Sennheiser MZH 3015 Product Sheet

MZH 3015
MZH 3040
Features
• Sturdy and elegant metal gooseneck for
unobtrusive miking
• RF shielding against intermodulation
from wireless equipment/devices
Architect's Specifications
The unit shall be streamlined in appear-
ance, with a boom diameter of 8 mm
(.31") and an overall length of 15 cm
(5.9") and 40 cm (15.75"). It must also
be finished with a durable anti-reflective
matte black coating and have a pre-amp
housed with its XLR-3 connector
housing. The unit must be mountable
using a table stand, direct to surface
receptacle or via a silent shock mount
system. The unit shall accept the ME34,
ME35 and ME36 microphone capsules.
The unit shall be a Sennheiser MZH
3015. The unit shall be a MZH 3040.
installed sound goosenecks
The MZH 3015 and MZH 3040
elegant metal goosenecks for use with the ME 34, ME 35 and
ME 36 microphone capsules. The rugged, matte black goose-
necks are fitted with a balanced, floating XLR-3 output,
enabling the microphone to be powered from 12 – 48 V
phantom power.
Technical Data
Connection . . . . . . . . . . . . . . . . . XLR 3
Phantom Powering . . . . . . . . . . P 12 - P48 V
Coating . . . . . . . . . . . . . . . . . . . . . matte black
Diameter . . . . . . . . . . . . . . . . . . . 6 mm (0.24")
Length . . . . . . . . . . . . . . . . . . . . . 150 mm (5.91")
Number of flexible elements . . 1
Weight (goosenecks) . . . . . . . . 73 g (23 oz.)
Delivery includes . . . . . . . . . . . . MZH 3015
are sturdy and
400 mm (15.75")
120 g (38 oz.)
MZH 3040
