Summary of Contents for TRENDnet TV-IP110WN

  • Page 2: Preface

    REFACE Thank you for purchasing the TV-IP110WN Wireless N Internet Camera Server, a powerful and high-quality image network camera. The camera can be installed as a standalone system within your application environment easily and quickly, and supports remote management function so that you can access and control it using a Web browser on your computer.

  • Page 3: Table Of Contents

    Contents PREFACE ................1 CHAPTER 1...............4 INTRODUCTION TO YOUR CAMERA ......4 1.1 C ..........4 HECKING THE ACKAGE ONTENTS 1.2 G ..........5 ETTING TO AMERA 1.3 F ............7 EATURES AND ENEFITS 1.4 S ...............8 YSTEM EQUIREMENT CHAPTER 2...............9 HARDWARE INSTALLAT ION .........9 2.1 I ..........9 NSTALLING THE...
  • Page 4 4.10 I ................56 NFORMATION CHAPTER 5..............57 SECURVIEW™ PRO SOFT WARE ......... 57 5.1 I .................58 NSTALLATION 5.2 U ™ P ............61 SING ECUR CHAPTER 6..............92 HOW TO ACCESS THE CAMERA BEHIND A ROUTER ..92 CHAPTER 7..............98 APPENDIX ..............

  • Page 5: Chapter 1

    HAPTER NTRODUCTION AMERA 1.1 Checking the Package Contents Check the items contained in the package carefully. You should have the following: 1 x TV-IP110WN  1 x CD-ROM (Utility & User’s Guide)  1 x Multi-Language Quick Installation Guide ...

  • Page 6: Getting To Know Your Camera

    Getting to Know Your Camera - 5 -...
  • Page 7 Power LED: A steady orange light indicates the camera is powered Link LED: A flash green light indicates the camera’s network connection correctly. Lens: Adjust the focus by rotate outside of the Lens. WPS button: A quick connection button to your encrypted wireless network Detachable Antenna: Adjust the antenna position to get the maximum signal.

  • Page 8: Features And Benefits

    1.3 Features and Benefits  Surveillance Supported The camera supports “nightshot mode” to deliver clearer images in the dark environment. Enable motion detection and setup automated email alerts and upload the still image into FTP.  Remote Control Supported By using a standard Web browser or the included SecurView Pro software application, the administrator can easily change the configuration of the camera via Intranet or Internet.

  • Page 9: System Requirement

    1.4 System Requirement  Networking LAN: 10Base-T Ethernet or 100Base-TX Fast Ethernet, Auto-MDIX WLAN: Based on IEEE 802.11n technology, IEEE 802.11g/b  Accessing the Camera using Web Browser Platform: Microsoft® Windows® 7/Vista/XP CPU: Intel Pentium III 800MHz or above RAM: 512MB Resolution: 800x600 or above...

  • Page 10: Chapter 2

    HAPTER ARDWARE NSTALLATION 2.1 Installing the Camera Stand The camera comes with a camera stand, which uses a swivel ball screw head to lock to the camera’s screw hole. When the camera stand is attached, you can place the camera anywhere by mounting the camera through the three screw holes located in the base of the camera stand.

  • Page 11: Connecting The Camera To Lan

    2.2 Connecting the Camera to LAN Use the provided Ethernet cable to connect the camera to your local area network (LAN). When you connect the power adapter, the camera is powered on automatically. You can verify the power status from the Power LED (amber) on the front panel of the camera.

  • Page 12: Applications Of The Camera

    2.3 Applications of the Camera The camera can be applied in multiple applications, including:  Monitor local and remote places and objects via Internet or Intranet  Capture still images and video clips remotely  Upload images or send email messages with the still images attached The following diagram explains one of the typical applications for your camera and provides a basic example for installing the camera.

