The Thomson Technology MPC-STD is a multi-protocol converter. This Quick Installation Guide will describe the
method to interface a PC to either a MEC 20 or TSC 800 controller over an RS 485/232 serial interface.
Check Components:
Qty
Description
1
MPC-STD protocol Converter
2
RJ45 to DB9M Converter
1
RJ45 to DB9F Converter
1
6ft Ethernet Cable (CAT5-STP)
1
10ft Ethernet Cable (CAT5-STP)
1
Software & Documentation CD-ROM*
*MPC Gateway Utility Software –Download from
Customer Required Components:
Qty
Description
1
24VDC power supply (min 12Vdc, max
30Vdc), 100mA max.
NOTE:
1. Modscan32 software is needed for Check/Verification of the MPC-STD setup. Download Modscan32 from the
following link - http://www.win-tech.com/html/demos.htm - ModScan32.zip (851K). Follow the Setup Wizard
for the installation of the Modscan32 Software.
THOMSON TECHNOLOGY ● 9087A – 198
TELEPHONE: (604) 888-3381 ● EMAIL: info@thomsontechnology.com ● www.thomsontechnology.com
PM085 REV 1 08/08/28
Quick Installation Guide for MPC-STD
www.thomsontechnology.com
th
STREET, LANGLEY, BC CANADA V1M 3B1
