- Page 1 TE100-S24V 24-Port 10/100Mbps Fast Ethernet Smart Switch User’s Guide...
-
Page 3: Fcc Warning
FCC Warning This equipment has been tested and found to comply with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 4 (Tmra). b) Reduced Air Flow- Installation of the equipment in a rack should be such that the amount of air flow required for safe operation of the equipment is not compromised. c) Mechanical Loading- Mounting of the equipment in the rack should be such that a hazardous condition is not achieved due to uneven mechanical loading.
-
Page 5: Table Of Contents
A B L E O F O N T E N T S ABOUT THIS GUIDE..............1 ...................1 URPOSE ................1 ERMS SAGE INTRODUCTION..............3 ..........3 THERNET ECHNOLOGY ............4 WITCHING ECHNOLOGY VLAN (V ) ......4 IRTUAL OCAL ETWORK .................6 EATURES UNPACKING AND INSTALLATION ........7 ................7... - Page 6 ..........17 ONFIGURING ETUP ETTINGS ..........22 ONFIGURING YSTEM ETTING ..........23 ONFIGURING ETTING ................25 TATISTICS TECHNICAL SPECIFICATIONS........27...
-
Page 7: About This Guide
This guide discusses how to install your 24-Port 10/100Mbps Fast Ethernet Smart Switch. Terms/Usage In this guide, the term “Switch” (first letter upper case) refers to your 24-Port 10/100Mbps Fast Ethernet Smart Switch, and “switch” (first letter lower case) refers to other Ethernet... -
Page 9: Introduction
N T R O D U C T I O N This chapter describes the features of the 24-Port 10/100Mbps Fast Ethernet Smart Switch and some background information about Ethernet/Fast Ethernet switching technology. Fast Ethernet Technology The growing importance of LANs and the increasing complexity... -
Page 10: Switching Technology
Routers have also been used to segment local area networks, but the cost of a router, the setup and maintenance required make routers relatively impractical. Today switches are an ideal solution to most kinds of local area network congestion problems. - Page 11 LAN. The primary utility of using VLAN is to reduce latency and need for routers, using faster switching instead. Other VLAN utility include: Security Security is increased with the reduction of opportunity in eavesdropping on a broadcast network because data will be switched to only those confidential users within the VLAN.
-
Page 12: Features
Features 24×10/100Mbps Auto-negotiation Ethernet ports All ports support auto-MDIX, so there is no need to use cross-over cables or an up-link port Full/half duplex transfer mode for each port Wire speed reception and transmission Store-and-Forward switching scheme capability to support rate adaptation and ensure data integrity... -
Page 13: Unpacking And Installation
One console serial cable This User’s Guide If any item is found missing or damaged, please contact your local reseller for replacement. Installation The site where you install the Switch stack may greatly affect its performance. When installing, consider the following pointers:... -
Page 14: Rack Mounting
Install the Switch in a fairly cool and dry place. See Technical Specifications acceptable temperature and humidity operating ranges. Install the Switch in a site free from strong electromagnetic field generators (such as motors), vibration, dust, and direct exposure to sunlight. -
Page 15: Connecting Network Cable
Figure 1. Installing the bracket with the provided screws Then, use screws provided with the equipment rack to mount the Switch on to the rack. Figure 2. Mounting the Switch on to the rack Connecting Network Cable The Switch supports 10Mbps Ethernet or 100Mbps Fast Ethernet and it runs both in half and full duplex mode. -
Page 16: Ac Power
AC Power The Switch requires AC power supply of 100~240V AC, 50~60 Hz. The Switch does not come with a Power ON/OFF switch, so the Switch will automatically power on when it is connected to an electrical outlet. The switch’s power supply will adjust to the local power source automatically and may be turned on without having any LAN segment cables connected. -
Page 17: Rear Panel
“plug and play” capability. Console Port An RS-232 DCE console port is used to setup and manage the Switch via a connection to a console terminal or PC using a terminal emulation program (e.g. Windows HyperTerminal). -
Page 18: Understanding Led Indicators
LED I N D E R S T A N D I N G N D I C A T O R S The front panel LEDs provides instant status feedback, and help monitor and troubleshoot. 24-Port 10/100Mbps Ethernet Smart Switch... -
Page 19: Fiber Module Leds
: No link. FDX: Full Duplex : When the FDX LED lights on, the fiber port is in full- duplex mode. : When the LED light is off, the fiber port is in half-duplex... -
Page 20: Configuration
Stop bits: Flow control: None Make sure the terminal or PC you are using to make this connection is configured to match these settings. Configuring the Switch The 24-Port 10/100Mbps Fast Ethernet Smart Switch has a menu-driven console interface. The Switch can be configured... - Page 21 Switch using the console program. This section indicates how to configure the Switch to enable its smart functions including: Setup The two options in the Setup screen are Port Configuration and VLAN. The functions of these two items are illustrated in the following sections.