  • Page 13: Chapter 3

    HAPTER CCESSING THE AMERA 3.1 Using IP Setup The camera comes with a conveniently utility, IP Setup, which is included in the Installation CD-ROM, allowing you to search the camera on your network easily. 1. Insert the Installation CD-ROM into your computer’s CD-ROM drive to initiate the Auto-Run program.
  • Page 14 2. Click the IP Setup from the Auto-Run menu screen. Then IP Setup Wizard will appear. Click “Next” when the Welcome to the IPSetup Setup Wizard appears. 3. Click “Browse” to choose the desired destination location. By default, the destination location is C:\Program Files\TRENDnet\IPSetup. Then Click “Next”. - 13 -...
  • Page 15 4. Click “Next” to confirm the IPSetup software to be installed to the computer. 5. When the Installation Complete window appears, click “Finish”. - 14 -...
  • Page 16 6. After installing the IPSetup utility, the application is automatically installed to your computer, and creates a folder in “Start \Program\TRENDnet\IPSetup”. 7. Click Start > Programs > TRENDnet > IPSetup, and then click IPSetup 8. The IPSetup window will appear. It will search the Camera within the same network.
  • Page 17 Camera Display Area: It shows the connected camera(s) within the same network. By default, the IP setting on the Camera is set up DHCP. If you have DHCP server, the camera will automatic get the IP address from DHCP server. If you do not have DHCP server on your network, it will show the default IP as 192.168.10.30.

  • Page 18: Accessing To The Camera

    3.2 Accessing to the Camera 1. Open the Web browser on your computer (example showed in the User’s Guide is based on the Internet Explorer) 2. Type the Camera IP address that DHCP server assigned in the web browser URL (e.g. 192.168.10.30) and then press [Enter]. 3.
  • Page 19 After you login into the Web Configuration of the camera, the main page will appear as below: Camera Information Zoom In Live View/ Setup Function Live View Image The main page of the Web Configuration provides you with many useful information and functions, including: –...
  • Page 20 –  Live View/Setup Switch Click Setup to configure the camera. Please refer to Chapter 4 for more information. –  Function Use these buttons to control the video functions. Manual Record allows you to record and save a video clip. Snapshot allows you to capture and save a still image.

  • Page 21: Configuring The Ip Address Of The Pc

    3.3 Configuring the IP Address of the PC If you are failed to access to the camera, please check the IP address of your computer. When you connect the camera to your computer directly to proceed with configuration of the camera, you need to set up the IP addresses to be in the same segment for the two devices to communicate.

  • Page 22: Chapter 4

    HAPTER ONFIGURATION OF THE CAMERA 4.1 Using the Web Configuration You can access and manage the camera through the Web browser and the provided software application SecurView Pro. This chapter describes the Web Configuration, and guides you through the configuration of the camera by using the web browser.

  • Page 23: Using Smart Wizard

    4.2 Using Smart Wizard The camera’s Smart Wizard lets you configure your camera easily and quickly. The wizard will guide you through the necessary settings with detailed instructions on each step. To start the wizard, click Smart Wizard in the left menu bar. - 22 -...
  • Page 24 The following screen will pop up. Step 1. Camera Settings Enter Camera name, Location, New Admin password and enter again to confirm Admin password - 23 -...
  • Page 25 Step 2. IP Settings Select the IP setting according to your network: DHCP, Static IP, or PPPoE. Step 3. Email Settings Enter the required information to be able to send email with image. - 24 -...
  • Page 26 Step 4. Wireless Networking Click Site Survey to select the SSID and then complete the required settings. - 25 -...
  • Page 27 Step 5. Confirm Settings This step shows all the setting information. This step shows the configuration of your camera. When you confirm the settings, click Apply to finish the wizard and reboot the camera. Click Prev to go back to the previous step(s) and change the settings; or click Cancel to end the wizard and discard the changes.

  • Page 28: Basic Setup

    4.3 Basic Setup The Basic menu contains three sub-menus that provide the system settings for the camera, such as the Camera Name, Location, Date & Time, and User management. - 27 -...
  • Page 29 Basic >> System  Basic - Camera Name: Enter a descriptive name for the camera. - Location: Enter a descriptive name for the location used by the camera.  Indication LED This item allows you to set the LED illumination as desired. There are two options: Normal and OFF.
  • Page 30  Date & Time - TimeZone: Select the proper time zone for the region from the pull- down menu. - Synchronize with PC: Select this option and the date & time settings of the camera will be synchronized with the connected computer. - Synchronize with NTP Server: Select this option and the time will be synchronized with the NTP Server.
  • Page 31  General User - User Name: Enter the user’s name you want to add to use the camera. - Password: Enter the password for the new user. When you are finished, click Add/Modify to add the new user to the camera.

