The Thomson Technology MPC-ETN is a multi-protocol converter and Serial –Ethernet media converter. This Quick
Installation Guide will describe the method to interface a PC to either a MEC 20 or TSC 800 controller over an
RS485/232 serial interface.
Check Components:
Unpack and ensure that all components are in good condition.
Qty
Description
1
MPC-ETN protocol converter
2
RJ45 to DB9M Converter
1
RJ45 to DB9F Converter
1
6ft Ethernet Cable (CAT5)
1
10ft Ethernet Cable (CAT5)
1
Software & Documentation CD-ROM
Gateway Utility Software – Download the latest from www.thomsontechnology.com
Customer Required Components:
Qt
Description
y
1
Ethernet Cable
1
24VDC power supply (min 12Vdc, max
30Vdc), 100mA max.
NOTES:
1. Your IT SUPPORT GROUP must assign a 'Static IP Address' to the MPC-ETN. The 'Static IP Address' is
required so that the MPC-ETN device will work correctly on your Ethernet Network.
2. Modscan32 software is needed for Check/Verification of the MPC-ETN setup. Download Modscan32 from the
following link - http://www.win-tech.com/html/demos.htm - ModScan32.zip (851K) . Follow the Setup Wizard
for the installation of the Modscan32 Software.
THOMSON TECHNOLOGY ● 9087A – 198
TELEPHONE: (604) 888-3381 ● EMAIL: info@thomsontechnology.com ● www.thomsontechnology.com
PM086 REV 1 08/08/28
Quick Installation Guide for MPC-ETN
th
STREET, LANGLEY, BC CANADA V1M 3B1
Advertisement
Related Manuals for THOMSON MPC-ETN
Summary of Contents for THOMSON MPC-ETN
-
Page 1: Check Components
Quick Installation Guide for MPC-ETN The Thomson Technology MPC-ETN is a multi-protocol converter and Serial –Ethernet media converter. This Quick Installation Guide will describe the method to interface a PC to either a MEC 20 or TSC 800 controller over an RS485/232 serial interface. -
Page 2: Programming Cable
Programming Cable: Insert one end of the 6ft Ethernet cable into the connector labeled MPC-COM2 (RS232). Insert the other end of the 6ft Ethernet cable into the connector labeled PC. THOMSON TECHNOLOGY ● 9087A – 198 STREET, LANGLEY, BC CANADA V1M 3B1 TELEPHONE: (604) 888-3381 ●... - Page 3 Quick Installation Guide for MPC-ETN Start Up: Connect 24VDC to the power input connector on the MPC-STD. Make sure that the Protective Earth of the • power supply is connected to the Earth connection of the MPC-ETN Power up the MPC-ETN and start Modbus™ communications with the Thomson Technology device (i.e.
- Page 4 Quick Installation Guide for MPC-ETN Setting the Modbus™ node address (default 1) and TCP/IP address: 1. The Gateway 3.11 Utility Software provides access to the IP address of the MPC-ETN. Install the software from the accompanying CD. :\MPC SETUP KIT 311\Setup.exe...
- Page 5 ‘Company Name’, and then Press the NEXT button. Select desired ‘Destination Folder’, and then Press the button. NEXT THOMSON TECHNOLOGY ● 9087A – 198 STREET, LANGLEY, BC CANADA V1M 3B1 TELEPHONE: (604) 888-3381 ● EMAIL: info@thomsontechnology.com ● www.thomsontechnology.com PM086 REV 1 08/08/28...
- Page 6 Press the NEXT Mark both ‘MPC-ETN’ and ‘MPC-STD’ with a ‘check mark’, and then Press the button. NEXT THOMSON TECHNOLOGY ● 9087A – 198 STREET, LANGLEY, BC CANADA V1M 3B1 TELEPHONE: (604) 888-3381 ● EMAIL: info@thomsontechnology.com ● www.thomsontechnology.com PM086 REV 1 08/08/28...
- Page 7 Wait for installation to complete, then Press the OK button. Gateway 3.11 Utility Software is now Complete. 2. Open the required template project (MEC20 or TSC800) using the Project->Open Project menu. Select ‘MPC-ETN’ found in the ‘Product Selection’ tree. Click the ‘Open Project’...
- Page 8 Select ET5MEC20-R2.prj for MEC20 communication or ET10TSC800-R2.prj for TSC800 communication, and then Press the OPEN button. 3. To change the default IP and Ethernet address Press the PLC2 button on the Gateway Utility Software toolbar. Click the Advanced button to open the IP edit dialog box.
- Page 9 IP Address’ is required so that the MPC-ETN device will work correctly on your Ethernet Network. 4. Connect the PC end of the programming cable to the PC and connect the MPC-COM1 end of the programming cable to the MPC-ETN COM1 port.
- Page 10 Click the Select All button then Download. (Cycle power to the MPC-ETN if necessary.) 6. Once download is complete a confirmation will appear. Click OK to re-start the Gateway. 7. Set-up complete. THOMSON TECHNOLOGY ● 9087A – 198 STREET, LANGLEY, BC CANADA V1M 3B1 TELEPHONE: (604) 888-3381 ●...
- Page 11 2. Connect the MPC-COM1 end of Cable 1 to the MPC-ETN port labeled COM1. Connect MPC-ETN to PC 1. Connect a customer supplied Ethernet cable to the Ethernet port of the MPC-ETN (not the Pass Through port). 2. Connect the other end of the customer supplied Ethernet cable to the desired Ethernet network.
- Page 12 1. Connect PC to Ethernet port on the MPC-ETN and Thomson Technology controller (MEC20/TSC800) to COM1 on the MPC-ETN NOTE: Laptop connected directly to the MPC-ETN port will require a ‘Cross Over’ cable IP Address PING Test Select Start found at the bottom left of your screen.
- Page 13 The test may need additional support from your IT SUPPORT GROUP. THOMSON TECHNOLOGY ● 9087A – 198 STREET, LANGLEY, BC CANADA V1M 3B1 TELEPHONE: (604) 888-3381 ● EMAIL: info@thomsontechnology.com ● www.thomsontechnology.com PM086 REV 1 08/08/28...
- Page 14 Quick Installation Guide for MPC-ETN 3. Open ‘Modscan32.exe’ and follow the procedure below: Select ‘Connect’ for the ‘Connection’ drop down menu. Connect Using: ‘Remote Modbus TCP Server’, Enter IT supplied ‘Static IP Address’, Default listening port ‘502’. THOMSON TECHNOLOGY ● 9087A – 198 STREET, LANGLEY, BC CANADA V1M 3B1 TELEPHONE: (604) 888-3381 ●...
-
Page 15: Holding Register
When comm./setup/configuration is correct the program will increment both counters • (Number of Polls and Valid Slave Responses) at the same rate. You may notice that the two numbers are at a different value but both will count up at the same time.
