TRENDnet TPE-101I Quick Installation Manual
Power over ethernet injector/power over ethernet splitter
Hide thumbs
Also See for TPE-101I:
- User manual (10 pages) ,
- Frequently asked questions (2 pages) ,
- Specifications (2 pages)
Related Manuals for TRENDnet TPE-101I
Summary of Contents for TRENDnet TPE-101I
- Page 1 Quick Installation Guide TPE-101I TPE-102S...
-
Page 2: Table Of Contents
Table of Contents Table of Contents English ...................... 1. Before You Start ................2. Hardware Installation ................ Technical Specifications ................Troubleshooting ..................Version 06.20.2007... -
Page 3: English
1. Before You Start Package Contents TPE-101I/TPE-102S Quick Installation Guide Power Cord (TPE-101I) Jumper Cable (TPE-102S) Note: The TPE-101I and TPE-102S only support Power over Ethernet (PoE) devices that follow the IEEE 802.3af standard Note: The TPE-102S only supports non-PoE devices with an output power of 5V, 7.5V, 9V or 12V. - Page 4 Application Power over Ethernet Injector Power Jack (TPE-101I) Power Power + Data (PoE) Data PoE Device 8-Port 10/100Mbps Fast Ethernet Switch (TE100-S8) Power Data Power + Data Power over Ethernet Injector Power (TPE-101I) Jack Power Data 8-Port 10/100Mbps Fast Ethernet Switch (TE100-S8) Power + Data (PoE)
-
Page 5: Hardware Installation
2. Hardware Installation Using the TPE-101I with a PoE device 1. Connect the Power Cord to the Injector. Then connect the Power Cord to an outlet. 2. Connect a CAT-5 cable from a switch to the TPE-101I's Data In port. 3. - Page 6 TEW-450APB) and to the TPE-102S. Your installation is now complete. Register Your Product To ensure the highest level of customer service and support, please take a moment to www.trendnet.com/register register your product Online at: Thank you for choosing TRENDnet English...
-
Page 7: Technical Specifications
Technical Specifications IEEE 802.3 10BASE-T Applicable Standards IEEE 802.3u 100BASE-TX IEEE 802.3af Power Over Ethernet (PoE) Data: 1, 2, 3, 6 Ethernet Pin Usage Power: 4, 5 (V+), 7, 8 (V-) TPE-101I: 1 Data In, 1 PoE Out Fixed Ports TPE-102S: 1 Data Out, 1 PoE In 10/20Mbps for half/full-duplex... -
Page 8: Troubleshooting
PoE injector or disconnecting the CAT 5 cable from the PoE Out port. Reinsert the connection after 5-10 seconds have elapsed. If you still encounter problems or have any questions regarding the PoE Injector/Splitter, please contact TRENDnet's Technical Support Department. - Page 9 Return Material Authorization (RMA) number, accompanied by a copy of the dated proof of the purchase. Products returned to TRENDnet must be pre- authorized by TRENDnet with RMA number marked on the outside of the package, and...