  • Page 32: Network Settings

    4.4 Network Settings The Network menu contains three sub-menus that provide the network settings for the camera, such as the IP Setting, DDNS Setting, IP Filter, and wireless network. - 31 -...
  • Page 33 Network >> Network  IP Setting This item allows you to select the IP address mode and set up the related configuration. - DHCP: The default IP Setting mode was set as DHCP. Select this option when your network uses the DHCP server. When the camera starts up, it will be assigned an IP address from the DHCP server automatically.
  • Page 34 assigned from your DHCP server. If you do not have a DHCP server in your network, the IP address will be assigned to 192.168.10.30. Subnet Mask Enter the Subnet Mask of the camera. The default setting is 255.255.255.0. Default Gateway Enter the Default Gateway of the camera.
  • Page 35 Network >> IP Filter The IP Filter setting allows the administrator of the camera to limit the users within a certain range of IP addresses to access the camera.  Start/End IP Address Assign a range of IP addresses that are not allowed to access the camera by entering the Start IP address and End IP address.
  • Page 36 The camera supports WLAN while you use the wireless network. Select the Enable option to enable this feature. - Network ID (SSID}: The default SSID setting is “TRENDnet”. To connect the camera to a specified access point, set a SSID for the camera to correspond with the access point’s ESS-ID.
  • Page 37 Click Site Survey to display the available wireless networks, so that you can easily connect to one of the listed wireless networks. - Wireless Mode: Select the type of wireless communication for the camera: Infrastructure or Ad-Hoc. - Channel: Select the appropriate channel from the list. - Authentication: Select the authentication method to secure the camera from being used by unauthorized user: Open, Shared-key, WPA-PSK, and WPA2-PSK.
  • Page 38 If you select Open or Shared-key as the Authentication mode, you need to complete the following settings: Encryption: Select the WEP option to enable the data encryption feature to secure the camera within the wireless network. Format: Once you enable the Encryption feature, you need to determine the encryption format by selecting ASCII or HEX.
  • Page 39 Network >> Wireless >> WPS Setting WPS (Wi-Fi Protected Setup) sets a new standard of Wi-Fi security, providing a simplified secure network setup solution for the end users. Once the required settings have been completed, your wireless network can be protected by simply pressing the WPS button on the camera. ...
  • Page 40 - PBC Mode: The PBC (Push Button Configuration) mode builds the connection by scanning the devices in the wireless network. Once you press the camera’s WPS button, it starts to scan the WPS devices in the wireless network, and then you can build the WPS connection by clicking the Connect button.

  • Page 41: Setting Up Video

    4.5 Setting up Video The Video contains three sub-menus that provide the video and settings for the camera. - 40 -...
  • Page 42 Video >> Camera  Image Setting - Brightness: Adjust the brightness level from 0 ~ 100. - Contrast: Adjust the contrast level from 0 ~ 100. - Saturation: Adjust the colors level from 0 ~ 100 Click Default to restore the default settings of the three options above.
  • Page 43  MJPEG - Video Resolution: Select the desired video resolution from the three formats: VGA, QVGA and QQVGA. The higher setting (VGA) obtains better video quality while it uses more resource within your network. - Video Quality: Select the desired image quality from five levels: Lowest, Low, Medium, High, and Highest.

  • Page 44: Event Server Configuration

    4.6 Event Server Configuration The Event Server menu contains three sub-menus that allow you to send notification to NVR, upload images to FTP or send images to emails. When you complete the required settings of HTTP, FTP or Email, click Test to verify the configuration.
  • Page 45 Event Server Setting>> HTTP  HTTP Notify For Motion Trigger Send the query parameter via an HTTP notification when an event is triggered. - Host: Enter the IP of the HTTP server - Port: Enter the Port number of the HTTP server - User Name: Enter the username of the HTTP server - Password: Enter the password of the HTTP server - Query: Enter the query parameter for the request if necessary...
  • Page 46 Event Server Setting>> FTP  FTP - Host Address: Enter the IP address of the target FTP server. - Port Number: Enter the port number used for the FTP server. - User Name: Enter the user name to login into the FTP server. - Password: Enter the password to login into the FTP server.
  • Page 47 Event Server Setting >> Email  Email - SMTP Server Address: Enter the mail server address. For example, mymail.com. - Sender Email Address: Enter the email address of the user who will send the email. For example, John@mymail.com. - Sender User Name: Enter the user name to login the mail server. - Sender Password: Enter the password to login the mail server.

