Summary of Contents for TRENDnet TEW-632BRP

  • Page 2 Regulatory notes and statements Wireless LAN, Health and Authorization for use Radio frequency electromagnetic energy is emitted from Wireless LAN devices. The energy levels of these emissions however are far much less than the electromagnetic energy emissions from wireless devices like for example mobile phones.

  • Page 3: Fcc Interference Statement

    FCC Radio Frequency Exposure statement This Wireless LAN radio device has been evaluated under FCC Bulletin OET 65 and found compliant to the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247 (b) (4) addressing RF Exposure from radio frequency devices. The radiated output power of this Wireless LAN device is far below the FCC radio frequency exposure limits.

  • Page 4: Safety Information

    Safety Information Your device contains a low power transmitter. When device is transmitted it sends out radio frequency (RF) signal. CAUTION: To maintain compliance with FCC’s RF exposure guidelines, this equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

  • Page 5: Table Of Contents

    TABLE OF CONTENT ..................1 BOUT UIDE     Purpose ........................................1   Terms/Usage ......................................1   Overview of this User’s Guide .................................. 1 ................... 2 NTRODUCTION     Applications: ......................................2   Supported Features: ....................................3 ................4 NPACKING AND ETUP  ...
  • Page 6   Routing ........................................38   Static ........................................38   Dynamic ....................................... 39   Routing Table ...................................... 40   Access ........................................41   Filters ........................................41   Virtual Server ....................................... 45   Special AP ......................................46   DMZ ........................................47   Management ......................................

  • Page 7: About This Guide

    ABOUT THIS GUIDE Congratulations on your purchase of this IEEE 802.11b/g/n Wireless Broadband Router. This integrated access device combines Internet gateway functions with wireless LAN and Fast Ethernet switch. It provides a complete solution for Internet surfing and office resource sharing, and it is easy to configure and operate for every user.

  • Page 8: Introduction

    INTRODUCTION With the explosive growth of the Internet, accessing information and services at any time, day or night has become a standard requirement for most people. The era of the standalone PC is waning. Networking technology is moving out of the exclusive domain of corporations and into homes with at least two computers.

  • Page 9: Supported Features

    Supported Features: High speed data transfer rate NAT for sharing 1 IP address to all LAN/WLAN users. PPPoE and PPTP protocol for Dial-Up ADSL. 64/128 bit WEP Encryption WPA-PSK, WPA2-PSK, WPA, WPA2 security DHCP Server / Client. UPnP (Universal Plug and Play). WPS (Wi-Fi Protected Setup) Virtual Server mapping.

  • Page 10: Unpacking And Setup

    Wireless Home Router. Unpacking Open the box of the WLAN Router and carefully unpack it. The box should contain the following items: TEW-632BRP Wireless N Home Router Easy Go Installation CD Multi-Language Quick Installation Guide 2 x 2dBi gain dipole antenna External power adapter 1.5m (5ft) Cat.5 Ethernet Cable...

  • Page 11: Hardware Installation

    HARDWARE INSTALLATION Front Panel The figure below shows the front panel of the IEEE 802.11b/g/n Wireless Home Router. Front Panel POWER This indicator lights green when the hub is receives power, otherwise it is off. SYSTEM This indicator blinking green means the WLAN Router is working successfully. Otherwise, this indicator always on or off means the function of the WLAN Router has failed.

  • Page 12: Rear Panel

    Rear Panel The figure below shows the rear panel of the IEEE 802.11b/g/n Wireless Home Router. Rear Panel Antenna There are two 2dBi gain antennas on the rear panel for wireless connection. LAN (1-4) Four RJ-45 10/100Mbps Auto-MDIX ports for connecting to either 10Mbps or 100Mbps Ethernet connections.

  • Page 13: Side Panel

    Side Panel The figure below shows the side panel of the IEEE 802.11b/g/n Wireless Home Router. WPS (side panel) Push this button to execute the Wi-Fi Protected Setup process.

  • Page 14: Hardware Connections

    Hardware connections Connecting the WLAN Router 1. Plug in one end of the network cable to the WAN port of the WLAN Router. 2. Plug in the other end of the network cable to the Ethernet port of the xDSL or Cable modem.

