Print Plug-In for Photoshop
Settings
Print Area Layout 2
3 Print Selected Range
Place a checkmark here to only print the selected range.
When you select Image in the Preview, then select a portion of the image on
Note
the preview display, this becomes valid.
4 Perform Proof in Preview
Place a checkmark here to simulate the colors of the output product in the preview.
• When you have selected Auto (for Color - Internal) in Output Profile,
Note
this becomes active for a portion of the media, the resolution and the pass
number. In addition, when you have selected ICC Profile in Output
Profile, this is always active.
• The actual color balance of the print product and the simulation product
may differ with some environments and conditions. In addition, when you
have selected an ICC Profile with Output Profile and it is not compatible
with the printer or media that you are using, the color balance of the actual
print product will differ.
5
When you click this button to open the Image Properties dialog box, where the image size,
the resolution, the pass number and the color space information of the image imported to
Print Plug-In are displayed.
Click the Close button to return to Print Plug-In.
Chapter 2 Functions of Print Plug-In
Details
This is the layout matching the Media Size you have set,
and both the valid print range and the area outside of that
range are displayed.
• You can change the image print position when you
drag the image while the cursor is displayed as
The entire image is displayed.
• You can select the print range when you drag the
image while the cursor is displayed as
• When you click the image while the cursor is displayed
as , the selected area is deselected.
.
.