  • Page 48: Motion Detect

    4.7 Motion Detect The Motion Detect menu contains the command and option that allow you to enable and set up the motion detection feature of the camera. The camera provides two detecting areas. To enable the detecting area, select Window 1 or 2 from the pull-down list, and then select Enable.
  • Page 49 - Name: Assign a name to the detecting area. - Threshold: Move the slide bar to adjust the level for detecting motion to record video. Click Save once done the setting. - 48 -...

  • Page 50: Event Config

    4.8 Event Config The Event Config menu contains four sub-menus that provide the commands to configure event profiles. Event Configuration >> General Setting - 49 -...
  • Page 51 - Snapshot/Recording Filename Prefix: You can assign a given prefix to each new captured file. Otherwise, leave this option blank to use the default setting. Event Configuration >> Arrange Schedule Profile This sub-menu displays the scheduled profile(s). To customize the profile, click Add and then enter a descriptive name for the profile in the prompt dialog window.
  • Page 52 - Profile Name: Display the profile name that you select in the Schedule Profiles list. - Weekdays: Select the weekday(s) that you want to separately assign in the schedule profile. The weekday that has been assigned will be displayed with green color. - Time List: Display the time period that you have assigned within the selected weekday.
  • Page 53 Event Configuration >> Motion Detect Trigger Select the Enable option to enable the trigger function of the camera, so that you can send captured images within the detecting area to the FTP server and email receiver. You have to configure corresponding settings, such as FTP server and email server, to enable this feature.
  • Page 54 Event Configuration >> Schedule Trigger You can separately configure the schedule for trigger function of the camera by Email or FTP. Select the Enable option on each item, and then select a Schedule Profile from the pull-down list and set the Interval time. - 53 -...

  • Page 55: Tools

    4.9 Tools The Tools menu provides the commands that allow you to restart or reset the camera. You can also backup and restore your configuration, and upgrade the firmware for the camera. - 54 -...
  • Page 56  Factory Reset Click Reset to restore all factory default settings for the camera.  System Reboot Click Reboot to restart the camera just like turning the device off and on. The camera configuration will be retained after rebooting.  Configuration You can save your camera configuration as a backup file on your computer.

  • Page 57: Information

    4.10 Information The Information menu displays the current configuration and events log of the camera.  Device Info Display the Basic, Video, Network, and Wireless settings of the camera.  System Log The Logs table displays the events log recorded by the system. - 56 -...

  • Page 58: Chapter 5

    HAPTER ™ P ECUR OFTWARE This chapter describes detailed instructions on using SecurView Pro, a customized software application with a user-friendly interface that allows you to access your cameras. The Software can monitor and record up to 36 cameras. It also let you change some basic settings of the camera, such as schedule profiles and motion detecting areas.

  • Page 59: Installation

    5.1 Installation 1. Insert the Installation CD-ROM into your computer’s CD-ROM drive to initiate the Auto-Run program. 2. Click the SecurView Pro from the Auto-Run menu screen. NOTE: To use SecurView Pro, you must have Microsoft .NET Framework 2.0 installed in the computer. The setup wizard will detect it and, if the program is not installed yet, it will ask you to install it during the process of installing SecurView™...
  • Page 60 3. Then SecurView Pro Setup Wizard will appear. Click “Install”. 4. Wait until the program finish the installation. By default, the destination location is C:\Program Files\TRENDnet\SecurView Pro. - 59 -...
  • Page 61 5. Click “Finish” to finish the installation. 6. After installing the SecurView Pro, the application is automatically installed to your computer, and creates a folder in “ Start \Program\TRENDnet\SecurView Pro ”. - 60 -...