-
Page 22: Login
[Space Bar]: Change selection. Available when the field has multiple selections. Login Execute the terminal emulation program on the remote workstation, connect the serial cable, and turn on the Switch. The login screen will ask you to input a password to login. Password: admin (default password) Figure 10. -
Page 23: Main Menu
You can see the available console command keys in the lower portion of the screen. Move cursor to highlight a desired option by using Up Arrow, Down Arrow, and Tab keys, and then press Enter key to confirm. The four options in the Main Menu screen are Setup, System, File, and Statistics. - Page 24 (port 25 is reserved for optional Fiber Port) Speed, Flow Control, and QoS. Link Status is determined by the Switch and can’t be changed. This screen displays Port 01 ~ 12 status, for port 13 ~ 25, please select Next.
- Page 25 10M Full, and 10M Half. To change the speed setting, highlight Port, enter the port number and hit Enter, and the cursor will move to the next field Speed. Hit Space Bar to select one of the speed options. Hit Enter to select the desired speed and the cursor will move to Flow Control option.
- Page 26 QoS Example: The computers connect to Switch’s Port 1 ~ 5 do Video Conferencing regularly. To ensure video/voice streaming quality between these 5 Users, you can set Port 1 ~ 5 QoS to High and set the rest of the ports’ QoS to low.
- Page 27 Bar] to select “V” to add the port to the VLAN group or select “- ” to delete the port from the group. In default, all ports belong to VLAN 1 (see Figure 14). Figure 14. VLAN Configuration For example, there are five computers (PC1~PC5) connected to the Switch’s port 1~5.
-
Page 28: C Onfiguring S Ystem S Etting
Figure 15. There is no connection between PC1 (VLAN 1) and PC5 (VLAN 2) Using VLAN feature, you can group the computers on the Switch into many independent small networks. For example, in Figure 16, the Switch has been divided into four VLAN groups. Each VLAN group is independent and there is no communication between the VLAN groups. -
Page 29: C Onfiguring F Ile S Etting
Confirm Password: To confirm the new password. Refresh Time: To set the automatic status refreshing time. You can select Disabled, 1 sec., 5 sec., 10 sec., 15 sec., or 20 sec. (by pressing the [Space bar]). Login Timeout: Set the console idle time-out to automatically logout the configuration console. - Page 30 On Hyper Terminal’s Menu Bar, click on “Transfer” and select “Receive File…”. Input the path where you would like to save the file to (or click on “Browse” to select the location), click on the drop down arrow and select “Xmodem” as transfer protocol, click on “Receive”, enter the desired file name, and then...
-
Page 31: S Tatistics
Switch. Move cursor to “Download Configuration” and hit “Enter”. At “Are you sure?”, hit “space bar” once to show “Yes” and then hit “Enter”. On Hyper Terminal’s Menu Bar, click on “Transfer” and select “Send File…”. - Page 32 Statistics Detail Highlight Port and enter port number to view the detail statistics of this port (see Figure 20). Figure 20. Statistics Detail...
-
Page 33: Technical Specifications
E C H N I C A L P E C I F I C A T I O N S General IEEE 802.3 10BASE-T Ethernet Standards IEEE 802.3u 100 BASE-TX, 100BASE-FX Fast Ethernet CSMA/CD Protocol Ethernet: 10Mbps (half duplex), 20Mbps (full duplex) - Page 34 Temperature: Operating: 0°~ 40°C, Storage: -10°~70°C Operating: 10%~90% RH, Humidity: Storage: 5%~90% RH Dimensions: 440 x140 x 44 mm (W x H x D) Weight: 2.1kg Emissions: FCC Class A, CE Mark Class A, VCCI Class A Safety: UL (1950), CB(IEC60950)
