Specifications

Specifications
System
Modulation
Frequency ranges
Switching bandwidth
Frequencies
Signal-to-noise ratio
THD
Temperature range
EM 10 receiver
Receiver principle
Sensitivity
(at peak deviation)
Adjacent channel rejection ≥ 60 dB
Intermodulation
attenuation
Blocking
AF frequency response
Pilot tone
Antenna input
AF output voltage
(at peak dev., 1 kHz AF)
Power supply
Dimensions
Weight
wideband FM
A: 548-572 MHz
GB: 606-630 MHz
B: 614-638 MHz
C: 766-790 MHz
E: 821-832 MHz and 863-865 MHz
24 MHz (range E: 13 MHz)
960 (range E: 520), tuneable in steps of 25 kHz
8 frequency banks, each with up to 12 factory-preset
channels
≥ 103 dBa
≤ 1%
0°C to +40°C
true diversity
< 3 μV at 52 dBa
rms S/N
≥ 50 dB
≥ 65 dB
50 – 16,000 Hz
32.768 kHz
2 BNC sockets, 50 Ω
¼'' (6.3 mm) jack socket (unbalanced): +8 dBu
XLR socket (balanced): +14 dBu
12 V nom. / 300 mA
DC
200 x 42 x 127 mm
730 g
XS WIRELESS | 13