  • Page 62: Using Securview™ Pro

    5.2 Using SecurView™ Pro 5.2.1 Launch the Program To start SecurView Pro, click Start > All Programs > TRENDnet >SecurView Pro > SecurView Pro. You can also start the program by double-click the SecurView Pro icon on your desktop. On the login window, enter the User name/Password and click OK to login.
  • Page 63 5.2.2 Main Window and Features When you start and login to SecurView Pro, the Main window will display as below:       The Main window provides you with the information on operating the system, as well as the control panel such as the Quick Launch buttons, and so on.
  • Page 64  Quick Launch Buttons are located below the Live View Window, providing you with the following quick-launch functions: Button Function Logout : To log out the SecurView Pro program Close: To close the SecurView Pro program Restore Recording Type: Restore all recording type to current camera’s setting All Continuous Recording: Continuous recording on all cameras...
  • Page 65  Camera View Mode buttons in this area allow you to switch the camera view mode. Buttons Functions Display the connected camera(s) in a single camera view mode. Display the connected camera(s) in a quad view mode. Display the connected camera(s) in a 3 x 3 grid view mode. Display the connected camera(s) in a 13-camera view mode using a split window.
  • Page 66  Camera List displays the status of the connected cameras. If multiple cameras are connected, you can switch to the live view of each camera by simply selecting the camera from the list.  eMap allows you to select the desired camera to the view from the map easily.
  • Page 67 5.2.3 Manage the Cameras Before adding the cameras, please setup the recording setting first.  Configure Recording Settings 1. Click the button and then select Record Setting. 2. Default path is C:\, click Browse and select the desire directory then click Save to complete the configuration. To change the time interval for recording, select time from the pull-down menu.
  • Page 68  Add a Camera 1. Click the button and select Device Setting to display the Device Setting window. 2. Click New. - 67 -...
  • Page 69 3. Click on Search, all cameras that’s connected to your network would appear. 4. Select the camera you would like to add and then click Add. - 68 -...
  • Page 70 5. The information of the camera will display on the screen. It will auto detect the IP address/port number and display the stream type of the camera. Please type in the correct user name and password, then select Preview to view live image. 6.
  • Page 71 Schedule: Records stream video by schedule. You can setup the schedule by click Add Schedule here. Click on New to create a new schedule and select the time to record. Click on Save when finish. Motion: Record video by Motion Detection. Motion detection recording required to setup a motion detection area.
  • Page 72 To use motion detection record, please enable the detection areas first. Click on Motion detection area to setup Enable motion detection windows, set up the senstivity and click on Save. Motion by Schedule: same requirement as Motion & Schedule recording. Digital Input: Recording triggered when there I/O port is triggered.
  • Page 73 After all recording methods are configured, click Save to apply the settings. 7. Camera list will appear with recording type notification. - 72 -...
  • Page 74 8. Once you added all the cameras, click the close button “x” on the Device Setting windows to return to the main windows. The cameras will display here. NOTE Divx/Xvid codec is required for viewing the image of camera. If the image cannot be displayed in the Live View/Preview window normally, click the following path to download and install the required component: http://download.divx.com/divx/DivXInstaller.exe...
  • Page 75  Edit / Delete a Camera 1. To edit a camera: From the Device Setting window, highlight the camera you would like to edit then click on Modify button. 2. To delete a camera: select the desired one and then click Remove.
  • Page 76  View Camera Image Since you have added camera(s) to the system, the image of the selected camera(s) will be displayed on the Live View Window automatically. You can view a maximum of 36 cameras simultaneously. Additionally, you can select one-camera or other view mode to display the video from the Camera View Mode buttons.
  • Page 77  Playback the Recorded Files 1. Click the button to display the Playback window. 2. On the Playback window, select the camera and setup the begin/end date and begin/end time, then click Search. The search result will be displayed in the Record File list. - 76 -...
  • Page 78 3. To playback the video clip, select the desired file and click Play. - 77 -...
  • Page 79 5.2.4 eMap Setup & Camera Status  Manage eMap Click the button and select View Setting to manage eMap. eMap refers to the geography and device scope in the SecurView Pro, which visually presents the devices in your security system. It uses a background of the area (e.g.
  • Page 80 2. Enter an eMap name. 3. Click Browse to select a Picture File from your computer. Picture will display in the Preview window. - 79 -...
  • Page 81 4. Click Save and click OK to apply the settings. 5. Click Camera Location to assign the camera location. - 80 -...
  • Page 82 6. The following screen appears. 7. Select the camera from the list and then click the position on the map. The camera icon will be displayed on map. - 81 -...
  • Page 83 8. Click Save when complete. To modify/remove an eMap 1. To edit the eMap: In the eMap List, select the map name from eMap list, and click Modify. The map’s information will display on the preview windows. After changes the setting information, click Save to save the setting. - 82 -...
  • Page 84 2. To delete the eMap: In the eMap List, select the desired one and click Remove. The selected map will be removed from the list.  View eMap Click the button and select eMap View. - 83 -...
  • Page 85 b. Select the map from the eMap Name list. Camera Status  Click the camera icon , the camera Live Monitor window will display live image on that camera. - 84 -...
  • Page 86 5.2.5 System Info  Account Click the System button and select Account to change the administrator password of the system. Enter the Current password, and then enter the new password twice (in the Type new password and Retype password boxes). Then click Save.
  • Page 87  Version Click the System button and select Version to view the current firmware version of the system.  System Setting Click the System button and select System Setting. Auto Scan period can be set from 30 seconds to 100 seconds. - 86 -...
  • Page 88 5.2.6 Event Settings  Setting up Event Server Click the button and select Event Server to configure the SMTP settings for email notification use. Select the Enable SMTP option and configure the following information correctly to start the email feature. - 87 -...
  • Page 89  SMTP Server Address: Enter the mail server address. For example, mymail.com or smtp.gmail.com or smtp.live.com  Sender Email Address: Enter the email address of the user who will send the email. For example, John@mailserver.com.  Authentication Mode: Select None or SMTP according to the mail server configuration.
  • Page 90  Sending Notification to the User Click the button and select Address Book to assign the user to the Address Book of the camera. The user will receive a real- time notification from the system while triggering out. 1. On the Address Book window, click New. 2.
  • Page 91 4. To edit the user: In the Address Book List, select the desired user and click Modify. The user’s information will be displayed, where you can change the user’s information and then click Save when completed. 5. To delete the user: In the Address Book List, select the desired user and click Remove.
  • Page 92 1. On the Event Trigger window, select the desired camera from the Camera List. 2. Do one of the following:  SMTP: Select this option and enter the Subject and Message, the system will send an email message to the selected user(s) in the Address Book List.

