TRENDnet TEG-S2400I - DATA SHEETS Datasheet

FEATURES
• 24 10/100Mbps Auto-Negotiation Ethernet/Fast Ethernet Ports
• Gigabit Module Slot; supports the following optional Modules: 1-Port 100Base-FX, 2-Port 100Base-FX, 2-Port Copper Gigabit, 1-Port Fiber
Gigabit, or 2-Port Fiber Gigabit
• Full/Half-duplex transfer mode for each 10/100Mbps port (1000Mbps port supports only at full-duplex mode)
• Auto-MDIX media type detection for all ports
• Supports store-and-forward switching architecture with non-blocking wire-speed performance
• IEEE 802.3x flow control for full-duplex and collision-based back pressure function for half-duplex operation
• 14K MAC addresses and 4K VLAN entries per device
• 3MB packet buffer and 1MB control buffer per device
• 8.8 Gbps Backplane speed
• Broadcast storm filtering and Head-of-Line blocking prevention
• Supports Port-Based VLAN (26 Groups), IEEE 802.1Q Tag-Based VLAN, and IEEE 802.1P Port-Based Quality of Service (QoS)
• Supports Port-Trunking (7 trunk groups with maximum of 4 ports per group)
• Supports IP Multicast, IGMP Snooping, and RMON Group 1,2,3,9
• Configuration via Console Port (serial cable included), SNMP, Telnet, and Web Browser
• Extensive front panel diagnostic LEDs
• 19" Rack Mountable
• 5-Year Warranty
BENEFITS
Performance:
Provides Gigabit Module Slot for 100Base-FX or Copper/Fiber Gigabit connection.
Flexibility:
Connects to 10Base-T, 100Base-TX, 100Base-FX, 1000Base-T, and 1000Base-SX networks (with optional module).
Expandability:
Simple expansion by uplinking to 10/100Mbps or Gigabit Switches. Trunking feature increases throughput between Switches within the
network.
Cost Effectiveness:
Provides SNMP management and Gigabit Performance at an affordable price.
Security:
Port-based VLAN to further segmenting the network.
24-Port 10/100Mbps SNMP Switch with
Gigabit Module Slot
TEG-S2400i
TRENDnet's TEG-2400i is a high performance web-managed
SNMP Layer 2 Switch that provides users with 24 10/100Mbps Fast
Ethernet ports and one Gigabit module slot. The module slot
accepts either copper or fiber media module, which offers
connection to Gigabit Server or Gigabit backbone with flexibility.
With the Web Browser configuration feature, users can easily install
and configure the Switch. The TEG-S2400i supports both Port-
Based and Tag-Based VLAN, and the trunking feature delivers more
bandwidth than regular uplink between Switches. TRENDnet's
TEG-S2400i is powerful and easy-to-use in reducing unnecessary
broadcast traffic and enhancing network security.
TEG-S2400i
rev:07. 1 4.2006
