Canon imagePROGRAF W6400 Manual page 52

Print Plug-In for Photoshop
4. Set the roll paper options and click OK.
Setting
Roll Paper Width
Automatic Cutting
No Spaces at Top or
Bottom (Conserve Paper)
• Refer to "Roll Paper Options Dialog Box" (p.2-10) for more information on
Note
the Roll Paper Options dialog box.
• Click the Defaults button to return all of the roll paper option settings to
their defaults.
5. Select either Portrait or Landscape as the media orientation for the image in Orientation.
• When you select Portrait, the image on the media prints as it appears on
Note
the screen.
• When you select Landscape, the image on the media prints rotated 90
degrees.
Chapter 3 Utilize Print Plug-In to Print
Details
This selects the width of the roll paper set to the
printer.
Select either Yes, No or Print Cut Guideline to
activate automatic cutting.
When you place a checkmark here, you can print
without any margins at the top and bottom of an
image.
3-25