  • Page 15: Pc Network Tcp/Ip Setting

    PC NETWORK TCP/IP SETTING The network TCP/IP settings differ based on the computer’s operating system (Win95/98/ME/NT/2000/XP) and are as follows. Windows 95/98/ME 1. Click on the “Network neighborhood” icon found on the desktop. 2. Click the right mouse button and a context menu will be show. 3.

  • Page 16: Windows 2000

    6. Select “None” for the “Gateway address” field. Windows 2000 Double click on the “My Computer” icon on the desktop. When “My Computer” window opens, open the “Control Panel” and then open the “Network dialup connection” applet. Double click on the “Local area network connection” icon. Select “Properties”...

  • Page 17: Windows Xp / Vista

    Windows XP / Vista Point the cursor and click the right button on the “My Network Place” icon. Select “properties” to enter the TCP/IP setting window. 1. Set “IP address” to “Obtain an IP address automatically.” 2. Set “DNS” to “Obtain DNS server address automatically.”...

  • Page 18: Configuration

    Before configuring the WLAN Router through WLAN, make sure that the SSID, Channel and the WEP is set properly. The default setting of the WLAN Router that you will use: SSID: TRENDnet Channel: 6 Security: disable Login to the WLAN Router...

  • Page 19: Setup Wizard

    Setup Wizard Setup wizard is provided as part of the web configuration utility. User can simply follow the step-by-step process to get the wireless Router configuration ready to run in 6 easy steps by clicking on` the “Wizard” button on the function menu. The following screen will appear.
  • Page 20 Step 3: Set LAN connection and DHCP server Set user’s IP address and mask. The default IP is 192.168.10.1. If the user chooses to enable DHCP, please click “Enable”. DHCP enabled is able to automatically assign IP addresses. Please assign the range of IP addresses in the fields of “Range start”...
  • Page 21 Obtain IP automatically (DHCP client): If the user has enabled DHCP server, choose "Obtain IP automatically (DHCP client)" to have the WLAN Router assign IP addresses automatically.
  • Page 22 Fixed IP Address: If the Internet Service Provider (ISP) assigns a fixed IP address, choose this option and enter the assigned WAN IP Address, WAN Subnet Mask, WAN Gateway Address and DNS Server Addresses for the WLAN Router.
  • Page 23 PPPoE to obtain IP automatically: If connected to the Internet using a PPPoE (Dial-up xDSL) connection, and the ISP provides a User Name and Password, then choose this option and enter the required information.
  • Page 24 PPPoE with a fixed IP address: If connected to the Internet using a PPPoE (Dial-up xDSL) connection, and the ISP provides a User Name, Password and a Fixed IP Address, choose this option and enter the required information.
  • Page 25 PPTP: If connected to the Internet using a PPTP xDSL connection, enter your IP, Subnet Mask, Gateway, Server IP, PPTP Account and PPTP Password.
  • Page 26 L2TP: If connected to the Internet using a L2TP (Dial-up xDSL) connection and the ISP provides a Server IP, Account and Password information, choose this option and enter the required information.
  • Page 27 Big Pond Cable(Australia): If your ISP is Big Pond Cable, the ISP will provide a User Name, Password, Authentication Server and Login Server IP (Optional). Choose this option and enter the required information.
  • Page 28 Step 5: Set Wireless LAN connection Click “Enable” to enable Wireless LAN. If user enables the Wireless LAN, type the SSID in the text box and select a communications channel. The SSID and channel must be the same as wireless devices attempting to connect to the WLAN Router. Step 6: Setup completed The Setup wizard is now completed.

  • Page 29: Advanced Configuration

    Advanced configuration Main The screen enables users to configure the LAN & DHCP Server, set WAN parameters, create Administrator and User passwords, and set the local time, time zone, and dynamic DNS. LAN & DHCP Server This page allows the user to configure LAN and DHCP properties, such as the host name, IP address, subnet mask, and domain name.

  • Page 30: Wan

    Start IP: Type an IP address to serve as the start of the IP range that DHCP will use to assign IP addresses to all LAN devices connected to the WLAN Router. End IP: Type an IP address to serve as the end of the IP range that DHCP will use to assign IP addresses to all LAN devices connected to the WLAN Router.

  • Page 31: Password

    WAN IP: Select whether user wants to specify an IP address manually, or want DHCP to obtain an IP address automatically. When Specify IP is selected, type the IP address, subnet mask, and default gateway in the text boxes. User’s ISP will provide with this information.

