ASROCK G41C-VS Specifications

G41C-VS
Intel G41+ ICH7 Chipsets
®
Product Brief
- Supports FSB1333/1066/800/533 MHz CPUs
- Supports Dual Channel DDR3 1333 (OC) +
DDR2 800
- Intel Graphics Media Accelerator X4500,
®
Pixel Shader 4.0, DirectX 10, Max. shared
memory 1759MB
- EuP Ready
- Supports ASRock Instant Boot, Instant Flash,
OC DNA, ASRock OC Tuner (Up to 143% CPU
frequency increase)
- Supports Smart BIOS, Intelligent Energy
Saver (Up to 20% CPU Power Saving)
- Free Bundle : ASRock Software Suite
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
Detail Specification
Platform
CPU
Chipset
Memory
Expansion Slot
Graphics
Audio
LAN
Rear Panel I/O
EuP
EuP
Ready
Connector
BIOS Feature
Support CD
Unique Feature
Hardware Monitor
OS
Certifications
Accessories
www.as rock.com
- Micro ATX Form Factor: 8.8-in x 7.8-in, 22.4 cm x 19.8 cm
- LGA 775 for Intel Core 2 Extreme / Core
® TM
Core 2 Duo / Pentium Dual Core / Celeron
TM ®
/ Celeron ® , supporting Penryn Quad Core Yorkfield and
Dual Core Wolfdale processors
- Supports FSB1333/1066/800/533 MHz
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology
- Supports EM64T CPU
- Northbridge: Intel G41
®
- Southbridge: Intel ® ICH7
- Dual Channel DDR3/DDR2 memory technology
- 2 x DDR3 DIMM slots
- Supports DDR3 1333(OC)/1066/800 non-ECC,
un-buffered memory
- Max. capacity of system memory: 8GB
- 2 x DDR2 DIMM slots
- Supports DDR2 800/667/533 non-ECC, un-buffered
memory
- Max. capacity of system memory: 8GB
- 1 x PCI Express x16 slot
- 1 x PCI slot
- Intel Graphics Media Accelerator X4500
®
- Pixel Shader 4.0, DirectX 10
- Max. shared memory 1759MB
- Supports D-Sub with max. resolution up to 2048x1536
@ 75Hz
- 5.1 CH Windows Vista Premium Level HD Audio
® TM
(Realtek ALC662 Audio Codec)
- Atheros PCIEx1 LAN AR8132L
®
- Speed: 10/100 Ethernet
- Supports Wake-On-LAN
I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Serial Port: COM1
- 1 x VGA Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and
SPEED LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
- 2 x SATAII 3.0 Gb/s connectors (No support for RAID
and "Hot Plug" functions)
- 1 x ATA100 IDE connector (supports 2 x IDE devices)
- 1 x Print port header
- CPU/Chassis FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
- 8Mb AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- SMBIOS 2.3.1 Support
- VCCM, NB, VTT, GTLRef Voltage Multi-adjustment
- Supports Smart BIOS
- Drivers, Utilities, AntiVirus Software (Trial Version),
ASRock Software Suite (CyberLink DVD Suite - OEM
and Trial ; Creative Sound Blaster X-Fi MB - Trial)
- ASRock OC Tuner
- Intelligent Energy Saver
- Instant Boot
- ASRock Instant Flash
- ASRock OC DNA
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
- Microsoft Windows 7 / 7 64-bit / Vista
® ®
/ XP / XP 64-bit compliant
- FCC, CE
- EuP Ready (EuP ready power supply is required)
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables (Optional)
2 Quad /
TM
Dual Core
®
/ Vista 64-bit
TM TM
