Installing the router in a cabinet” on page 12 for illustrations and complete rack mount instructions.) 10. Set the router aside for later return to IBM, following the instructions included with the replacement router. Installing the CRU router Follow these steps to install the replacement for the router you removed earlier.
  • Page 83 IBM service system. Once you have installed the replacement router, follow the steps below to change the serial number displayed through the router or fabric management program.
  • Page 84 SAN04B-R Installation, Service, and User’s Guide...

  • Page 85: Appendix. Product Specifications

    Table 15. Switch dimensions Dimension Value Height 1U = 42.44 mm (1.67 in.) Depth 635 mm (25.0 inches) Width 429 mm (16.89 in.) Weight (with two power supplies and three 12.43 kg (27.4 lbs) fan assemblies installed) © Copyright IBM Corp. 2008...

  • Page 86: Power Supply

    Power supply The power supplies are universal and capable of functioning worldwide without voltage jumpers or switches. They meet IEC 61000-4-5 surge voltage requirements and are autoranging in terms of accommodating input voltages and line frequencies. Each power supply has a built-in fan for cooling, pushing air towards the port side of the router.

  • Page 87: Data Transmission Ranges

    Data transmission ranges Table 18 provides the data transmission ranges for different cable types and port speeds. Table 18. Data transmission ranges by cable type and port speed Short Long Extended Long Cable Size Wavelength Wavelength Wavelength Port Speed (microns) (SWL) (LWL) (ELWL)

  • Page 88: Parts List (Crus)

    Refer to Figure 1 on page 4 and Figure 2 on page 6 for the location of the parts listed below. Part numbers are subject to change, particularly for SFP transceivers. Contact your IBM representative for current information on part numbers for SFPs to meet your needs.

  • Page 89: Notices

    The materials at those web sites are not part of the materials for this IBM product and use of those web sites is at your own risk.
  • Page 90 IBM has not tested those products and cannot confirm the accuracy of performance, compatibility or any other claims related to non-IBM products. Questions on the capabilities of non-IBM products should be addressed to the suppliers of those products.

  • Page 91: Trademarks

    IBM, the IBM logo, and ibm.com are trademarks or registered trademarks of International Business Machines Corporation in the United States, other countries, or both. A complete and current list of other IBM trademarks is available on the Web at http://www.ibm.com/legal/copytrade.shtml Brocade and SilkWorm are trademarks of Brocade Communications Systems, Inc.,...

  • Page 92: Electronic Emission Notices

    Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. IBM is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment.

  • Page 93: Germany Electromagnetic Compatibility Directive

    EU-Mitgliedsstaaten und hält die Grenzwerte der EN 55022 Klasse A ein. Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben. Des Weiteren dürfen auch nur von der IBM empfohlene Kabel angeschlossen werden. IBM übernimmt keine Verantwortung für die Einhaltung der Schutzanforderungen, wenn das Produkt ohne Zustimmung der IBM verändert bzw.

  • Page 94: People's Republic Of China Class A Electronic Emission Statement

    People’s Republic of China Class A Electronic Emission Statement Japan VCCI Class A ITE Electronic Emission Statement Korea Class A Electronic Emission Statement SAN04B-R Installation, Service, and User’s Guide...

  • Page 95: Index

    Ethernet connection FICON accelerator 2 logging in 21 FICON Accelerator 7 CRU status FICON Activation 7 CLI commands 37 FICON with CUP 2, 7 determining 37 high-performance extension activation 2 monitoring 37 High-performance extension activation 7 © Copyright IBM Corp. 2008...
  • Page 96 5 battery xxiii setting 20 caution xvii items included 9 danger xv environmental xv, xxii general 61 IBM 61 labels, safety xviii patents 61 safety xv location 30, 34 types xv LED patterns notices ,danger xv Ethernet management port 33...
  • Page 97 product specifications 57 pull-out tab 4 optional features IP address 5 Advanced Performance Monitor 7 serial number 5 FICON Accelerator 7 world wide name (WWN) 5 FICON Activation 7 FICON with CUP 7 High-performance extension activation 7 Trunking Activation 7 rack safety xx rack mount kit 13...
  • Page 98 serial port 4 setting date 22 IP address 20 time 22 time zones 23 setting the IP address 20 setup required items 18 router 18 SFPs installing 21 supported connectivity 6 supported features 7 synchronizing local time 24 system status LED 32 LED patterns 32 terminal emulator applications 19...
  • Page 99 When you send comments to IBM, you grant IBM a nonexclusive right to use or distribute your comments in any way it believes appropriate without incurring any obligation to you. IBM or any other organizations will only use the personal information that you supply to contact you about the issues that you state on this form.
  • Page 100 Readers’ Comments — We’d Like to Hear from You Cut or Fold Along Line GA32-0583-01 Fold and Tape Please do not staple Fold and Tape _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ NO POSTAGE NECESSARY IF MAILED IN THE...
  • Page 102 Part Number: 45W1697 Printed in USA GA32-0583-01...
