Sony HCD-BX20I - Compact Disc Receiver Component Service Manual

Service manual.
Hide thumbs

CMT-BX20i/BX50BTi
SERVICE MANUAL
US Model
CMT-BX20i/BX50BTi
Canadian Model
Ver. 1.0 2008.02
Australian Model
CMT-BX20i
• CMT-BX20i/BX50BTi are composed of following models.
As service manuals are issued for each component model, please
refer to them.
COMPONENT MODEL NAME
CMT-BX20i
CMT-BX50BTi
Compact Disc Receiver
HCD-BX20i
HCD-BX50BTi
Speaker System
SS-CBX20
• The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sony
Corporation is under license. Other trademarks and trade names are those of their respective owners.
• MPEG Layer-3 audio coding technology and patents licensed from Fraunhofer IIS and Thomson.
• iPod is a trademark of Apple Inc., registered in the U.S. and other countries.
SPECIFICATIONS
ACCESSORIES
Part No.
Description
Remark
iPod section
Compatible iPod models:
1-754-102-31
ANTENNA, LOOP (LW.MW) (AM loop antenna)
1-754-243-11
ANTENNA (FM lead antenna)
2-055-382-01
LID, BATTERY CASE (for Remote commander)
3-293-641-12
MANUAL, INSTRUCTION (ENGLISH) (BX20i)
3-293-641-22
MANUAL, INSTRUCTION (FRENCH) (BX20i: CND)
iPod nano 3rd
generation
3-293-642-12
MANUAL, INSTRUCTION (ENGLISH) (BX50BTi)
iPod classic
(video)
iPod touch
A-1438-479-A
RM-AMU009 (Remote commander) (including battery case lid)
(US, CND)
A-1519-797-A
RM-AMU011 (Remote commander) (including battery case lid)
(BX20i: AUS)
A-1539-392-A
PACK ASSY, ADAPTOR (iPod Dock Adaptors: 1 set) (US, CND)
iPod nano 2nd
iPod nano 1st
iPod 5th
generation
generation
generation
(aluminum)
• Abbreviation
(video)
AUS
: Australian model
CND : Canadian model
iPod mini
iPod 4th
iPod 4th
generation
generation
(color display)
General
Power requirements:
North American model: 120 V AC, 60 Hz
Australian model: 230 − 240 V AC, 50/60 Hz
Power consumption: 63 watts
Dimensions (w/h/d) (excl. speakers): Approx. 215 × 140 × 298 mm
Mass (excl. speakers): Approx. 3.9 kg
Supplied accessories: Remote Commander (1)/R6 (Size AA) batteries (2)/
AM loop antenna (1)/FM lead antenna (1)/iPod Dock Adaptors (1 set)
(Except for Australian model)
Design and specifi cations are subject to change without notice.
MICRO HI-FI COMPONENT SYSTEM
Sony Corporation
9-889-021-01
2008B05-1
Audio Business Group
©
2008.02
Published by Sony Techno Create Corporation
