SERVICE MANUAL
REVISED
Discard MHC-GRX3/R300/R500/RX55 Service Manual
(No.9-922-801-11) previously issued.
This Service Manual contains it.
• MHC-GRX3/R300/R500/R55 is composed of following
models.
As for the service manual, it is issued for each component
model, then, please refer to it.
COMPONENT MODEL NAME FOR MHC-GRX3/R300/R500/RX55
COMPACT DISC DECK
RECEIVER SYSTE
SPEAKER SYSTEM
General
Power requirements
North American model: 120 V AC, 60 Hz
European model: 230 V AC, 50/60 Hz
Mexican model: 120 V AC, 50/60 Hz
Australian and South African models:
220-240 V AC, 50/60 Hz
Other models: 110-120 V or 220-240 VAC,
50/60 Hz (Adjastable
with voltage selector)
PARTS LIST
Ref.No. Part No. Description
–––––– ––––––– –––––––––
ACCESSORIES & PACKING MATERIALS
********************************
1-475-827-11 REMOTE COMMANDER(RM-SG7B)(GRX3/RX55)
1-475-828-11 REMOTE COMMANDER(RM-SG7)(R300/R500)
1-501-374-11 ANTENNA,LOOP
1-501-594-11 ANTENNA (FM)
3-862-439-11 MANUAL,INSTRUCTION(ENGLISH)(US,CND)
3-862-439-21 MANUAL,INSTRUCTION(FRENCH)(CND)
3-862-439-31 MANUAL,INSTRUCTION(FRENCH,SPANISH)
3-862-439-91 MANUAL,INSTRUCTION(CHINESE)(SP,MY,TW)
MICROFILM
9-922-801-12
MHC-GRX3 MHC-R300
HCD-GRX3 HCD-R300
SS-J20A SS-J20B
SPECIFICATIONS
Remark
––––––
(E,SP,MY,MX,AR,TW)
Sony Corporation
Home A&V Products Company
MHC-GRX3/R300/
MHC-R500 MHC-RX55
HCD-R500 HCD-RX55
SS-J30B SS-J15A(US,CND) SS-J30(AEP,UK)
Power consumption
Supplied accessories
AM loop antenna (1)
Remote RM-SG7(R300/R500) (1)
Remote RM-SG7B(GRX3/RX55) (1)
FM wire antenna (1)
Design and specifications are subject to change without notice.
Ref.No. Part No. Description
–––––– ––––––– –––––––––
4-982-031-01 COVER,BATTERY
MINI Hi-Fi COMPONENT SYSTEM
R500/RX55
US Model
Canadian Model
AEP Model
UK Model
MHC-R500/RX55
E Model
MHC-GRX3/R300
Australian Model
MHC-GRX3
• Abbreviation
CND : Canadian model
MY : Malaysian model
MX : Mexican model
AR : Argentine model
SP : Singapore model
TW : Taiwan model
100W
Printed in Japan ©1998.7
Published by Quality Assurance Dept.
http://getMANUAL.com
MHC-RX55
Remark
––––––
98G001689-1
(Shibaura)