  • Page 93: Chapter 6

    HAPTER How to access the camera behind a Router You can either setup the Dynamic DNS connection via camera itself or your home router. An account from any of the listed DDNS providers is required prior to this operation. Configure DDNS on your Camera 1.
  • Page 94 9000. 4. Open another web browser and go to your Router’s Web Configuration page. (In the example, TRENDnet’s TEW-651BR Wireless N router is used) 5. Go to Virtual Server* section and create a new entry.
  • Page 95 Private Port: The HTTP port that you assign on your Camera. Public Port: The port used on remote side to access to your Camera. LAN Server: The local IP address of your Camera. Then click Add to add the application. * Please refer to your router’s user’s manual for detail Virtual Server setting.
  • Page 96 6. Open another web browser and enter your DDNS domain and camera’s port number. http://yourDomainName:PortNumber 7. Camera’s login page will appear. Configure DDNS on your router 1. Go to Camera’s DDNS  Ports Number section, assign a HTTP port for your camera and click Apply. 2.
  • Page 97 3. Find the Dynamic DNS configuration section. 4. Enable DDNS, fill out the following information and then click Apply. - 96 -...
  • Page 98 5. Go to Virtual Server* section and create a new entry. Enable: Click Enable Name: Enter the application name (eg. Camera Name) Protocol: Select TCP Private Port: The HTTP port that you assign on your Camera. Public Port: The port used on remote side to access to your Camera.