  • Page 32: Time

    Time This screen enables users to set the time and date for the WLAN Router's real-time clock, select properly time zone, and enable or disable daylight saving. Local Time: Displays the local time and date. Time Zone: Select the time zone from the drop-down list. Synchronize the clock with: Select the clock adjustment method form the drop- down list.

  • Page 33: Dynamic Dns

    Dynamic DNS This synchronizes the DDNS server with your current Public IP address when you are online. First, you need to register your preferred DNS with the DDNS provider. Then, please select the DDNS address in the Server Address and fill the related information in the below fields: Host Name, User Name and Password.

  • Page 34: Wireless

    Wireless This section enables users to configuration the wireless communications parameters for the WLAN Router. Basic This page allow user to enable and disable the wireless LAN function, create a SSID, and select the channel for wireless communications. Enable/Disable: Enables or disables wireless LAN via the WLAN Router. SSID: Type an SSID in the text box.

  • Page 35: Security

    SSID Broadcast: While SSID Broadcast is enabled, all wireless clients will be able to view the WLAN Router’s SSID. For security purposes, users may want to disable SSID Broadcast to ensure only authorized clients have access. Security Authentication Type: The authentication type default is set to open system. There are four options: Disabled, WEP, WPA, WPA2 and WPA-Auto.
  • Page 36 WEP Key: Select the level of encryption from the drop-down list. The WLAN Router supports, 64 and 128-bit encryption. Key 1 ~ Key 4: Enables users to create up to 4 different WEP keys. Manually enter a set of values for each key. Select a key to use by clicking the radio button next to the key.

  • Page 37: Advanced

    WPA-PSK/WPA2-PSK Security If WPA, WPA2 or WPA-Auto PSK is selected. Cipher Type: Select the cipher type for TKIP or AES encryption, Selected Auto for auto detects the cipher type. Passphrase: The length should be 8 characters at least. Advanced This screen enables users to configure advanced wireless functions. Beacon Interval: Type the beacon interval in the text box.

  • Page 38: Wi-Fi Protected Setup

    packet transfer rates are minimized. (NOTE: set this fragmentation threshold value may diminish system performance.) DTIM Interval: Type a DTIM (Delivery Traffic Indication Message) interval in the text box. User can specify a value between 1 and 255. The default value is 1. Wi-Fi Protected Setup This screen enables users to configure the Wi-Fi Protected Setup function.

  • Page 39: Device Information

    Device Information This screen enables users to view the WLAN Router’s LAN, Wireless and WAN configurations. Firmware Version: Displays the latest build of the WLAN Router firmware interface. After updating the firmware in Tools - Firmware, check this to ensure that the firmware was successfully updated.

  • Page 40: Log

    This screen enables users to view a running log of Router system statistics, events, and activities. The log displays up to 200 entries. Older entries are overwritten by new entries. The Log screen commands are as follows: Click “First Page” to view the first page of the log Click “Last Page”...

  • Page 41: Statistic

    SMTP Authentication: Selected the Enabled if the SMTP server need for authentication, fill in account name and password in SMTP Account field and SMTP Password field. SMTP Account: If the SMTP Authentication enabled, fill in the SMTP account name here. SMTP Password: If the SMTP Authentication enabled, fill in the password of the SMTP account here.
  • Page 42 Click “Reset” to erase all statistics and begin logging statistics again.

  • Page 43: Wireless

    Wireless This screen enables users to view information about wireless devices that are connected to the WLAN Router. Connected Time: Displays how long the wireless client has been connected to the WLAN Router. MAC Address: Displays the wireless client’s MAC address.

  • Page 44: Routing

    Routing This selection enables users to set how the WLAN Router forwards data: Static and Dynamic. Routing Table enables users to view the information created by the WLAN Router that displays the network interconnection topology. Static It enables users to set parameters by which the WLAN Router forwards data to its destination if the network has a static IP address.

  • Page 45: Dynamic

    New: Click “New” to clear the text boxes and add required information to create a new entry. Dynamic This screen enables users to set NAT parameters. Transmit: Click the radio buttons to set the desired transmit parameters, Disabled, RIP 1, or RIP 2. Receive: Click the radio buttons to set the desired transmit parameters, Disabled, RIP 1, or RIP 2.

