Smeg ST113-2 Instruction Manual

Hide thumbs

Advertisement

Quick Links

INSTRUCTION MANUAL
GUIDE FOR USING THE DISHWASHER AND THE WASHING PROGRAMS

Advertisement

loading

Related Manuals for Smeg ST113-2

Summary of Contents for Smeg ST113-2

  • Page 1 INSTRUCTION MANUAL GUIDE FOR USING THE DISHWASHER AND THE WASHING PROGRAMS...
  • Page 3 Cleaning and maintenance _______________________________ 25 Troubleshooting _______________________________________ 29 Thank you for choosing one of our products. You are advised to read this manual carefully; it contains all the information you need about the right conditions for the proper, safe use of your dishwasher.

  • Page 4: User Instructions

    All the dishwasher controls are grouped on the upper panel. Switch-on, programming, switch-off, etc. procedures are only possible when the door is open. The panel shown is only a guideline example: the form of the lights and buttons may vary depending on the model. ON/OFF BUTTON Press this button to switch the dishwasher on/off.
  • Page 5 Adds a final antibacterial rinse to the selected program. Spread HALF LOAD WASH Allows washing of just a few dishes placed in both baskets. PROGRAM DELAY Allows the program to be set to start with a delay of 3, 6 or 9 hours.
  • Page 6 PROGRAMS TABLE The manual contains the programs table for several models. To find the table for your dishwasher, compare the program symbols at the top of the table with those on your control panel. SETTING THE WASHING PROGRAM AND SWITCHING ON...
  • Page 7 The ULTRA CLEAN program terminate with an extra anti-bacteria rinse that ensures a further reduction in the bacteria level. If the temperature falls during this stage of the program (e.g. because the door is opened or due to a power blackout), the program lights flash to warn that the anti-bacteria effect is not guaranteed.
  • Page 8 15,5 1,60 dishes, even with dried-on Cold rinse (2) residues. Rinse at 70°C **** IMPORTANT: see “NOTES AND REFERENCES” table on the following pages. If the dishwasher door is open or not properly closed, the washing cycle will not start.
  • Page 9 The ULTRA CLEAN program terminate with an extra anti-bacteria rinse that ensures a further reduction in the bacteria level. If the temperature falls during this stage of the program (e.g. because the door is opened or due to a power blackout), the program lights flash to warn that the anti-bacteria effect is not guaranteed.
  • Page 10 Standard programme under EN 50242. See information sheet provided IEC/DIN reference programme. Reference program for laboratories: Detergent: 20g in the dispenser + 10g in **** the door or tablet. Configuration: see photo in “Using the baskets”. The cycle duration and power consumption may vary according to the water and room temperatures, and the type and amount of dishes.
  • Page 11 Some models feature additional options, activated by pressing two buttons simultaneously. In this case, two lines in the control panel graphics link the symbol of the additional option to the two buttons to be pressed simultaneously to enable it. (e.g. “Flexi Tabs” in this...
  • Page 12 (the light goes out). If the water hardness has been set on a value above H3, and the “Flexi Tabs” option is activated, the relative light flashes, warning of a setting error.
  • Page 13 The start of the program can be delayed by 3, 6 or 9 hours. This allows you to set the dishwasher to work at the times of day most convenient to you. After setting the program, press the button to select the delay you require;...
  • Page 14 To ensure that any drops of water left in the top basket cannot drip onto the dishes still in the bottom basket, you are advised always to empty the bottom basket first.

  • Page 15: Operating Instructions

    Before replacing the cap, remove any salt residues from around the opening. When using the dishwasher for the first time, in addition to the salt it is also necessary to add one litre of water to the container.
  • Page 16 ADJUSTING THE WATER SOFTENING SYSTEM The dishwasher is equipped with a device which allows the softener setting to be varied to suit the hardness of the mains water. The hardness is set using the PROGRAM SELECTION BUTTON (3). To access the setting function, hold the button down for more than 15 seconds.
  • Page 17 Contact your local water board for information on the hardness of your water supply. After adjustment or display of the current setting, simply do not touch the button for a few seconds; the dishwasher will automatically return to standard mode, quitting the adjustment mode.
  • Page 18 Replace the cover and turn it in a clockwise direction. Use a cloth to remove any spillage of rinse aid which might lead to the formation of excess foam. ADJUSTING THE RINSE AID DISPENSER SETTING The dishwasher is factory set for medium water hardness.
  • Page 19 Use only detergents specially formulated for dishwashers. For optimal washing results it is important to use a good quality detergent. The detergent packs must be sealed and stored in a dry place to prevent the formation of lumps which may negatively affect washing results.
  • Page 20 The introduction of detergent into the rinse aid dispenser, even in liquid form, will damage the dishwasher. General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types to be washed and their loading.
  • Page 21 If in doubt as to the fastness of the colours, it is advisable to wash just a few items at a time for approximately one month.
  • Page 22 The dishwasher has a capacity of 12 place-settings, including serving dishes. LOWER BASKET The lower basket receives the full force of the lower spray arm, and should therefore be used for the “toughest” items with a heavier degree of soiling.
  • Page 23 The cutlery supports and central lid are in the bag of accessories. The central lid is intended to act only as a cover: do not place the cutlery in it. Depending on model the grids may vary in shape.
  • Page 24 It is recommended to load the upper basket with small- or medium-sized items such as glasses, small plates, tea or coffee cups, shallow bowls and light objects made from heat resistant plastic. If the upper basket is used in the lowermost position, it can also be loaded with serving dishes, provided they are only slightly soiled.
  • Page 25 User instructions Depending on the models, the basket may be equipped with some or all of the following accessories: Supports for cups or long objects (ladles, spoons…), on the left; can be tipped to the vertical position when not in use.
  • Page 26 Fit the upper or lower pair of wheels into the guide, depending on the setting required Return the stops to their original position. The left hand and right hand sides of the basket must always be set at the same height. Version B: with adjustment in three positions on both sides.

  • Page 27: Cleaning And Maintenance

    CLEANING THE WATER INTAKE FILTER The water intake filter A located at the outlet of the water supply tap needs to be cleaned periodically. After having closed the water supply tap, unscrew the end of the water intake hose, remove the filter A and clean it delicately under running water.
  • Page 28 CLEANING THE FILTER UNIT It is advisable to periodically inspect the centre filter C and, if necessary, to clean it. To remove the filter, grip the tabs, turn them anticlockwise and lift upwards; push the centre filter D from the underside to remove it from the...
  • Page 29 DISUSE: Check that there are no deposits of sludge or rust inside the water pipe: if there are, allow the water to run from the water supply tap for a few minutes. Plug the power cord back into the socket.
  • Page 30 If there are visible traces of rust inside the tank: the tank is made of steel, and therefore any rust marks are due to external elements (fragments of rust from the water pipes, pots, cutlery, etc.).

  • Page 31: Troubleshooting

    User instructions 4. Troubleshooting The dishwasher is capable of signalling a number of faults through the simultaneous illumination of several indicator lights, with the following meanings: FAULT DESCRIPTION Acquastop failure The anti-flooding system has been activated (for the relevant models only). The system is tripped in case of water leaks.
  • Page 32 To “reset” an alarm is necessary: Open and close the door, or turn off and on the machine. At this point is possible to program the dishwasher again.
  • Page 33 Height (depending on models) Semi-integrated: from 820 mm to 890 mm from 860 mm to 930 mm Capacity 12 Standard place settings Water supply pressure min. 0,05 - max. 0,9 MPa (min. 0.5 – max. 9 bar) Electrical characteristics See rating plate...

This manual is also suitable for:

St119-2Dishwasher
