ASROCK PV530 Specifications

PV530
VIA PV530 CPU + VX900 Chipset
®
Product Brief
- VIA PV530 Processor (1.8 GHz)
®
- Solid Capacitor for CPU power
- Supports DDR3 / DDR2 memory
- Integrated VIA Chrome9 HD DX9 Graphics,
®
DirectX 9.0, Max. shared memory 512MB
- Supports ASRock Instant Boos, Instant Flash,
OC Tuner, OC DNA
- ErP/EuP Ready
- Free Software : CyberLink DVD Suite - OEM and
Trial; Creative Sound Blaster X-Fi MB - Trial
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
ww w. as ro ck. c o m
Detail Specification
Platform
- Micro ATX Form Factor: 8.5-in x 6.7-in, 21.6 cm x 17.0 cm
- Solid Capacitor for CPU power
CPU
- VIA PV530 Processor (1.8 GHz)
®
- Supports FSB800 MHz
- Supports Untied Overclocking Technology
Chipset - VIA VX900
®
- 1 x DDR3 DIMM slot
Memory
- Supports DDR3 800 non-ECC, un-buffered memory
- Max. capacity of system memory: 4GB
- 2 x DDR2 DIMM slots
- Supports DDR2 800/667/533 non-ECC, un-buffered
memory
- Max. capacity of system memory: 4GB
- 1 x PCI Express 2.0 x16 slot (blue @ x8 mode)
Expansion Slot
- 1 x PCI slot
Graphics
- VIA Chrome9 HD DX9 Graphics
®
- Pixel Shader 2.0, DirectX 9.0
- Max. shared memory 512MB
- Supports D-Sub with max. resolution up to 2048x1536
@ 75Hz
Audio - 5.1 CH HD Audio (VIA
LAN
- Atheros PCIEx1 LAN AR8132L
®
- Speed: 10/100 Ethernet
- Supports Wake-On-LAN
Rear Panel I/O
I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Parallel Port (ECP/EPP Support)
- 1 x Serial Port: COM1
- 1 x VGA Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and
SPEED LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
Connector
- 2 x SATAII 3.0 Gb/s connectors
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
BIOS Feature
- 4Mb AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
Support CD
- Drivers, Utilities, AntiVirus Software (Trial Version),
ASRock Software Suite (CyberLink DVD Suite - OEM and
Trial; Creative Sound Blaster X-Fi MB - Trial)
Unique Feature
- ASRock OC Tuner
- Instant Boot
- ASRock Instant Flash
- ASRock OC DNA
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
Hardware Monitor - CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU/Chassis/Power Fan Tachometer
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
OS
- Microsoft Windows
®
Certifications
- FCC, CE, WHQL
- ErP/EuP Ready (ErP/EuP ready power supply is required)
Accessories - Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables (Optional)
V1705 Audio Codec)
®
7 / Vista / XP compliant