  • Page 46: Routing Table

    Routing Table This screen enables users to view the routing table of the WLAN Router. The routing table is a database created by the WLAN Router that displays the network interconnection topology. Network Address: Displays the network IP address of the connected node. Network Mask: Displays the network (subnet) mask of the connected node.

  • Page 47: Access

    Access This page enables you to define access restrictions, set up protocol and IP filters, create virtual servers, define access for special applications such as games, and set firewall rules. Filters Using filters to deny or allow the users to access. Five types of filters to select: MAC, URL blocking, IP, Protocol filter and Domain blocking.
  • Page 48 MAC Filters MAC Filter: Enables you to allow or deny Internet access to users within the LAN based upon the MAC address of their network interface. Click the radio button next to Disabled to disable the MAC filter. Disable: Disable the MAC filter function. Allow: Only allow computers with MAC address listed in the MAC Table.
  • Page 49 New: Click New to erase all fields and enter new information. Domain/URL Blocking You could specify the domains that allow users to access or deny by clicking one of the two items. Also, add the specified domains in the text box. Disable: Disable the Domain/URL Blocking function.
  • Page 50 IP Filters This screen enables you to define a minimum and maximum IP address range filter; all IP addresses falling within the range are not allowed Internet access. The IP filter profiles are listed in the table at the bottom of the page. (Note: Click anywhere in the item.

  • Page 51: Virtual Server

    Virtual Server This screen enables users to create a virtual server via the WLAN Router. If the WLAN Router is set as a virtual server, remote users requesting Web or FTP services through the WAN are directed to local servers in the LAN. The WLAN Router redirects the request via the protocol and port numbers to the correct LAN server.

  • Page 52: Special Ap

    Special AP This screen enables users to specify special applications, such as games which require multiple connections that are blocked by NAT. The special applications profiles are listed in the table at the bottom of the page. Note: When selecting items in the table at the bottom, click anywhere in the item. The line is selected, and the fields automatically load the item's parameters, which user can edit.

  • Page 53: Dmz

    Add: Click to add the special application profile to the table at the bottom of the screen. Update: Click to update information for the special application if user have selected a list item and have made changes. Delete: Select a list item and click Delete to remove the item from the list. Cancel: Click Cancel button to erase all fields and enter new information.
  • Page 54 HTTP: Enables users to set up HTTP access for remote management. Allow to Ping WAN Port: Type a range of Router IP addresses that can be pinged from remote locations UPnP Enable: UPnP is short for Universal Plug and Play that is a networking architecture that provides compatibility among networking equipment, software, and peripherals.

  • Page 55: Tools

    Tools This page enables users to restart the system, save and load different settings as profiles, restore factory default settings, run a setup wizard to configure WLAN Router settings, upgrade the firmware, and ping remote IP addresses. Restart Click “Restart” to restart the system in the event the system is not performing correctly.

  • Page 56: Settings

    Settings This screen enables users to save settings as a profile and load profiles for different circumstances. User can also load the factory default settings, and run a setup wizard to configure the WLAN Router and Router interface. Save Settings: Click “Save” to save the current configuration as a profile that can load when necessary.

  • Page 57: Firmware

    Firmware This screen enables users to keep the WLAN Router firmware up to date. Please follow the below instructions: Download the latest firmware from the manufacturer's Web site, and save it to disk. Click “Browse” and go to the location of the downloaded firmware file. Select the file and click “Upgrade”...

  • Page 58: Technical Specifications

    TECHNICAL SPECIFICATIONS General Standards IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.11n draft 2.0; IEEE 802.11g; IEEE 802.11b Protocol CSMA/CD Radio Technology DSSS/OFDM Data Transfer 802.11n mode: up to 300Mbps (auto sense) Rate 802.11g mode: up to 54Mbps (auto sense) 802.11b mode: up to 11Mbps (auto sense) Ethernet: 10Mbps (half duplex), 20Mbps (full-duplex) Fast Ethernet: 100Mbps (half duplex), 200Mbps (full- duplex) Receiver...

  • Page 59: Limited Warranty

    3 Years If a product does not operate as warranted above during the applicable warranty period, TRENDnet shall, at its option and expense, repair the defective product or deliver to customer an equivalent product to replace the defective item. All products that are replaced will become the property of TRENDnet.