  • Page 99: Chapter 7

    HAPTER PPENDIX A.1 Specification  Image Sensor Sensor 1/4” color CMOS Resolution 640x480  Video CompressionMJPEG Video resolution VGA/QVGA/QQVGA; up to 30fps  System Hardware Processor ARM9 base 32MB SDRAM 4MB NOR Flash Power DC 5V  Communication 10/100Mbps Fast Ethernet, auto-sensed, Auto-MDIX WLAN Based on IEEE 802.11n technology,...
  • Page 100 One WPS button Reset One Reset button LEDs Power LED (amber); Link LED (green)  Software OS Support Windows 7/Vista/XP Browser Internet Explorer 6.0 or above Software SecurView Pro for playback/recording/ configuration features  Operating Environment Temperature - Operation: 0C ~ 45C - Storage: -15C ~ 60C Humidity Max.

  • Page 101: Glossary Of Terms

    A.2 Glossary of Terms NUMBERS 10BASE-T 10BASE-T is Ethernet over UTP Category III, IV, or V unshielded twisted-pair media. 100BASE-TX The two-pair twisted-media implementation of 100BASE-T is called 100BASE-TX. ADPCM Adaptive Differential Pulse Code Modulation, a new technology improved from PCM, which encodes analog sounds to digital form.
  • Page 102 Communication Communication has four components: sender, receiver, message, and medium. In networks, devices and application tasks and processes communicate messages to each other over media. They represent the sender and receivers. The data they send is the message. The cabling or transmission method they use is the medium.
  • Page 103 distributed company and operates the company’s mission- critical applications. Ethernet The most popular LAN communication technology. There are a variety of types of Ethernet, including 10Mbps (traditional Ethernet), 100Mbps (Fast Ethernet), and 1,000Mbps (Gigabit Ethernet). Most Ethernet networks use Category 5 cabling to carry information, in the form of electrical signals, between devices.
  • Page 104 numbers. Intranet This is a private network, inside an organization or company that uses the same software you will find on the public Internet. The only difference is that an Intranet is used for internal usage only. Internet The Internet is a globally linked system of computers that are logically connected based on the Internet Protocol (IP).
  • Page 105 writing programs that can be safely downloaded to your computer through the Internet without the fear of viruses. It is an object-oriented multi-thread programming best for creating applets and applications for the Internet, Intranet and other complex, distributed network. Local Area Network a computer network that spans a relatively small area sharing common resources.
  • Page 106 network are: LAN – (local area network): Computers are in close distance to one another. They are usually in the same office space, room, or building. WAN – (wide area network): The computers are in different geographic locations and are connected by telephone lines or radio waves.
  • Page 107 Carrier Sense Multiple Access with Collision Detection (CSMA/CD), implemented as token-ring, ARCNET, FDDI, or Ethernet. The Router Information Protocol (RIP),a part of the Transmission Control Protocol/Internet Protocol (TCP/IP) suite, forwards packets from one network to another using the same network protocol. RJ-45 RJ-45 connector is used for Ethernet cable connections.
  • Page 108 FDDI stations. Subnet mask In TCP/IP, the bits used to create the subnet are called the subnet mask. (TCP/IP) Transmission Control Protocol/Internet Protocol is a widely used transport protocol that connects diverse computers of various transmission methods. It was developed y the Department of Defense to connect different computer types and led to the development of the Internet.
  • Page 109 128-bit encryption. Windows Windows is a graphical user interface for workstations that use DOS. WPA (Wi-Fi Protected Access ) is used to improve the security of Wi-Fi networks, replacing the current WEP standard. It uses its own encryption, Temporal Key Integrity Protocol (TKIP), to secure data during transmission.

  • Page 110: Limited Warranty

    1 year warranty. If a product does not operate as warranted during the applicable warranty period, TRENDnet shall reserve the right, at its expense, to repair or replace the defective product or part and deliver an equivalent product or part to the customer.
  • Page 111 Material Authorization (RMA) number will be issued. An RMA number is required in order to initiate warranty service support for all TRENDnet products. Products that are sent to TRENDnet for RMA service must have the RMA number marked on the outside of return packages and sent to TRENDnet prepaid, insured and packaged appropriately for safe shipment.
  • Page 112 Go to http://www.trendnet.com/gpl http://www.trendnet.com Download section and look for the desired TRENDnet product to access to the GPL Code or LGPL Code. These codes are distributed WITHOUT WARRANTY and are subject to the copyrights of the developers. TRENDnet does not provide technical support for these codes. Please go to http://www.gnu.org/licenses/gpl.txt...
  • Page 113 - 112 -...
